Power Supply
AGILENT-Hp/Keysight 6644A
Output Ratings
Output voltage: 0 to 60 V
Output current (40° C): 0 to 3.5 A
Maximum current (50° C/55° C): 3.2 A/3 AProgramming Accuracy at 25°C ±5°C
Voltage 0.06% + 26 mV
Current 0.15% + 4.1 mARipple & Noise (20 Hz – 20 MHz)
Voltage rms: 500 µV
Voltage peak-to-peak: 5 mV
Current rms: 1.5 mAKeysight high performance DC power supplies offer speed and accuracy for test optimization. The single output, 200 W, GPIB 6641A-6645A provide fast, low-noise outputs; analog control of output voltage and current; fan-speed control to minimize acoustic noise; as well as parallel and series connections of multiple units.
The Keysight 210W, GPIB, single output 6644A is a versatile programmable supply designed to maximize test throughput during design verification or on the production line, and is fully programmable to help reduce test time through a variety of automated capabilities.
DatasheetSKU: 1166 -
Power Supply
AGILENT-Hp/Keysight 6645A
Questa serie di alimentatori CC regolati lineari da 200 W è progettata per massimizzare la produttività dei DUT attraverso il processo di test di produzione con tempi di programmazione rapidi su e giù.
I preziosi insiemi possono essere distrutti da un guasto minore di un componente che può consentire un flusso di tensione o corrente che fluisce verso il DUT. Le funzioni di protezione rapida, tra cui il piede di porco rapido, la protezione crossover in modalità e la possibilità di collegare i circuiti di protezione di più alimentatori possono aumentare il rendimento di produzione.
La programmazione dell'uscita CC e delle funzioni di protezione può essere effettuata dal pannello frontale o utilizzando i comandi SCPI standard del settore, tramite GPIB. Utilizzando il collegamento seriale, è possibile collegare fino a 16 alimentatori tramite un indirizzo GPIB. L'integrazione del sistema di test può essere ulteriormente semplificata utilizzando i driver VXIplug & play. La tensione e la corrente di uscita possono anche essere controllate con segnali analogici. Ciò è utile per alcuni tipi di ambienti rumorosi e anche per reazioni immediate ai cambiamenti di processo.Tensione flottante CC: i terminali di uscita possono essere fatti galleggiare fino a ± 240 V CC dalla terra del telaio.
Telerilevamento: è possibile far cadere fino a metà della tensione di uscita nominale in ciascun cavo di carico. La caduta del carico comporta la sottrazione della tensione disponibile per il carico.
Tempo di elaborazione del comando: il tempo medio necessario affinché la tensione di uscita inizi a cambiare in seguito alla ricezione di dati digitali è di 20 ms per gli alimentatori collegati direttamente al GPIB.
Tempo di risposta della programmazione dell'uscita: il tempo di salita e discesa (10/90% e 90/10%) della tensione di uscita è inferiore a 15 ms. La variazione della tensione di uscita si assesta entro 1 LSB (0,025% x tensione nominale) del valore finale in meno di 60 ms.
Programmazione verso il basso: un programmatore attivo verso il basso affonda circa il 20% della corrente di uscita nominale.Valori nominali di uscita
Tensione di uscita: da 0 a 120 V.
Corrente di uscita (40 ° C): da 0 a 1,5 A
Corrente massima (50 ° C / 55 ° C): 1,4 A / 1,3 APrecisione di programmazione a 25 ° C ± 5 ° C
Tensione 0,06% + 51 mV
Corrente 0,15% + 1,7 mARipple & Noise (20 Hz – 20 MHz)
Voltaggio rms: 700 µV
Tensione picco-picco: 7 mV
Corrente efficace: 1 mA
Scheda TecnicaSKU: n/a -
Power Supply
AGILENT-Hp/Keysight 6675A
Output Ratings
Output voltage: 0 to 120 V
Output current (40°C): 0 to 18 AProgramming Accuracy at 25°C ±5°C
Voltage 0.04% + 120 mV
Current 0.1% + 12 mARipple & Noise from 20 Hz to 20 MHz
Voltage rms: 1.9 mV
Peak-to-Peak: 16 mV
Current rms: 12 mAHp high performance DC power supplies offer speed and accuracy for test optimization. The single output, 2000 W GPIB 6671A-6675A provide fast, low-noise outputs; analog control of output voltage and current; and fan-speed control to minimize acoustic noise.
The Hp 2160W, GPIB, single output 6675A is a highly efficient low-noise supply that maximize test throughput and is designed to offer excellent reliability, low ripple and noise, and extremely accurate built-in measurements of voltage and current.
DatasheetSKU: n/a -
Pulse Pattern Generator
AGILENT-Hp/Keysight 81101A
The Keysight 81101A 50 MHz single-channel Pulse Generator is the economy, entry-level instrument of the 81100 family. All timing parameters (repetition rate, delay, width and transitions) are variable.
The instrument comprises a PLL oscillator that enables the repetition rate to be kept within 0.01% accuracy.
Double-pulses and pulse bursts are available. All pulses can be triggered externally when the PLL is turned off. Bursts can also be triggered by the internal PLL if it is not in use as the repetition-rate generator. An external width (pulse recovery) mode is available, too.
The selectable 50/1000 Ohm source resistance allows output amplitudes up to 10 or 20 Vpp respectively into a 50 Ohm load.
Single-channel pulse generator
50 MHz, 10 V from 50 Ohm into 50 Ohm
Triggerable / PLL operation selectable
Pulse / burst modes selectable
Variable transition times
BNC outputs, single-ended
DatasheetSKU: n/a -
Power Sensor
AGILENT-Hp/Keysight 8481A
HP AGILENT KEYSIGHT POWER SENSOR 8481A 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM Series, EPM-P Series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
8481A offers extraordinary precision, stability and lower SWR.
• Excellent SWR to reduce mismatch uncertainty
• Accurately calibrated and traceable to the US National Institute of Standards and Technology (NIST).
• Compatible with EPM, EPM-P, and P Series power meters, as well as E1416A VXI and discontinued 70100A and 43X power switches
• Accurate average power measurements over -30 to +20 dBm
• Frequency range from 10 MHz to 18 GHz
• Element sensitive to the power of the thermocouple
• Measurement range: 1 µW to 100 mW (-30 dBm to +20 dBm)
• impedance 50 ohm
• Connector N (m)SKU: n/a -
Rf Electronic Calibration Module
AGILENT-Hp/Keysight 85093C
The Keysight 85093C RF electronic calibration (ECal) module makes the calibration of vector network analyzers fast, easy, and accurate. ECal is a precision, single-connection calibration technique for your vector network analyzer. Performing a full two-port calibration takes less than half the time and the number of connections using ECal versus mechanical cal kits. Furthermore, the accuracy of the calibration is comparable between electronic and mechanical methods. Traditional mechanical calibrations require intensive operator interaction, which is prone to errors. With ECal, the operator simply connects the ECal module to the network analyzer and the software controls the rest.
ECal modules are transfer standards capable of transferring the factory calibration accuracy to your network analyzer. The new 85093C RF electronic calibration system is now easily controlled by one of two methods depending on the network analyzer. The Keysight PNA and ENA series of network analyzers controls the module directly through a USB interface.
DatasheetSKU: n/a -
Module
AGILENT-HP/Keysight 89605B
RF Input and Calibration Module
The Agilent 89605B is a RF based Input and Calibration Modules for Vector Signal Analyzer (VSA) Systems. It has applications such as LMDS or wideband wireless LAN design, or signal monitoring applications such as satellite or surveillance.
SKU: n/a -
AGILENT-Hp/Keysight E1439C
The Keysight 1439C/D is ideal for applications in RF signal acquisition, analysis and high resolution ATE. It has a baseband input and a 70 MHz IF input, both with 36 MHz bandwidth. The single-channel 95 MSa/s digitizer combines exceptional spurious-free dynamic range with alias-protected signal conditioning, center-frequency tunable digital filters, and a large signal capture memory, all in a single-wide C-size VXI module. The E1439D also incorporates a 200 MB/sec FPDP (Front Panel Data Port) capable of carrying full bandwidth data out of the module for analysis or storage.
36 MHz input bandwidth centered at 70 MHz
-90 dBfs spurious-free dynamic range
Anti-alias filter and signal conditioning
18MB RAM FIFO memory (expandable to 1.2 GB)
VXIbus outputs
VXI local bus (E1439D only)
Multi-channel compatible
VXI plug&play compatible
Single-slot, C-size module
DatasheetSKU: n/a -
Power Supply
AGILENT-Hp/Keysight E3631A
The triple output, 80 W, GPIB, E3631A provides small, compact size for bench use; low output ripple and noise; built-in measurements and basic programmable features with GPIB and RS232 interface. This clean and reliable supply is designed for general purpose applications; and combines convenient benchtop capabilities with flexible system features in a compact, multi-output package.
Output 1: 0 to 6 V, 0 to 5 A
Output 2: 0 to +25 V, 0 to 1 A
Output 3: 0 to -25 V, 0 to 1 A
Programming Accuracy at 25°C ±5°C
Voltage: 0.05% + 20 mV, 0.05% + 20 mV, 0.1% + 5 mV
+ Current: 0.15% + 4 mA, 0.15% + 4 mA, 0.2% + 10 mA
Normal Mode Voltage: <350 µVrms/ 2 mV p-p, <350 µV rms/2 mV p-p, <350 µV rms/2 mV p-p Normal-mode current: <500 µA rms, <500 µA rms, <2 mA rms Common-mode current: <1.5 µA rms, <1.5 µA rms, <1.5 µA rms Readback Accuracy at 25°C ±5° 1200W, DC System Power Supplies,60V - 50A. DatasheetSKU: n/a -
Power Supply
AGILENT-Hp/Keysight E3646A
The Agilent E3646A 60-watt dual-output programmable power supply features built-in GPIB and RS-232 connectivity and SCPI language compatibility making it easy to create flexible power programs. For general-purpose use, this programmable power supply offers the performance of a system power supply at a surprisingly affordable price.
E364X: Basic System Power
The Agilent E3640A – E3649A power supplies fill the gap between manual bench power supplies and high performance system supplies, offering unmatched performance and functionality at a great price. They’re designed for moderate-speed test where automation is important and throughput is not critical. These single- and dual-output, dual range power supplies are ideal for contract manufacturers and OEMs who need to perform basic electronic functional tests on a variety of products quickly and economically.All models support GPIB and RS-232 for quick connectivity. SCPI (Standard Commands for Programmable Instruments) keeps programming fast and simple. Less than 90 ms output settling time keeps throughput high without the need for a down programmer. Up to five store/recall states help minimize programming time while accelerating test. Remote sensing capability ensures output stability with longer leads.
Great Performance, Outstanding Price
With 30 to 100W of output power, the Agilent E364xA-series of programmable dc power supplies provides great performance at a great price. All ten models deliver clean power, dependable regulation, fast transient response and built-in GPIB and RS-232 interfaces. They’re designed to meet the needs of R&D design verification, production testing, QA verifications and other demanding applications with Agilent Technologies’ quality and reliability.Steady Output
With 0.01 percent load and line regulation, Agilent E364xA power supplies keep output steady when power line and load changes occur. They also specify low normal mode voltage noise and low common mode current noise. The low normal mode noise specification assures clean power for precision circuitry applications, and the low common mode current provides isolation from power line current injection. Agilent E364xA power supplies specify less than 90 msec of voltage settling time at any output load condition.Remote Interface
Agilent E364xA power supplies support any PC with a GPIB (IEEE-488) card or RS-232 interface. Every model ships standard with both GPIB and RS-232. Easy-to-use SCPI (Standard Commands for Programmable Instruments) keeps programming fast and simple. The user manual provides information for beginning programmers, yet includes enough detail to help veteran programmers as well.Broad Support
VXIplug&play software drivers are available for Agilent VEE and National Instruments LabView™ and LabWindows™, simplifying integration of the E364xA into your test system. The drivers are supported under Microsoft® Windows 98 ® and NT. ®Front Panel Operation
An easy-to-use rotary knob and self-guiding keypads allow you to quickly and easily set output at the resolution you need. Voltage and current levels can be set to a maximum resolution of 10 mV/1 mA from the front panel. Up to five complete powers supply setups can be stored and recalled from the internal non-volatile memory. The output on/off button sets the output to zero. Dual output models allow two voltages or currents to be displayed simultaneously.
DatasheetSKU: 895 -
Power Supply
AGILENT-Hp/Keysight N5748A
Output Ratings
Voltage: 80 V
Current: 9.5 A
Power: 760 WThe single output, 760W N5748A, provides universal AC input, GPIB, LAN, USB, LXI compliance, and analog/resistance control of output voltage and current. It delivers reliable performance and enhanced capabilities in a compact 1U package.
SKU: n/a -
Precision DC Power Module
AGILENT-HP/Keysight N6732B
The Keysight N6732B 50 W basic DC power module provides programmable voltage and current, as well as measurement and protection features at a very economical price. Use this module to power your DUT or ATE system resources, such as fixture control.
This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance come standard. Select from more than 20 different DC power modules, ranging in capability from basic to high precision, and in power from 20 – 500 W.
Download BenchVue Basic app for free to control your instruments.
Output RatingsVoltage: 8 V
Current: 6.25 A
Power: 50 WProgramming Accuracy (at 23°C ±5°)
Voltage: 0.1% + 19 mV
Current: 0.15% + 20 mARipple and Noise (20 Hz to 20 MHz)
Voltage rms: 2 mV
Voltage peak-to-peak: 12 mV
Current rms: 4 mASKU: n/a -
Precision DC Power Module
AGILENT-HP/Keysight N6733B
The Keysight N6733B 50 W basic DC power module provides programmable voltage and current, as well as measurement and protection features at a very economical price. Use this module to power the DUT or ATE system resources, such as fixture control.
This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance come standard. Select from more than 20 different DC power modules, ranging in capability from basic to high precision, and in power from 20 – 300 W.
Output ratingsVoltage: 20 V
Current: 2.5 A
Power: 50 WProgramming accuracy (at 23°C ±5°C)
Voltage: 0.1% + 20 mV
Current: 0.15% + 20 mARipple and noise (20 Hz to 20 MHz)
Voltage rms: 3 mV
Voltage peak-to-peak: 14 mV
Current rms: 2 mASKU: n/a -
Audio Analyzer
AGILENT-Hp/Keysight U8903A
DC to 100kHz frequency range
Generator, analyzer, graph and sweep modes
High-quality signals and arbitrary waveforms
S-N ratio, SINAD, IMD, DFD, THD+N ratio, THD+N level, crosstalk and more
GPIB, LAN and USB interfacesWhether listening to mono, stereo or surround, the human ear knows what sounds good. Measuring how good, however, can be a challenge. The Keysight (Agilent/HP) U8903A audio analyzer helps you measure and quantify audio performance in applications such as wireless audio, analog components and ICs, and consumer audio.
Across the audio spectrum and beyond, this scalable, single-unit solution provides versatile measurement functions, diverse test signals and powerful analysis capabilities. Whatever your application, the U8903A can help you make an audible difference in device performance.
SKU: n/a -
Frequency Counter
HP – Agilent/ Keysight 53181A
Optimized for RF applications, the single-channel 10 digit/s 53181A measures frequency, period and peak voltage. A digit-blanking function lets you easily eliminate unnecessary digits when you want to read measurements quickly. For higher-frequency measurements, choose an optional second channel that provides measurements up to 1.5, 3, 5, or 12.4 GHz. A self-guided shallow menu makes this counter exceptionally easy to use
RF Frequency Counter, 10 digits/s
One 225 MHz input channel, plus optional second channel up to 12.4 GHz
10 digits/second resolution
GPIB StandardThe Keysight Technologies, Inc. 53131A/132A/181A high-performance counters give you fast, precise frequency measurements at an affordable price. These counters feature an intuitive user interface and one-button access to frequently used functions so you can make accurate measurements quickly and easily. Real-time digital signal processing technology is used to analyze data while simultaneously taking new readings, speeding measurement throughput. The technology, developed for Keysight’s high-end line of modulation domain analyzers, allows the counters to gather more data for each measurement, so you get higher-resolution measurements in a fraction of the time it takes other counters. The 53131A/132A/181A counters offer built-in statistics and math functions so you can scale measurements and simultaneously measure and track average, min/max and standard deviation. Automated limit testing lets you set upper and lower limits for any measurement. An analog display mode lets you see at a glance whether a measurement is within pass/fail limits. The counters flag out-of-limit conditions and can generate an output signal to trigger external devices when a limit is exceeded. For quick access to frequently used tests, a single keystroke recalls up to 20 different stored front-panel set-ups. For computer-controlled systems applications, each counter includes a standard GPIB interface with full SCPI-compatible programmability and a data transfer rate of up to 200 fully formatted measurements per second. The standard RS-232 talk-only interface provides printer support or data transfer to a computer through a terminal-emulation program.
DatasheetSKU: n/a -
HP 10240B
The HP 10240B Blocking Capacitor is a probing accessory that provides ac-coupling while maintaining a 50 ohm system. This capacitor is designed for use with the model HP 10020A Resistive Divider Kit, and the Keysight 54006A Resistive Divider Probe Kit, but may be used with any probe that must be terminated in 50 Ω.
* Provides ac-coupling
* Maintains a 50 ohm system
* Capacitance: 0.18 µF
* Maximum voltage: +/-200 Vdc
* Sag: Approximately 10% per µs (1% in 100 ns)
* Connectors: BNC
* Reflection: less than 12% when driven by a 150 ps risetime step in a 50 ohm system
* Capacitance: 0.18 µF
* Maximum voltage: +/-200 Vdc
* Sag: Approximately 10% per µs (1% in 100 ns)
* Connectors: BNC
* Reflection: less than 12% when driven by a 150 ps risetime step in a 50 ohm system
DatasheetSKU: n/a -
Oscillator
HP 8350A Sweep Oscillator
The HP 8350A Sweep Oscillator is a solid-state, swept signal source. This unit can be used with network analyzer systems such as the HP 8410B (Network Analyzer), the HP 8755 (Frequency Response Test Set), and others.
Accepts the 86200 (with adapter) and 83500 series of plug-ins for true versatility. Frequency range is dependent upon plug-in used (sold separately). Mainframe features also include the ability to save & recall up to 9 different front-panel settings! This is a very reliable mainframe that will provide years of quality service.* LCD Display
* Remote Programmable via GPIB
* Different Configuration Options with Different RF Plug-Ins
* 27.8 kHz or 1 kHz Square Wave ModulationSKU: 397€0.00 View Product -
Adapter
HP E5346A HIGH DENSITY PROBE ADAPTER
The HP E5346A Mictor probe provides a convenient and reliable connection to your target through a Mictor connector designed into your target. Route your signals of interest to the location containing the Mictor connector and when you are ready to measure these signals simply plug-in the Mictor probe. These probes can be used with a support shroud in environments where accidental unplugging of the probe is a concern. This probe can be used with any HP/Agilent logic analyzer with a 40-pin cable connector.
SKU: n/a -
RF Plug
HP-Agilent/Keysight 83545A
The HP 83545A was designed to be used in the 8350 Mainframe
This unit is a RF Sweep Oscillator Plug-in offers high performance 5.9 to 12.4GHz frequency coverage with exceptionally high output power.
In addition, the 83545A provides slope compensation and complete HP-IB programmability.
The output power is internally leveled to at least 17 dB, with power variations less that 0.6 dB.SKU: 633 -
Signal Generator
HP-Agilent/Keysight 83650A
The Agilent 83650A synthesized sweeper is the standard of excellence for applications requiring the high performance and accuracy of a synthesized source and the speed and versatility of a sweep oscillator. Synthesized broadband frequency coverage and precise 1 Hz frequency resolution (Opt 008) are generated by indirect synthesis, enabling the Agilent 83650A to achieve low single-sideband phase noise performance. It delivers excellent harmonic performance with harmonics at least 50 dB below the carrier from 2.0 to 26.5 GHz, and at least 40 dB below the carrier above 26.5 GHz.
Features:
Scan modulation to simulate antenna scan patterns
Accurate fixed and swept frequency offset for two-tone measurement
User flatness correction for leveling at remote points in the test system
General purpose source for use in component test, receiver test and for frequency conversion
Sweep Modes: Step, List, Ramp
Maximum Power: +10 dBm 26.5 GHz
Maximum Power: +2.5 dBm >40 GHz
Power Sweep Range: -20 dBm to maximum power
Phase Noise (50 GHz at 10 KHz): -68 dBc
Max FM Deviation (locked): +/- 8 MHz
DatasheetSKU: n/a -
Power Sensor
HP-Agilent/Keysight 8487D
Il sensore di potenza a diodo 8487D misura la potenza media nell'intervallo di frequenza da 50 MHz a 50 GHz e l'intervallo di potenza da -70 a -20 dBm (intervallo dinamico 50 dB).
L'attenuatore Keysight 11708A 30 dB viene fornito con sensori di potenza serie 8480 con il suffisso “D”, per la calibrazione con misuratore di potenza 0 dBm, riferimento 50 MHz.
SWR eccellente per ridurre l'incertezza di mancata corrispondenza
Calibrazione e tracciabilità accurate alla calibrazione del sensore a onde millimetriche del National Institute of Standards and Technology (NIST)
Compatibile con misuratori di potenza EPM (nuovo N1913A / 14A, E4418B / 19B), EPM-P (E4416A / 17A) e serie P (N1911A / 12A), oltre al misuratore di potenza E1416A VXI e fuori produzione 70100A e 43X
Misurazioni di potenza media accurate oltre -70 a -20 dBm
Gamma di frequenza da 50 MHz a 50 GHz
Elemento di rilevamento della potenza del diodo
DatasheetSKU: n/a
-
Power Supply
AGILENT-Hp/Keysight 6644A
Output Ratings
Output voltage: 0 to 60 V
Output current (40° C): 0 to 3.5 A
Maximum current (50° C/55° C): 3.2 A/3 AProgramming Accuracy at 25°C ±5°C
Voltage 0.06% + 26 mV
Current 0.15% + 4.1 mARipple & Noise (20 Hz – 20 MHz)
Voltage rms: 500 µV
Voltage peak-to-peak: 5 mV
Current rms: 1.5 mAKeysight high performance DC power supplies offer speed and accuracy for test optimization. The single output, 200 W, GPIB 6641A-6645A provide fast, low-noise outputs; analog control of output voltage and current; fan-speed control to minimize acoustic noise; as well as parallel and series connections of multiple units.
The Keysight 210W, GPIB, single output 6644A is a versatile programmable supply designed to maximize test throughput during design verification or on the production line, and is fully programmable to help reduce test time through a variety of automated capabilities.
Datasheet -
Power Supply
AGILENT-Hp/Keysight 6645A
Questa serie di alimentatori CC regolati lineari da 200 W è progettata per massimizzare la produttività dei DUT attraverso il processo di test di produzione con tempi di programmazione rapidi su e giù.
I preziosi insiemi possono essere distrutti da un guasto minore di un componente che può consentire un flusso di tensione o corrente che fluisce verso il DUT. Le funzioni di protezione rapida, tra cui il piede di porco rapido, la protezione crossover in modalità e la possibilità di collegare i circuiti di protezione di più alimentatori possono aumentare il rendimento di produzione.
La programmazione dell'uscita CC e delle funzioni di protezione può essere effettuata dal pannello frontale o utilizzando i comandi SCPI standard del settore, tramite GPIB. Utilizzando il collegamento seriale, è possibile collegare fino a 16 alimentatori tramite un indirizzo GPIB. L'integrazione del sistema di test può essere ulteriormente semplificata utilizzando i driver VXIplug & play. La tensione e la corrente di uscita possono anche essere controllate con segnali analogici. Ciò è utile per alcuni tipi di ambienti rumorosi e anche per reazioni immediate ai cambiamenti di processo.Tensione flottante CC: i terminali di uscita possono essere fatti galleggiare fino a ± 240 V CC dalla terra del telaio.
Telerilevamento: è possibile far cadere fino a metà della tensione di uscita nominale in ciascun cavo di carico. La caduta del carico comporta la sottrazione della tensione disponibile per il carico.
Tempo di elaborazione del comando: il tempo medio necessario affinché la tensione di uscita inizi a cambiare in seguito alla ricezione di dati digitali è di 20 ms per gli alimentatori collegati direttamente al GPIB.
Tempo di risposta della programmazione dell'uscita: il tempo di salita e discesa (10/90% e 90/10%) della tensione di uscita è inferiore a 15 ms. La variazione della tensione di uscita si assesta entro 1 LSB (0,025% x tensione nominale) del valore finale in meno di 60 ms.
Programmazione verso il basso: un programmatore attivo verso il basso affonda circa il 20% della corrente di uscita nominale.Valori nominali di uscita
Tensione di uscita: da 0 a 120 V.
Corrente di uscita (40 ° C): da 0 a 1,5 A
Corrente massima (50 ° C / 55 ° C): 1,4 A / 1,3 APrecisione di programmazione a 25 ° C ± 5 ° C
Tensione 0,06% + 51 mV
Corrente 0,15% + 1,7 mARipple & Noise (20 Hz – 20 MHz)
Voltaggio rms: 700 µV
Tensione picco-picco: 7 mV
Corrente efficace: 1 mA
Scheda Tecnica -
Power Supply
AGILENT-Hp/Keysight 6675A
Output Ratings
Output voltage: 0 to 120 V
Output current (40°C): 0 to 18 AProgramming Accuracy at 25°C ±5°C
Voltage 0.04% + 120 mV
Current 0.1% + 12 mARipple & Noise from 20 Hz to 20 MHz
Voltage rms: 1.9 mV
Peak-to-Peak: 16 mV
Current rms: 12 mAHp high performance DC power supplies offer speed and accuracy for test optimization. The single output, 2000 W GPIB 6671A-6675A provide fast, low-noise outputs; analog control of output voltage and current; and fan-speed control to minimize acoustic noise.
The Hp 2160W, GPIB, single output 6675A is a highly efficient low-noise supply that maximize test throughput and is designed to offer excellent reliability, low ripple and noise, and extremely accurate built-in measurements of voltage and current.
Datasheet -
Pulse Pattern Generator
AGILENT-Hp/Keysight 81101A
The Keysight 81101A 50 MHz single-channel Pulse Generator is the economy, entry-level instrument of the 81100 family. All timing parameters (repetition rate, delay, width and transitions) are variable.
The instrument comprises a PLL oscillator that enables the repetition rate to be kept within 0.01% accuracy.
Double-pulses and pulse bursts are available. All pulses can be triggered externally when the PLL is turned off. Bursts can also be triggered by the internal PLL if it is not in use as the repetition-rate generator. An external width (pulse recovery) mode is available, too.
The selectable 50/1000 Ohm source resistance allows output amplitudes up to 10 or 20 Vpp respectively into a 50 Ohm load.
Single-channel pulse generator
50 MHz, 10 V from 50 Ohm into 50 Ohm
Triggerable / PLL operation selectable
Pulse / burst modes selectable
Variable transition times
BNC outputs, single-ended
Datasheet -
Power Sensor
AGILENT-Hp/Keysight 8481A
HP AGILENT KEYSIGHT POWER SENSOR 8481A 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM Series, EPM-P Series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
8481A offers extraordinary precision, stability and lower SWR.
• Excellent SWR to reduce mismatch uncertainty
• Accurately calibrated and traceable to the US National Institute of Standards and Technology (NIST).
• Compatible with EPM, EPM-P, and P Series power meters, as well as E1416A VXI and discontinued 70100A and 43X power switches
• Accurate average power measurements over -30 to +20 dBm
• Frequency range from 10 MHz to 18 GHz
• Element sensitive to the power of the thermocouple
• Measurement range: 1 µW to 100 mW (-30 dBm to +20 dBm)
• impedance 50 ohm
• Connector N (m) -
Rf Electronic Calibration Module
AGILENT-Hp/Keysight 85093C
The Keysight 85093C RF electronic calibration (ECal) module makes the calibration of vector network analyzers fast, easy, and accurate. ECal is a precision, single-connection calibration technique for your vector network analyzer. Performing a full two-port calibration takes less than half the time and the number of connections using ECal versus mechanical cal kits. Furthermore, the accuracy of the calibration is comparable between electronic and mechanical methods. Traditional mechanical calibrations require intensive operator interaction, which is prone to errors. With ECal, the operator simply connects the ECal module to the network analyzer and the software controls the rest.
ECal modules are transfer standards capable of transferring the factory calibration accuracy to your network analyzer. The new 85093C RF electronic calibration system is now easily controlled by one of two methods depending on the network analyzer. The Keysight PNA and ENA series of network analyzers controls the module directly through a USB interface.
Datasheet -
Module
AGILENT-HP/Keysight 89605B
RF Input and Calibration Module
The Agilent 89605B is a RF based Input and Calibration Modules for Vector Signal Analyzer (VSA) Systems. It has applications such as LMDS or wideband wireless LAN design, or signal monitoring applications such as satellite or surveillance.
-
AGILENT-Hp/Keysight E1439C
The Keysight 1439C/D is ideal for applications in RF signal acquisition, analysis and high resolution ATE. It has a baseband input and a 70 MHz IF input, both with 36 MHz bandwidth. The single-channel 95 MSa/s digitizer combines exceptional spurious-free dynamic range with alias-protected signal conditioning, center-frequency tunable digital filters, and a large signal capture memory, all in a single-wide C-size VXI module. The E1439D also incorporates a 200 MB/sec FPDP (Front Panel Data Port) capable of carrying full bandwidth data out of the module for analysis or storage.
36 MHz input bandwidth centered at 70 MHz
-90 dBfs spurious-free dynamic range
Anti-alias filter and signal conditioning
18MB RAM FIFO memory (expandable to 1.2 GB)
VXIbus outputs
VXI local bus (E1439D only)
Multi-channel compatible
VXI plug&play compatible
Single-slot, C-size module
Datasheet -
Power Supply
AGILENT-Hp/Keysight E3631A
The triple output, 80 W, GPIB, E3631A provides small, compact size for bench use; low output ripple and noise; built-in measurements and basic programmable features with GPIB and RS232 interface. This clean and reliable supply is designed for general purpose applications; and combines convenient benchtop capabilities with flexible system features in a compact, multi-output package.
Output 1: 0 to 6 V, 0 to 5 A
Output 2: 0 to +25 V, 0 to 1 A
Output 3: 0 to -25 V, 0 to 1 A
Programming Accuracy at 25°C ±5°C
Voltage: 0.05% + 20 mV, 0.05% + 20 mV, 0.1% + 5 mV
+ Current: 0.15% + 4 mA, 0.15% + 4 mA, 0.2% + 10 mA
Normal Mode Voltage: <350 µVrms/ 2 mV p-p, <350 µV rms/2 mV p-p, <350 µV rms/2 mV p-p Normal-mode current: <500 µA rms, <500 µA rms, <2 mA rms Common-mode current: <1.5 µA rms, <1.5 µA rms, <1.5 µA rms Readback Accuracy at 25°C ±5° 1200W, DC System Power Supplies,60V - 50A. Datasheet -
Power Supply
AGILENT-Hp/Keysight E3646A
The Agilent E3646A 60-watt dual-output programmable power supply features built-in GPIB and RS-232 connectivity and SCPI language compatibility making it easy to create flexible power programs. For general-purpose use, this programmable power supply offers the performance of a system power supply at a surprisingly affordable price.
E364X: Basic System Power
The Agilent E3640A – E3649A power supplies fill the gap between manual bench power supplies and high performance system supplies, offering unmatched performance and functionality at a great price. They’re designed for moderate-speed test where automation is important and throughput is not critical. These single- and dual-output, dual range power supplies are ideal for contract manufacturers and OEMs who need to perform basic electronic functional tests on a variety of products quickly and economically.All models support GPIB and RS-232 for quick connectivity. SCPI (Standard Commands for Programmable Instruments) keeps programming fast and simple. Less than 90 ms output settling time keeps throughput high without the need for a down programmer. Up to five store/recall states help minimize programming time while accelerating test. Remote sensing capability ensures output stability with longer leads.
Great Performance, Outstanding Price
With 30 to 100W of output power, the Agilent E364xA-series of programmable dc power supplies provides great performance at a great price. All ten models deliver clean power, dependable regulation, fast transient response and built-in GPIB and RS-232 interfaces. They’re designed to meet the needs of R&D design verification, production testing, QA verifications and other demanding applications with Agilent Technologies’ quality and reliability.Steady Output
With 0.01 percent load and line regulation, Agilent E364xA power supplies keep output steady when power line and load changes occur. They also specify low normal mode voltage noise and low common mode current noise. The low normal mode noise specification assures clean power for precision circuitry applications, and the low common mode current provides isolation from power line current injection. Agilent E364xA power supplies specify less than 90 msec of voltage settling time at any output load condition.Remote Interface
Agilent E364xA power supplies support any PC with a GPIB (IEEE-488) card or RS-232 interface. Every model ships standard with both GPIB and RS-232. Easy-to-use SCPI (Standard Commands for Programmable Instruments) keeps programming fast and simple. The user manual provides information for beginning programmers, yet includes enough detail to help veteran programmers as well.Broad Support
VXIplug&play software drivers are available for Agilent VEE and National Instruments LabView™ and LabWindows™, simplifying integration of the E364xA into your test system. The drivers are supported under Microsoft® Windows 98 ® and NT. ®Front Panel Operation
An easy-to-use rotary knob and self-guiding keypads allow you to quickly and easily set output at the resolution you need. Voltage and current levels can be set to a maximum resolution of 10 mV/1 mA from the front panel. Up to five complete powers supply setups can be stored and recalled from the internal non-volatile memory. The output on/off button sets the output to zero. Dual output models allow two voltages or currents to be displayed simultaneously.
Datasheet -
Power Supply
AGILENT-Hp/Keysight N5748A
Output Ratings
Voltage: 80 V
Current: 9.5 A
Power: 760 WThe single output, 760W N5748A, provides universal AC input, GPIB, LAN, USB, LXI compliance, and analog/resistance control of output voltage and current. It delivers reliable performance and enhanced capabilities in a compact 1U package.
-
Precision DC Power Module
AGILENT-HP/Keysight N6732B
The Keysight N6732B 50 W basic DC power module provides programmable voltage and current, as well as measurement and protection features at a very economical price. Use this module to power your DUT or ATE system resources, such as fixture control.
This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance come standard. Select from more than 20 different DC power modules, ranging in capability from basic to high precision, and in power from 20 – 500 W.
Download BenchVue Basic app for free to control your instruments.
Output RatingsVoltage: 8 V
Current: 6.25 A
Power: 50 WProgramming Accuracy (at 23°C ±5°)
Voltage: 0.1% + 19 mV
Current: 0.15% + 20 mARipple and Noise (20 Hz to 20 MHz)
Voltage rms: 2 mV
Voltage peak-to-peak: 12 mV
Current rms: 4 mA -
Precision DC Power Module
AGILENT-HP/Keysight N6733B
The Keysight N6733B 50 W basic DC power module provides programmable voltage and current, as well as measurement and protection features at a very economical price. Use this module to power the DUT or ATE system resources, such as fixture control.
This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance come standard. Select from more than 20 different DC power modules, ranging in capability from basic to high precision, and in power from 20 – 300 W.
Output ratingsVoltage: 20 V
Current: 2.5 A
Power: 50 WProgramming accuracy (at 23°C ±5°C)
Voltage: 0.1% + 20 mV
Current: 0.15% + 20 mARipple and noise (20 Hz to 20 MHz)
Voltage rms: 3 mV
Voltage peak-to-peak: 14 mV
Current rms: 2 mA -
Audio Analyzer
AGILENT-Hp/Keysight U8903A
DC to 100kHz frequency range
Generator, analyzer, graph and sweep modes
High-quality signals and arbitrary waveforms
S-N ratio, SINAD, IMD, DFD, THD+N ratio, THD+N level, crosstalk and more
GPIB, LAN and USB interfacesWhether listening to mono, stereo or surround, the human ear knows what sounds good. Measuring how good, however, can be a challenge. The Keysight (Agilent/HP) U8903A audio analyzer helps you measure and quantify audio performance in applications such as wireless audio, analog components and ICs, and consumer audio.
Across the audio spectrum and beyond, this scalable, single-unit solution provides versatile measurement functions, diverse test signals and powerful analysis capabilities. Whatever your application, the U8903A can help you make an audible difference in device performance.
-
Frequency Counter
HP – Agilent/ Keysight 53181A
Optimized for RF applications, the single-channel 10 digit/s 53181A measures frequency, period and peak voltage. A digit-blanking function lets you easily eliminate unnecessary digits when you want to read measurements quickly. For higher-frequency measurements, choose an optional second channel that provides measurements up to 1.5, 3, 5, or 12.4 GHz. A self-guided shallow menu makes this counter exceptionally easy to use
RF Frequency Counter, 10 digits/s
One 225 MHz input channel, plus optional second channel up to 12.4 GHz
10 digits/second resolution
GPIB StandardThe Keysight Technologies, Inc. 53131A/132A/181A high-performance counters give you fast, precise frequency measurements at an affordable price. These counters feature an intuitive user interface and one-button access to frequently used functions so you can make accurate measurements quickly and easily. Real-time digital signal processing technology is used to analyze data while simultaneously taking new readings, speeding measurement throughput. The technology, developed for Keysight’s high-end line of modulation domain analyzers, allows the counters to gather more data for each measurement, so you get higher-resolution measurements in a fraction of the time it takes other counters. The 53131A/132A/181A counters offer built-in statistics and math functions so you can scale measurements and simultaneously measure and track average, min/max and standard deviation. Automated limit testing lets you set upper and lower limits for any measurement. An analog display mode lets you see at a glance whether a measurement is within pass/fail limits. The counters flag out-of-limit conditions and can generate an output signal to trigger external devices when a limit is exceeded. For quick access to frequently used tests, a single keystroke recalls up to 20 different stored front-panel set-ups. For computer-controlled systems applications, each counter includes a standard GPIB interface with full SCPI-compatible programmability and a data transfer rate of up to 200 fully formatted measurements per second. The standard RS-232 talk-only interface provides printer support or data transfer to a computer through a terminal-emulation program.
Datasheet -
HP 10240B
The HP 10240B Blocking Capacitor is a probing accessory that provides ac-coupling while maintaining a 50 ohm system. This capacitor is designed for use with the model HP 10020A Resistive Divider Kit, and the Keysight 54006A Resistive Divider Probe Kit, but may be used with any probe that must be terminated in 50 Ω.
* Provides ac-coupling
* Maintains a 50 ohm system
* Capacitance: 0.18 µF
* Maximum voltage: +/-200 Vdc
* Sag: Approximately 10% per µs (1% in 100 ns)
* Connectors: BNC
* Reflection: less than 12% when driven by a 150 ps risetime step in a 50 ohm system
* Capacitance: 0.18 µF
* Maximum voltage: +/-200 Vdc
* Sag: Approximately 10% per µs (1% in 100 ns)
* Connectors: BNC
* Reflection: less than 12% when driven by a 150 ps risetime step in a 50 ohm system
Datasheet -
Oscillator
HP 8350A Sweep Oscillator
The HP 8350A Sweep Oscillator is a solid-state, swept signal source. This unit can be used with network analyzer systems such as the HP 8410B (Network Analyzer), the HP 8755 (Frequency Response Test Set), and others.
Accepts the 86200 (with adapter) and 83500 series of plug-ins for true versatility. Frequency range is dependent upon plug-in used (sold separately). Mainframe features also include the ability to save & recall up to 9 different front-panel settings! This is a very reliable mainframe that will provide years of quality service.* LCD Display
* Remote Programmable via GPIB
* Different Configuration Options with Different RF Plug-Ins
* 27.8 kHz or 1 kHz Square Wave Modulation -
Adapter
HP E5346A HIGH DENSITY PROBE ADAPTER
The HP E5346A Mictor probe provides a convenient and reliable connection to your target through a Mictor connector designed into your target. Route your signals of interest to the location containing the Mictor connector and when you are ready to measure these signals simply plug-in the Mictor probe. These probes can be used with a support shroud in environments where accidental unplugging of the probe is a concern. This probe can be used with any HP/Agilent logic analyzer with a 40-pin cable connector.
-
RF Plug
HP-Agilent/Keysight 83545A
The HP 83545A was designed to be used in the 8350 Mainframe
This unit is a RF Sweep Oscillator Plug-in offers high performance 5.9 to 12.4GHz frequency coverage with exceptionally high output power.
In addition, the 83545A provides slope compensation and complete HP-IB programmability.
The output power is internally leveled to at least 17 dB, with power variations less that 0.6 dB. -
Signal Generator
HP-Agilent/Keysight 83650A
The Agilent 83650A synthesized sweeper is the standard of excellence for applications requiring the high performance and accuracy of a synthesized source and the speed and versatility of a sweep oscillator. Synthesized broadband frequency coverage and precise 1 Hz frequency resolution (Opt 008) are generated by indirect synthesis, enabling the Agilent 83650A to achieve low single-sideband phase noise performance. It delivers excellent harmonic performance with harmonics at least 50 dB below the carrier from 2.0 to 26.5 GHz, and at least 40 dB below the carrier above 26.5 GHz.
Features:
Scan modulation to simulate antenna scan patterns
Accurate fixed and swept frequency offset for two-tone measurement
User flatness correction for leveling at remote points in the test system
General purpose source for use in component test, receiver test and for frequency conversion
Sweep Modes: Step, List, Ramp
Maximum Power: +10 dBm 26.5 GHz
Maximum Power: +2.5 dBm >40 GHz
Power Sweep Range: -20 dBm to maximum power
Phase Noise (50 GHz at 10 KHz): -68 dBc
Max FM Deviation (locked): +/- 8 MHz
Datasheet -
Power Sensor
HP-Agilent/Keysight 8487D
Il sensore di potenza a diodo 8487D misura la potenza media nell'intervallo di frequenza da 50 MHz a 50 GHz e l'intervallo di potenza da -70 a -20 dBm (intervallo dinamico 50 dB).
L'attenuatore Keysight 11708A 30 dB viene fornito con sensori di potenza serie 8480 con il suffisso “D”, per la calibrazione con misuratore di potenza 0 dBm, riferimento 50 MHz.
SWR eccellente per ridurre l'incertezza di mancata corrispondenza
Calibrazione e tracciabilità accurate alla calibrazione del sensore a onde millimetriche del National Institute of Standards and Technology (NIST)
Compatibile con misuratori di potenza EPM (nuovo N1913A / 14A, E4418B / 19B), EPM-P (E4416A / 17A) e serie P (N1911A / 12A), oltre al misuratore di potenza E1416A VXI e fuori produzione 70100A e 43X
Misurazioni di potenza media accurate oltre -70 a -20 dBm
Gamma di frequenza da 50 MHz a 50 GHz
Elemento di rilevamento della potenza del diodo
Datasheet
-
Power Supply
AGILENT-Hp/Keysight 6644A
Output Ratings
Output voltage: 0 to 60 V
Output current (40° C): 0 to 3.5 A
Maximum current (50° C/55° C): 3.2 A/3 AProgramming Accuracy at 25°C ±5°C
Voltage 0.06% + 26 mV
Current 0.15% + 4.1 mARipple & Noise (20 Hz – 20 MHz)
Voltage rms: 500 µV
Voltage peak-to-peak: 5 mV
Current rms: 1.5 mAKeysight high performance DC power supplies offer speed and accuracy for test optimization. The single output, 200 W, GPIB 6641A-6645A provide fast, low-noise outputs; analog control of output voltage and current; fan-speed control to minimize acoustic noise; as well as parallel and series connections of multiple units.
The Keysight 210W, GPIB, single output 6644A is a versatile programmable supply designed to maximize test throughput during design verification or on the production line, and is fully programmable to help reduce test time through a variety of automated capabilities.
Datasheet -
Power Supply
AGILENT-Hp/Keysight 6645A
Questa serie di alimentatori CC regolati lineari da 200 W è progettata per massimizzare la produttività dei DUT attraverso il processo di test di produzione con tempi di programmazione rapidi su e giù.
I preziosi insiemi possono essere distrutti da un guasto minore di un componente che può consentire un flusso di tensione o corrente che fluisce verso il DUT. Le funzioni di protezione rapida, tra cui il piede di porco rapido, la protezione crossover in modalità e la possibilità di collegare i circuiti di protezione di più alimentatori possono aumentare il rendimento di produzione.
La programmazione dell'uscita CC e delle funzioni di protezione può essere effettuata dal pannello frontale o utilizzando i comandi SCPI standard del settore, tramite GPIB. Utilizzando il collegamento seriale, è possibile collegare fino a 16 alimentatori tramite un indirizzo GPIB. L'integrazione del sistema di test può essere ulteriormente semplificata utilizzando i driver VXIplug & play. La tensione e la corrente di uscita possono anche essere controllate con segnali analogici. Ciò è utile per alcuni tipi di ambienti rumorosi e anche per reazioni immediate ai cambiamenti di processo.Tensione flottante CC: i terminali di uscita possono essere fatti galleggiare fino a ± 240 V CC dalla terra del telaio.
Telerilevamento: è possibile far cadere fino a metà della tensione di uscita nominale in ciascun cavo di carico. La caduta del carico comporta la sottrazione della tensione disponibile per il carico.
Tempo di elaborazione del comando: il tempo medio necessario affinché la tensione di uscita inizi a cambiare in seguito alla ricezione di dati digitali è di 20 ms per gli alimentatori collegati direttamente al GPIB.
Tempo di risposta della programmazione dell'uscita: il tempo di salita e discesa (10/90% e 90/10%) della tensione di uscita è inferiore a 15 ms. La variazione della tensione di uscita si assesta entro 1 LSB (0,025% x tensione nominale) del valore finale in meno di 60 ms.
Programmazione verso il basso: un programmatore attivo verso il basso affonda circa il 20% della corrente di uscita nominale.Valori nominali di uscita
Tensione di uscita: da 0 a 120 V.
Corrente di uscita (40 ° C): da 0 a 1,5 A
Corrente massima (50 ° C / 55 ° C): 1,4 A / 1,3 APrecisione di programmazione a 25 ° C ± 5 ° C
Tensione 0,06% + 51 mV
Corrente 0,15% + 1,7 mARipple & Noise (20 Hz – 20 MHz)
Voltaggio rms: 700 µV
Tensione picco-picco: 7 mV
Corrente efficace: 1 mA
Scheda Tecnica -
Power Supply
AGILENT-Hp/Keysight 6675A
Output Ratings
Output voltage: 0 to 120 V
Output current (40°C): 0 to 18 AProgramming Accuracy at 25°C ±5°C
Voltage 0.04% + 120 mV
Current 0.1% + 12 mARipple & Noise from 20 Hz to 20 MHz
Voltage rms: 1.9 mV
Peak-to-Peak: 16 mV
Current rms: 12 mAHp high performance DC power supplies offer speed and accuracy for test optimization. The single output, 2000 W GPIB 6671A-6675A provide fast, low-noise outputs; analog control of output voltage and current; and fan-speed control to minimize acoustic noise.
The Hp 2160W, GPIB, single output 6675A is a highly efficient low-noise supply that maximize test throughput and is designed to offer excellent reliability, low ripple and noise, and extremely accurate built-in measurements of voltage and current.
Datasheet -
Pulse Pattern Generator
AGILENT-Hp/Keysight 81101A
The Keysight 81101A 50 MHz single-channel Pulse Generator is the economy, entry-level instrument of the 81100 family. All timing parameters (repetition rate, delay, width and transitions) are variable.
The instrument comprises a PLL oscillator that enables the repetition rate to be kept within 0.01% accuracy.
Double-pulses and pulse bursts are available. All pulses can be triggered externally when the PLL is turned off. Bursts can also be triggered by the internal PLL if it is not in use as the repetition-rate generator. An external width (pulse recovery) mode is available, too.
The selectable 50/1000 Ohm source resistance allows output amplitudes up to 10 or 20 Vpp respectively into a 50 Ohm load.
Single-channel pulse generator
50 MHz, 10 V from 50 Ohm into 50 Ohm
Triggerable / PLL operation selectable
Pulse / burst modes selectable
Variable transition times
BNC outputs, single-ended
Datasheet -
Power Sensor
AGILENT-Hp/Keysight 8481A
HP AGILENT KEYSIGHT POWER SENSOR 8481A 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM Series, EPM-P Series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
8481A offers extraordinary precision, stability and lower SWR.
• Excellent SWR to reduce mismatch uncertainty
• Accurately calibrated and traceable to the US National Institute of Standards and Technology (NIST).
• Compatible with EPM, EPM-P, and P Series power meters, as well as E1416A VXI and discontinued 70100A and 43X power switches
• Accurate average power measurements over -30 to +20 dBm
• Frequency range from 10 MHz to 18 GHz
• Element sensitive to the power of the thermocouple
• Measurement range: 1 µW to 100 mW (-30 dBm to +20 dBm)
• impedance 50 ohm
• Connector N (m) -
Rf Electronic Calibration Module
AGILENT-Hp/Keysight 85093C
The Keysight 85093C RF electronic calibration (ECal) module makes the calibration of vector network analyzers fast, easy, and accurate. ECal is a precision, single-connection calibration technique for your vector network analyzer. Performing a full two-port calibration takes less than half the time and the number of connections using ECal versus mechanical cal kits. Furthermore, the accuracy of the calibration is comparable between electronic and mechanical methods. Traditional mechanical calibrations require intensive operator interaction, which is prone to errors. With ECal, the operator simply connects the ECal module to the network analyzer and the software controls the rest.
ECal modules are transfer standards capable of transferring the factory calibration accuracy to your network analyzer. The new 85093C RF electronic calibration system is now easily controlled by one of two methods depending on the network analyzer. The Keysight PNA and ENA series of network analyzers controls the module directly through a USB interface.
Datasheet -
Module
AGILENT-HP/Keysight 89605B
RF Input and Calibration Module
The Agilent 89605B is a RF based Input and Calibration Modules for Vector Signal Analyzer (VSA) Systems. It has applications such as LMDS or wideband wireless LAN design, or signal monitoring applications such as satellite or surveillance.
-
AGILENT-Hp/Keysight E1439C
The Keysight 1439C/D is ideal for applications in RF signal acquisition, analysis and high resolution ATE. It has a baseband input and a 70 MHz IF input, both with 36 MHz bandwidth. The single-channel 95 MSa/s digitizer combines exceptional spurious-free dynamic range with alias-protected signal conditioning, center-frequency tunable digital filters, and a large signal capture memory, all in a single-wide C-size VXI module. The E1439D also incorporates a 200 MB/sec FPDP (Front Panel Data Port) capable of carrying full bandwidth data out of the module for analysis or storage.
36 MHz input bandwidth centered at 70 MHz
-90 dBfs spurious-free dynamic range
Anti-alias filter and signal conditioning
18MB RAM FIFO memory (expandable to 1.2 GB)
VXIbus outputs
VXI local bus (E1439D only)
Multi-channel compatible
VXI plug&play compatible
Single-slot, C-size module
Datasheet -
Power Supply
AGILENT-Hp/Keysight E3631A
The triple output, 80 W, GPIB, E3631A provides small, compact size for bench use; low output ripple and noise; built-in measurements and basic programmable features with GPIB and RS232 interface. This clean and reliable supply is designed for general purpose applications; and combines convenient benchtop capabilities with flexible system features in a compact, multi-output package.
Output 1: 0 to 6 V, 0 to 5 A
Output 2: 0 to +25 V, 0 to 1 A
Output 3: 0 to -25 V, 0 to 1 A
Programming Accuracy at 25°C ±5°C
Voltage: 0.05% + 20 mV, 0.05% + 20 mV, 0.1% + 5 mV
+ Current: 0.15% + 4 mA, 0.15% + 4 mA, 0.2% + 10 mA
Normal Mode Voltage: <350 µVrms/ 2 mV p-p, <350 µV rms/2 mV p-p, <350 µV rms/2 mV p-p Normal-mode current: <500 µA rms, <500 µA rms, <2 mA rms Common-mode current: <1.5 µA rms, <1.5 µA rms, <1.5 µA rms Readback Accuracy at 25°C ±5° 1200W, DC System Power Supplies,60V - 50A. Datasheet -
Power Supply
AGILENT-Hp/Keysight E3646A
The Agilent E3646A 60-watt dual-output programmable power supply features built-in GPIB and RS-232 connectivity and SCPI language compatibility making it easy to create flexible power programs. For general-purpose use, this programmable power supply offers the performance of a system power supply at a surprisingly affordable price.
E364X: Basic System Power
The Agilent E3640A – E3649A power supplies fill the gap between manual bench power supplies and high performance system supplies, offering unmatched performance and functionality at a great price. They’re designed for moderate-speed test where automation is important and throughput is not critical. These single- and dual-output, dual range power supplies are ideal for contract manufacturers and OEMs who need to perform basic electronic functional tests on a variety of products quickly and economically.All models support GPIB and RS-232 for quick connectivity. SCPI (Standard Commands for Programmable Instruments) keeps programming fast and simple. Less than 90 ms output settling time keeps throughput high without the need for a down programmer. Up to five store/recall states help minimize programming time while accelerating test. Remote sensing capability ensures output stability with longer leads.
Great Performance, Outstanding Price
With 30 to 100W of output power, the Agilent E364xA-series of programmable dc power supplies provides great performance at a great price. All ten models deliver clean power, dependable regulation, fast transient response and built-in GPIB and RS-232 interfaces. They’re designed to meet the needs of R&D design verification, production testing, QA verifications and other demanding applications with Agilent Technologies’ quality and reliability.Steady Output
With 0.01 percent load and line regulation, Agilent E364xA power supplies keep output steady when power line and load changes occur. They also specify low normal mode voltage noise and low common mode current noise. The low normal mode noise specification assures clean power for precision circuitry applications, and the low common mode current provides isolation from power line current injection. Agilent E364xA power supplies specify less than 90 msec of voltage settling time at any output load condition.Remote Interface
Agilent E364xA power supplies support any PC with a GPIB (IEEE-488) card or RS-232 interface. Every model ships standard with both GPIB and RS-232. Easy-to-use SCPI (Standard Commands for Programmable Instruments) keeps programming fast and simple. The user manual provides information for beginning programmers, yet includes enough detail to help veteran programmers as well.Broad Support
VXIplug&play software drivers are available for Agilent VEE and National Instruments LabView™ and LabWindows™, simplifying integration of the E364xA into your test system. The drivers are supported under Microsoft® Windows 98 ® and NT. ®Front Panel Operation
An easy-to-use rotary knob and self-guiding keypads allow you to quickly and easily set output at the resolution you need. Voltage and current levels can be set to a maximum resolution of 10 mV/1 mA from the front panel. Up to five complete powers supply setups can be stored and recalled from the internal non-volatile memory. The output on/off button sets the output to zero. Dual output models allow two voltages or currents to be displayed simultaneously.
Datasheet -
Power Supply
AGILENT-Hp/Keysight N5748A
Output Ratings
Voltage: 80 V
Current: 9.5 A
Power: 760 WThe single output, 760W N5748A, provides universal AC input, GPIB, LAN, USB, LXI compliance, and analog/resistance control of output voltage and current. It delivers reliable performance and enhanced capabilities in a compact 1U package.
-
Precision DC Power Module
AGILENT-HP/Keysight N6732B
The Keysight N6732B 50 W basic DC power module provides programmable voltage and current, as well as measurement and protection features at a very economical price. Use this module to power your DUT or ATE system resources, such as fixture control.
This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance come standard. Select from more than 20 different DC power modules, ranging in capability from basic to high precision, and in power from 20 – 500 W.
Download BenchVue Basic app for free to control your instruments.
Output RatingsVoltage: 8 V
Current: 6.25 A
Power: 50 WProgramming Accuracy (at 23°C ±5°)
Voltage: 0.1% + 19 mV
Current: 0.15% + 20 mARipple and Noise (20 Hz to 20 MHz)
Voltage rms: 2 mV
Voltage peak-to-peak: 12 mV
Current rms: 4 mA -
Precision DC Power Module
AGILENT-HP/Keysight N6733B
The Keysight N6733B 50 W basic DC power module provides programmable voltage and current, as well as measurement and protection features at a very economical price. Use this module to power the DUT or ATE system resources, such as fixture control.
This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance come standard. Select from more than 20 different DC power modules, ranging in capability from basic to high precision, and in power from 20 – 300 W.
Output ratingsVoltage: 20 V
Current: 2.5 A
Power: 50 WProgramming accuracy (at 23°C ±5°C)
Voltage: 0.1% + 20 mV
Current: 0.15% + 20 mARipple and noise (20 Hz to 20 MHz)
Voltage rms: 3 mV
Voltage peak-to-peak: 14 mV
Current rms: 2 mA -
Audio Analyzer
AGILENT-Hp/Keysight U8903A
DC to 100kHz frequency range
Generator, analyzer, graph and sweep modes
High-quality signals and arbitrary waveforms
S-N ratio, SINAD, IMD, DFD, THD+N ratio, THD+N level, crosstalk and more
GPIB, LAN and USB interfacesWhether listening to mono, stereo or surround, the human ear knows what sounds good. Measuring how good, however, can be a challenge. The Keysight (Agilent/HP) U8903A audio analyzer helps you measure and quantify audio performance in applications such as wireless audio, analog components and ICs, and consumer audio.
Across the audio spectrum and beyond, this scalable, single-unit solution provides versatile measurement functions, diverse test signals and powerful analysis capabilities. Whatever your application, the U8903A can help you make an audible difference in device performance.
-
Frequency Counter
HP – Agilent/ Keysight 53181A
Optimized for RF applications, the single-channel 10 digit/s 53181A measures frequency, period and peak voltage. A digit-blanking function lets you easily eliminate unnecessary digits when you want to read measurements quickly. For higher-frequency measurements, choose an optional second channel that provides measurements up to 1.5, 3, 5, or 12.4 GHz. A self-guided shallow menu makes this counter exceptionally easy to use
RF Frequency Counter, 10 digits/s
One 225 MHz input channel, plus optional second channel up to 12.4 GHz
10 digits/second resolution
GPIB StandardThe Keysight Technologies, Inc. 53131A/132A/181A high-performance counters give you fast, precise frequency measurements at an affordable price. These counters feature an intuitive user interface and one-button access to frequently used functions so you can make accurate measurements quickly and easily. Real-time digital signal processing technology is used to analyze data while simultaneously taking new readings, speeding measurement throughput. The technology, developed for Keysight’s high-end line of modulation domain analyzers, allows the counters to gather more data for each measurement, so you get higher-resolution measurements in a fraction of the time it takes other counters. The 53131A/132A/181A counters offer built-in statistics and math functions so you can scale measurements and simultaneously measure and track average, min/max and standard deviation. Automated limit testing lets you set upper and lower limits for any measurement. An analog display mode lets you see at a glance whether a measurement is within pass/fail limits. The counters flag out-of-limit conditions and can generate an output signal to trigger external devices when a limit is exceeded. For quick access to frequently used tests, a single keystroke recalls up to 20 different stored front-panel set-ups. For computer-controlled systems applications, each counter includes a standard GPIB interface with full SCPI-compatible programmability and a data transfer rate of up to 200 fully formatted measurements per second. The standard RS-232 talk-only interface provides printer support or data transfer to a computer through a terminal-emulation program.
Datasheet -
HP 10240B
The HP 10240B Blocking Capacitor is a probing accessory that provides ac-coupling while maintaining a 50 ohm system. This capacitor is designed for use with the model HP 10020A Resistive Divider Kit, and the Keysight 54006A Resistive Divider Probe Kit, but may be used with any probe that must be terminated in 50 Ω.
* Provides ac-coupling
* Maintains a 50 ohm system
* Capacitance: 0.18 µF
* Maximum voltage: +/-200 Vdc
* Sag: Approximately 10% per µs (1% in 100 ns)
* Connectors: BNC
* Reflection: less than 12% when driven by a 150 ps risetime step in a 50 ohm system
* Capacitance: 0.18 µF
* Maximum voltage: +/-200 Vdc
* Sag: Approximately 10% per µs (1% in 100 ns)
* Connectors: BNC
* Reflection: less than 12% when driven by a 150 ps risetime step in a 50 ohm system
Datasheet -
Oscillator
HP 8350A Sweep Oscillator
The HP 8350A Sweep Oscillator is a solid-state, swept signal source. This unit can be used with network analyzer systems such as the HP 8410B (Network Analyzer), the HP 8755 (Frequency Response Test Set), and others.
Accepts the 86200 (with adapter) and 83500 series of plug-ins for true versatility. Frequency range is dependent upon plug-in used (sold separately). Mainframe features also include the ability to save & recall up to 9 different front-panel settings! This is a very reliable mainframe that will provide years of quality service.* LCD Display
* Remote Programmable via GPIB
* Different Configuration Options with Different RF Plug-Ins
* 27.8 kHz or 1 kHz Square Wave Modulation€0.00 View Product -
Adapter
HP E5346A HIGH DENSITY PROBE ADAPTER
The HP E5346A Mictor probe provides a convenient and reliable connection to your target through a Mictor connector designed into your target. Route your signals of interest to the location containing the Mictor connector and when you are ready to measure these signals simply plug-in the Mictor probe. These probes can be used with a support shroud in environments where accidental unplugging of the probe is a concern. This probe can be used with any HP/Agilent logic analyzer with a 40-pin cable connector.
-
RF Plug
HP-Agilent/Keysight 83545A
The HP 83545A was designed to be used in the 8350 Mainframe
This unit is a RF Sweep Oscillator Plug-in offers high performance 5.9 to 12.4GHz frequency coverage with exceptionally high output power.
In addition, the 83545A provides slope compensation and complete HP-IB programmability.
The output power is internally leveled to at least 17 dB, with power variations less that 0.6 dB. -
Signal Generator
HP-Agilent/Keysight 83650A
The Agilent 83650A synthesized sweeper is the standard of excellence for applications requiring the high performance and accuracy of a synthesized source and the speed and versatility of a sweep oscillator. Synthesized broadband frequency coverage and precise 1 Hz frequency resolution (Opt 008) are generated by indirect synthesis, enabling the Agilent 83650A to achieve low single-sideband phase noise performance. It delivers excellent harmonic performance with harmonics at least 50 dB below the carrier from 2.0 to 26.5 GHz, and at least 40 dB below the carrier above 26.5 GHz.
Features:
Scan modulation to simulate antenna scan patterns
Accurate fixed and swept frequency offset for two-tone measurement
User flatness correction for leveling at remote points in the test system
General purpose source for use in component test, receiver test and for frequency conversion
Sweep Modes: Step, List, Ramp
Maximum Power: +10 dBm 26.5 GHz
Maximum Power: +2.5 dBm >40 GHz
Power Sweep Range: -20 dBm to maximum power
Phase Noise (50 GHz at 10 KHz): -68 dBc
Max FM Deviation (locked): +/- 8 MHz
Datasheet -
Power Sensor
HP-Agilent/Keysight 8487D
Il sensore di potenza a diodo 8487D misura la potenza media nell'intervallo di frequenza da 50 MHz a 50 GHz e l'intervallo di potenza da -70 a -20 dBm (intervallo dinamico 50 dB).
L'attenuatore Keysight 11708A 30 dB viene fornito con sensori di potenza serie 8480 con il suffisso “D”, per la calibrazione con misuratore di potenza 0 dBm, riferimento 50 MHz.
SWR eccellente per ridurre l'incertezza di mancata corrispondenza
Calibrazione e tracciabilità accurate alla calibrazione del sensore a onde millimetriche del National Institute of Standards and Technology (NIST)
Compatibile con misuratori di potenza EPM (nuovo N1913A / 14A, E4418B / 19B), EPM-P (E4416A / 17A) e serie P (N1911A / 12A), oltre al misuratore di potenza E1416A VXI e fuori produzione 70100A e 43X
Misurazioni di potenza media accurate oltre -70 a -20 dBm
Gamma di frequenza da 50 MHz a 50 GHz
Elemento di rilevamento della potenza del diodo
Datasheet
