Low-Profile Modular Power System Mainframe
AGILENT – Hp/ Keysight N6700B
€1,020.00€1,200.00View Product
-
Transmission Analyzers
HP 37721A Digital Transmission Analyzer opt. 001-003
The 37718A communications performance analyzer is a single-box portable multi-rate BER and jitter tester up to 2.5 Gb/s (OC-48/STM-16) for development, qualification and manufacture of SONET, SDH, ATM and POS network equipment, sub-assemblies, line cards and devices.
* ATM and POS test capability to 2.5 Gb/s
* Concatenated payloads at all synchronous rates up to 2.5 Gb/s
* SmartTest facility for fast test setup
* Automatic detection of mixed payload signal structures
* Accurate measurement of protection switching times (ring and linear networks)
* Jitter generation and measurement at all rates (1.5, 2, 8, 34, 45, 140, 52, 155, 622 and 2,488 Mb/s)
* Jitter testing to ITU-T and Telcordia recommendationsSKU: n/a -
Attenuator
HP 11708A 30 dB Attenuator Pad, 50 MHz
The HP 11708A 30 dB attenuator is supplied with 8480 series power sensors with the “D” suffix, for calibration with the power meter 0 dBm, 50 MHz reference.
* Frequency Range: 50 MHz
* Attenuation: 30 dB ± 0.05 dB
* 50 ohm impedance
* SWR: <1.05 at 50 MHzSKU: n/a -
Power Meter
HP438A Dual Sensor Power Meter
The HP 438A power meter is a dual-channel power meter designed specifically for ATE systems. The compact front panel saves critical rack space, while the dual-channel design allows simple and accurate measurements of the ratio and difference of power levels from two separate sensors. This meter is compatible with the 8480 series of power sensors.
GPIB capability is standard on the 438A. For U.S. Air Force Modular Automatic Test Equipment (MATE) system application, Option 700 provides the 438A with the internal capability to be controlled by the MATE Control Interface Intermediate Language (CIIL).
* Two power sensors for multi-port measurement
* Ratio mode for measuring gain compression
* Programmable high and low power limits for unattended power monitoring
* Frequency: 100 kHz to 26.5 GHz
* Power Range: -70 to +44 dBm
* Dynamic Range: 50 dB
* Measurement Modes: A, B, A-B, B-A, A/B, B/ASKU: 1061 -
Microwave Counter/Power Meter
HP 5347A – 20 GHz Microwave Counter/Power Meter
The HP 5347A 20 GHz Microwave Counter/Power Meter offers the convenience of a single instrument that makes frequency and power measurements with accuracy and resolution comparable to stand-alone instruments. As a true power meter, the HP 5347A offers excellent dynamic range, linearity, and accuracy. It uses the same proven power sensors as HP's standalone power meters. The high-performance frequency counter measures frequency from 10 Hz to 20 GHz.
With only five function keys, the HP 5347A is especially easy to use. Its rugged, lightweight package, along with an optional internal battery that provides up to two hours of cordless measurements, makes the HP 5347A ideal for taking portable measurements.
* True power meter performance
* Negligible power meter error
* Outstanding frequency measurements
* Built-in sensor calibration tables save time
* External DC operation for greater measurement flexibility
* Supports three HP power sensorsSKU: n/a -
Power Sensor
HP 84812A Peak Power Sensor, 0.5-18 GHz, -40 dBm to 20 dBm
The HP 84812A peak power sensor is compatible with the obsolete 8990/1A peak power analyzers and the obsolete 8992A digital video power analyzer. This sensor gives you outstanding measurement accuracy in demanding situations and includes automatic temperature sensing and correction.
* Outstanding measurement accuracy
* Automatic temperature sensing and correctionSKU: 941 -
Attenuator
HP 8494G Programmable Step Attenuator, DC to 4 GHz
The 8494G dc to 4 GHz programmable step attenuator offers exceptional repeatability and reliability. Attenuation is provided in 1 dB steps from 0 to 11 dB. Precision gold-plated leaf springs ensure long-life (over 5 million cycles) and very high attenuator repeatability (typically 0.01 dB). To improve measurement accuracy, NIST traceable data (SWR and attenuation) is available as Option UK6. A maximum switching time of 20 ms (including contact settling) speeds automatic testing. Custom step attenuator/switch combinations are possible. The Keysight 11716A/B/C interconnect kits provide quick connection of Keysight 8494/5/6/7 1 dB and 10 dB step attenuators in series for greater dynamic range with 1 dB steps.
* Frequency range: dc to 4 GHz
* Insertion loss at 0 dB: 0.6 dB + 0.09 dB/GHz
* Maximum SWR: 1.5
* Repeatability life: 0.03 dB max 5 million cycles per section, typical
* 5 million cycles per section
* Maximum RF input power: 1 W (average), 100 W (peak)
* Connector type: choice of Type-N female, SMA female, APC-7
* Programming connector: 12-pin Viking, optional 14-pin DIPSKU: n/a -
PEAK POWER SENSOR
HP 8991A Peak Power Meter
The HP 8991A peak power analyzer provides complete and accurate characterization of today's complex pulsed signals. It is capable of performing seven automatic timing measurements (rise time, fall time, pulse width, PRI, PRF, duty cycle, and delay) and five automatic power measurement (peak power, average power, pulse top/base amplitude, and overshoot) with push-button ease. Front-panel operation is intuitive and straightforward. Data entries can be typed in or made with the front panel knob; automatic measurements are made with simple keystroke. The 8990A offers two sensor channels plus two external triggering/oscilloscope channels, allowing the simultaneous measurement of modulating signals and detector power envelopes.
* Amplitude and time markers for measuring power exactly where its needed
* Two oscilloscope channels for measuring time delay between video and microwave pulse
* Versatile triggering enables the capturing of exclusive glitches
* Waveform math functions for measuring scalar pulse parameters
* Dynamic Range: >45 dB
* Minimum Pulse Width: 20 ns
* Rise Time: <5 ns * Sensor and Video Inputs: 1 and 4; 2 and 3SKU: n/a -
Power Supply
HP E3616A 60W Power Supply, 35V, 1.7A
Keysight basic DC power supplies offer essential features for a tight budget.
The single output, 30-60 W, E3610A-E3617A provide small, compact size for bench use; low-noise and excellent regulation; and dual-range outputs (E3610A/11A/12A).
The Keysight 60W, single output E3616A is a reliable and convenient power for benchtop use, and offers solid performance and a variety of basic and enhanced capabilities.Output Ratings (Maximum current is derated 1% per °C between 40° to 55°C)
> Range 1: 0 to 35 V, 0 to 1.7 A
> Range 2: NA
> Power (max): 60 WRipple & Noise from 20 Hz to 20 MHz
> Voltage rms: 200 µV
> Peak-to-Peak: 1 mVLoad & Line Regulation
> 0.01% + 2 mVMeter Resolution
> Voltage: 10 mV (0-20 V), 100 mV (>20 V)
> Current: 1 mASKU: n/a -
Power Supply
HP-Agilent/Keysight E3620A
50W Dual Output Power Supply, Two 25V, 1A
Keysight basic DC power supplies offer essential features for a tight budget.
The multiple output, 35-50 W, E3620A and E3630A provide dual and triple outputs; small, compact size for bench use; low-noise and excellent regulation; and overload indicator to monitor output.
The Keysight 50W, dual output E3620A has two clean, reliable outputs for general purpose application; and is compact, affordable for versatile benchtop testing.Output ratings (Maximum current is derated 3.3% per °C from 40°C to 55°C)
> Output 1: 0 to 25 V, 0 to 1 A
> Output 2: 0 to 25 V, 0 to 1 A
> Power (max): 50 WRipple & noise from 20 Hz to 20 MHz
> Normal Mode Voltage rms: 350 µV
> Peak-to-Peak: 1.5 mVLoad & line regulation
> 0.01% + 2mVMeter resolution
> Voltage: 10 mV (0-20 V), 100 mV, (>20 V)
> Current: 1 mASKU: 1102 -
Cable
HP-Agilent/Keysight 11730A Sensore di potenza / Cavo sorgente rumore SNS (1,5 m / 5 piedi)
The Keysight 11730A/B/C/D/E cables are used with the N8480/8480 and E-series power sensors (except the E9320 family of peak and average sensors). These cables are designed to reduce RFI effects on low power readings with an improved shielding design in the cable itself. Cables may be ordered individually or in pairs in any combination desired for single and dual-channel measurements. The Keysight 11730A/B/C can also be used in conjunction with the SNS series noise sources which are designed to operate with the NFA Series Noise Figure Analyzers
SKU: 336€0.00 View Product -
Power Sensor
HP-Agilent/Keysight 8481A
HP AGILENT KEYSIGHT 8481A POWER SENSOR 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
The 8481A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 10 MHz to 18 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• N (m) connectorSKU: n/a -
Network Analyzer
HP/Agilent-Keysight 8753D
The HP 8753D is a vector network analyzer and it offers even more flexibility and measurement capability than the HP 8752C in the following areas:
* Frequency range from 30 kHz to 3 GHz.
* Built-in S-parameter test set provides complete forward and reverse measurements, allowing you to completely characterize your component with a single connection.
* 50 and 75 ohm solutions.
* Superb accuracy. The most comprehensive calibration available guarantees accurate measurements. TRL**nRMt makes calibration in non-coaxial environments easier and more convenient.
* Mixer testing. Quickly and easily characterize frequency translating devices such as mixers.
* Add swept harmonic measurements. Characterize amplifter parameters – gain, 1 dB compression, match – and 2nd and 3rd harmonic distortion with the same test setup.
* Built-in 3.5 inch floppy disk drive provides convenient storage of instrument states and data.
* Parallel and serial ports provide interfaces to popular printers and plotters. The parallel port can also be used as a general U0 bus, with user-controllable TI’L inputs and outputs. Users can also connect a DIN keyboard to speed up entry of titles, labels, or file names, and for remote hnt panel operation.Two excellent choices, the HP 8752C and HP 8753D continue the tradition of affordable excellence in RF component measurements for the lab and production test areas. The HP 8752C and HP 8753D network analyzers bring superior performance and useful productivity features to simplify and speed your device, component, or network measurements in the 30 kHz to 6 GHz frequency range. A swept synthesized source, sensitive receiver, and crisp color display ensure rapid, accurate, and easy-to-read test results. Since the HP 8752C and HP 8753D are vector network analyzers, they not only provide magnitude and phase information, but also offer up to 1 10 dB dynamic range, make group delay and time domain measurements, and utilize vector accuracy enhancement to minimize measurement uncertainty.
DatasheetSKU: n/a -
Frequency Counter
HP/Agilent-Keysight 53131A
The two-channel 53131A counter offers 10 digits per second of frequency/period resolution and a bandwidth of 225 MHz. Time interval resolution is specified at 500 ps. An optional third channel provides frequency measurements up to 3, 5, or 12.4 GHz. Standard measurements include frequency, period, ratio, time interval, pulse width, rise/fall time, phase angle, duty cycle, totalize, and peak voltage.
Two 225 MHz input channels, plus optional third channel up to 12.4 GHz
10 digits per second, 500 ps time interval resolution
GPIB Standard
option 010 > Optional High Stability Timebase with Oven and Electronic Calibration
option 030 > 100 MHz to 3 GHzThe Keysight Technologies, Inc. 53131A/132A/181A high-performance counters give you fast, precise frequency measurements at an affordable price. These counters feature an intuitive user interface and one-button access to frequently used functions so you can make accurate measurements quickly and easily. Real-time digital signal processing technology is used to analyze data while simultaneously taking new readings, speeding measurement throughput. The technology, developed for Keysight’s high-end line of modulation domain analyzers, allows the counters to gather more data for each measurement, so you get higher-resolution measurements in a fraction of the time it takes other counters. The 53131A/132A/181A counters offer built-in statistics and math functions so you can scale measurements and simultaneously measure and track average, min/max and standard deviation. Automated limit testing lets you set upper and lower limits for any measurement. An analog display mode lets you see at a glance whether a measurement is within pass/fail limits. The counters flag out-of-limit conditions and can generate an output signal to trigger external devices when a limit is exceeded. For quick access to frequently used tests, a single keystroke recalls up to 20 different stored front-panel set-ups. For computer-controlled systems applications, each counter includes a standard GPIB interface with full SCPI-compatible programmability and a data transfer rate of up to 200 fully formatted measurements per second. The standard RS-232 talk-only interface provides printer support or data transfer to a computer through a terminal-emulation program.
DatasheetSKU: n/a -
Low-Profile Modular Power System Mainframe
AGILENT – Hp/ Keysight N6700B
The Keysight N6700B is a 400 W 1U high, 4-slot modular power system mainframe that accepts from 1 to 4 N6700 series DC power modules in any combination. Modules are ordered separately. The N6700B offers GPIB, LAN, and USB, interfaces standard, and LXI compliance. Select from more than 20 different DC power modules, ranging in capability from basic to high precision, and in power from 20 – 300 W.
SKU: n/a€1,020.00€1,200.00View Product -
Frequency Counter
AGILENT – Hp/Keysight 53181A OPT 030 /3 GHZ
Optimized for RF applications, the single-channel 10 digit/s 53181A measures frequency, period and peak voltage. A digit-blanking function lets you easily eliminate unnecessary digits when you want to read measurements quickly. For higher-frequency measurements, choose an optional second channel that provides measurements up to 1.5, 3, 5, or 12.4 GHz. A self-guided shallow menu makes this counter exceptionally easy to use
RF Frequency Counter, 10 digits/s
One 225 MHz input channel, plus optional second channel up to 12.4 GHz
10 digits/second resolution
GPIB StandardThe Keysight Technologies, Inc. 53131A/132A/181A high-performance counters give you fast, precise frequency measurements at an affordable price. These counters feature an intuitive user interface and one-button access to frequently used functions so you can make accurate measurements quickly and easily. Real-time digital signal processing technology is used to analyze data while simultaneously taking new readings, speeding measurement throughput. The technology, developed for Keysight’s high-end line of modulation domain analyzers, allows the counters to gather more data for each measurement, so you get higher-resolution measurements in a fraction of the time it takes other counters. The 53131A/132A/181A counters offer built-in statistics and math functions so you can scale measurements and simultaneously measure and track average, min/max and standard deviation. Automated limit testing lets you set upper and lower limits for any measurement. An analog display mode lets you see at a glance whether a measurement is within pass/fail limits. The counters flag out-of-limit conditions and can generate an output signal to trigger external devices when a limit is exceeded. For quick access to frequently used tests, a single keystroke recalls up to 20 different stored front-panel set-ups. For computer-controlled systems applications, each counter includes a standard GPIB interface with full SCPI-compatible programmability and a data transfer rate of up to 200 fully formatted measurements per second. The standard RS-232 talk-only interface provides printer support or data transfer to a computer through a terminal-emulation program.
DatasheetSKU: n/a -
Power Sensor
AGILENT – Hp/Keysight 8487A
HP AGILENT KEYSIGHT 8487A POWER SENSOR 50 MHz to 50 GHz
The 8487A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters. The 8487A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 50 MHz to 50 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• 2.4 mm(m) connector
Scheda TecnicaSKU: n/a -
Module
AGILENT 34903A – 20 Channel Actuator/GP Switch Module for 34970A/34972A
The Agilent 34903A is a general-purpose switch module for the 34970A/34972A Data Acquisition/Switch Unit. It has 20 independent single-pole, double-throw (SPDT) relays and is used to cycle power to products under test, control indicator and status lights, and to actuate external power relays and solenoids. Combine it with matrix and multiplexer modules to build custom switch systems. Its 300 V, 1 A contacts can handle up to 50 W, enough for many power line switching applications.
* 20 Channel Actuator/GP Switch
* SPDT (Form C) latching relays
* 300 V, 1 A actuation and controlSKU: 1142 -
Module
AGILENT 34907A Multifunction Module for 34970A/34972A
The HP 34907A module for the 34970A/34972A Data Acquisition/Switch Unit allows great flexibility for a variety of sense and control applications. It combines two 8-bit ports of digital input and output, a 100 kHz gated totalizer, and two ±12V analog outputs – all on a single earth-referenced module. The digital inputs and totalizer input may be included in a scan. Alarm limits for the digital and event counter inputs are evaluated continuously, capturing and logging alarm conditions even between scans.
Use the digital outputs with an external power supply to control microwave switches and attenuators, solenoids, power relays, indicators, and more. Use the digital inputs to sense limit switch and digital bus status. There are no complex handshake modes; reads and writes are initiated either from the front panel or the bus.
Count events from devices like photo interrupters, limit switches, and Hall-effect sensors.
It keeps an updated total which can be read via the front panel or programmatically at any time. With 26 bits of resolution, it can count events at full speed for nearly 45 minutes without an overflow.
Use the two electronically calibrated analog outputs to source bias voltages to your device under test, to control your analog programmable power supplies, or use the outputs as setpoints for your control systems. The outputs are programmed directly in volts, either from the front panel or from the bus.
Key Features & Specifications:
– 16 bits of digital input and output
– 100 kHz totalizer input
– Two +/-12V analog outputsSKU: 1145 -
Power Sensor
AGILENT E9323A
AGILENT E9323A E-Series Power Sensor, 50 MHz to 6 GHz
The E9323A diode power sensor has a 5 MHz video bandwidth and is ideal for time-gated peak, average and peak-to-average ratio power measurements on W-CDMA wireless formats such as cdma2000.Key Features & Specifications:
– 5 MHz video bandwidth, ideal for W-CDMA and cdma2000 applications
– Fast measurement speed, up to 1000 corrected readings per second, via the GPIB
– Wide dynamic range
– Calibration factors, linearity, temperature and bandwidth correction stored in EEPROM
– Precision type-N connector as standard
– Operates with the EPM-P (E4416A/ 17A) series and P-Series (N1911A/ 12A) power meters
DatasheetSKU: n/a -
USB/GPIB Interface High-Speed USB 2.0
AGILENT-Hp/Keysight 82357B
The Agilent 82357B USB/GPIB Interface provides a direct connection from a USB port on your laptop or desktop PC to GPIB instruments. There are no switches to set, no PC cards to install, and no external power supplies required. Getting connected has never been easier.
Easy connection – plug-and-play interface
USB 2.0 interface (USB 1.1 compatible) and IEEE-488 interface (connect up to 14 GPIB instruments)
High-speed – transfer over 1.15MB/sec
Parallel Polling (check response of up to 8 devices at one single poll)
Standard industry libraries with Keysight IO Libraries SuiteSKU: n/a -
Function/Arbitrary Waveform Generator
AGILENT-Hp/Keysight 33120A
The 33120A function generator has a proven legacy, 15 MHz bandwidth, arbitrary waveforms & modulation capability. DDS technology provides precise adjustment and frequency stability.
15 MHz sine & square waveforms
Ramp, triangle, noise & DC waveforms
12-bit, 40 MSa/s, 16,000 points arbitrary waveforms
AM (int/ext), FM (int), FSK (internal/external), burst (int/extl)
Linear & logarithmic sweeps and burst operation
IntuiLink software plus GPIB & RS-232 interfaces included
Option 001 provides improved stability & a multiple-unit link
DatasheetSKU: 72 -
Date Acquisition/Switch Unit
AGILENT-Hp/Keysight 34970A
The Agilent 34970A data acquisition / data logger switch consists of a three-slot mainframe with a built-in 6 1/2 digit digital multimeter. Each channel can be configured independently to measure one of 11 different functions without the added cost or hassles of signal-conditioning accessories. Choose from eight optional plug-in modules to create a compact data logger, full-featured data acquisition system or low-cost switching unit. On-module screw-terminal connections eliminate the need for terminal blocks and a unique relay maintenance feature counts every closure on every switch for easy, predictable relay maintenance. Our most popular module 34901A features a built-in thermocouple reference and 20 two-wire channels.
* 3-slot mainframe with built-in GPIB and RS232 interfaces
* 6 1/2-digit (22-bit) internal DMM, scanning up to 250 channels per second
* 8 switch and control plug-in modules to choose from
* Built-in signal conditioning measures thermocouples, RTDs and thermistors, AC/DC volts and current; resistance; frequency and period
* 50k readings of non-volatile memory holds data when power is removed
* Hi/LO alarm limits on each channel, plus 4 TTL alarm outputs
* A BenchVue software license (BV0006B) is now included with your instrument. BenchVue makes it simple to connect, control instruments, and automate test sequencesSKU: 1118 -
Power Supply
AGILENT-Hp/Keysight 6644A
Output Ratings
Output voltage: 0 to 60 V
Output current (40° C): 0 to 3.5 A
Maximum current (50° C/55° C): 3.2 A/3 AProgramming Accuracy at 25°C ±5°C
Voltage 0.06% + 26 mV
Current 0.15% + 4.1 mARipple & Noise (20 Hz – 20 MHz)
Voltage rms: 500 µV
Voltage peak-to-peak: 5 mV
Current rms: 1.5 mAKeysight high performance DC power supplies offer speed and accuracy for test optimization. The single output, 200 W, GPIB 6641A-6645A provide fast, low-noise outputs; analog control of output voltage and current; fan-speed control to minimize acoustic noise; as well as parallel and series connections of multiple units.
The Keysight 210W, GPIB, single output 6644A is a versatile programmable supply designed to maximize test throughput during design verification or on the production line, and is fully programmable to help reduce test time through a variety of automated capabilities.
DatasheetSKU: 1166 -
Power Supply
AGILENT-Hp/Keysight 6645A
Questa serie di alimentatori CC regolati lineari da 200 W è progettata per massimizzare la produttività dei DUT attraverso il processo di test di produzione con tempi di programmazione rapidi su e giù.
I preziosi insiemi possono essere distrutti da un guasto minore di un componente che può consentire un flusso di tensione o corrente che fluisce verso il DUT. Le funzioni di protezione rapida, tra cui il piede di porco rapido, la protezione crossover in modalità e la possibilità di collegare i circuiti di protezione di più alimentatori possono aumentare il rendimento di produzione.
La programmazione dell'uscita CC e delle funzioni di protezione può essere effettuata dal pannello frontale o utilizzando i comandi SCPI standard del settore, tramite GPIB. Utilizzando il collegamento seriale, è possibile collegare fino a 16 alimentatori tramite un indirizzo GPIB. L'integrazione del sistema di test può essere ulteriormente semplificata utilizzando i driver VXIplug & play. La tensione e la corrente di uscita possono anche essere controllate con segnali analogici. Ciò è utile per alcuni tipi di ambienti rumorosi e anche per reazioni immediate ai cambiamenti di processo.Tensione flottante CC: i terminali di uscita possono essere fatti galleggiare fino a ± 240 V CC dalla terra del telaio.
Telerilevamento: è possibile far cadere fino a metà della tensione di uscita nominale in ciascun cavo di carico. La caduta del carico comporta la sottrazione della tensione disponibile per il carico.
Tempo di elaborazione del comando: il tempo medio necessario affinché la tensione di uscita inizi a cambiare in seguito alla ricezione di dati digitali è di 20 ms per gli alimentatori collegati direttamente al GPIB.
Tempo di risposta della programmazione dell'uscita: il tempo di salita e discesa (10/90% e 90/10%) della tensione di uscita è inferiore a 15 ms. La variazione della tensione di uscita si assesta entro 1 LSB (0,025% x tensione nominale) del valore finale in meno di 60 ms.
Programmazione verso il basso: un programmatore attivo verso il basso affonda circa il 20% della corrente di uscita nominale.Valori nominali di uscita
Tensione di uscita: da 0 a 120 V.
Corrente di uscita (40 ° C): da 0 a 1,5 A
Corrente massima (50 ° C / 55 ° C): 1,4 A / 1,3 APrecisione di programmazione a 25 ° C ± 5 ° C
Tensione 0,06% + 51 mV
Corrente 0,15% + 1,7 mARipple & Noise (20 Hz – 20 MHz)
Voltaggio rms: 700 µV
Tensione picco-picco: 7 mV
Corrente efficace: 1 mA
Scheda TecnicaSKU: n/a -
Power Supply
AGILENT-Hp/Keysight 6675A
Output Ratings
Output voltage: 0 to 120 V
Output current (40°C): 0 to 18 AProgramming Accuracy at 25°C ±5°C
Voltage 0.04% + 120 mV
Current 0.1% + 12 mARipple & Noise from 20 Hz to 20 MHz
Voltage rms: 1.9 mV
Peak-to-Peak: 16 mV
Current rms: 12 mAHp high performance DC power supplies offer speed and accuracy for test optimization. The single output, 2000 W GPIB 6671A-6675A provide fast, low-noise outputs; analog control of output voltage and current; and fan-speed control to minimize acoustic noise.
The Hp 2160W, GPIB, single output 6675A is a highly efficient low-noise supply that maximize test throughput and is designed to offer excellent reliability, low ripple and noise, and extremely accurate built-in measurements of voltage and current.
DatasheetSKU: n/a -
Power Sensor
AGILENT-Hp/Keysight 8481A
HP AGILENT KEYSIGHT 8481A POWER SENSOR 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
The 8481A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 10 MHz to 18 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• N (m) connectorSKU: n/a
-
Transmission Analyzers
HP 37721A Digital Transmission Analyzer opt. 001-003
The 37718A communications performance analyzer is a single-box portable multi-rate BER and jitter tester up to 2.5 Gb/s (OC-48/STM-16) for development, qualification and manufacture of SONET, SDH, ATM and POS network equipment, sub-assemblies, line cards and devices.
* ATM and POS test capability to 2.5 Gb/s
* Concatenated payloads at all synchronous rates up to 2.5 Gb/s
* SmartTest facility for fast test setup
* Automatic detection of mixed payload signal structures
* Accurate measurement of protection switching times (ring and linear networks)
* Jitter generation and measurement at all rates (1.5, 2, 8, 34, 45, 140, 52, 155, 622 and 2,488 Mb/s)
* Jitter testing to ITU-T and Telcordia recommendations -
Attenuator
HP 11708A 30 dB Attenuator Pad, 50 MHz
The HP 11708A 30 dB attenuator is supplied with 8480 series power sensors with the “D” suffix, for calibration with the power meter 0 dBm, 50 MHz reference.
* Frequency Range: 50 MHz
* Attenuation: 30 dB ± 0.05 dB
* 50 ohm impedance
* SWR: <1.05 at 50 MHz -
Power Meter
HP438A Dual Sensor Power Meter
The HP 438A power meter is a dual-channel power meter designed specifically for ATE systems. The compact front panel saves critical rack space, while the dual-channel design allows simple and accurate measurements of the ratio and difference of power levels from two separate sensors. This meter is compatible with the 8480 series of power sensors.
GPIB capability is standard on the 438A. For U.S. Air Force Modular Automatic Test Equipment (MATE) system application, Option 700 provides the 438A with the internal capability to be controlled by the MATE Control Interface Intermediate Language (CIIL).
* Two power sensors for multi-port measurement
* Ratio mode for measuring gain compression
* Programmable high and low power limits for unattended power monitoring
* Frequency: 100 kHz to 26.5 GHz
* Power Range: -70 to +44 dBm
* Dynamic Range: 50 dB
* Measurement Modes: A, B, A-B, B-A, A/B, B/A -
Microwave Counter/Power Meter
HP 5347A – 20 GHz Microwave Counter/Power Meter
The HP 5347A 20 GHz Microwave Counter/Power Meter offers the convenience of a single instrument that makes frequency and power measurements with accuracy and resolution comparable to stand-alone instruments. As a true power meter, the HP 5347A offers excellent dynamic range, linearity, and accuracy. It uses the same proven power sensors as HP's standalone power meters. The high-performance frequency counter measures frequency from 10 Hz to 20 GHz.
With only five function keys, the HP 5347A is especially easy to use. Its rugged, lightweight package, along with an optional internal battery that provides up to two hours of cordless measurements, makes the HP 5347A ideal for taking portable measurements.
* True power meter performance
* Negligible power meter error
* Outstanding frequency measurements
* Built-in sensor calibration tables save time
* External DC operation for greater measurement flexibility
* Supports three HP power sensors -
Power Sensor
HP 84812A Peak Power Sensor, 0.5-18 GHz, -40 dBm to 20 dBm
The HP 84812A peak power sensor is compatible with the obsolete 8990/1A peak power analyzers and the obsolete 8992A digital video power analyzer. This sensor gives you outstanding measurement accuracy in demanding situations and includes automatic temperature sensing and correction.
* Outstanding measurement accuracy
* Automatic temperature sensing and correction -
Attenuator
HP 8494G Programmable Step Attenuator, DC to 4 GHz
The 8494G dc to 4 GHz programmable step attenuator offers exceptional repeatability and reliability. Attenuation is provided in 1 dB steps from 0 to 11 dB. Precision gold-plated leaf springs ensure long-life (over 5 million cycles) and very high attenuator repeatability (typically 0.01 dB). To improve measurement accuracy, NIST traceable data (SWR and attenuation) is available as Option UK6. A maximum switching time of 20 ms (including contact settling) speeds automatic testing. Custom step attenuator/switch combinations are possible. The Keysight 11716A/B/C interconnect kits provide quick connection of Keysight 8494/5/6/7 1 dB and 10 dB step attenuators in series for greater dynamic range with 1 dB steps.
* Frequency range: dc to 4 GHz
* Insertion loss at 0 dB: 0.6 dB + 0.09 dB/GHz
* Maximum SWR: 1.5
* Repeatability life: 0.03 dB max 5 million cycles per section, typical
* 5 million cycles per section
* Maximum RF input power: 1 W (average), 100 W (peak)
* Connector type: choice of Type-N female, SMA female, APC-7
* Programming connector: 12-pin Viking, optional 14-pin DIP -
PEAK POWER SENSOR
HP 8991A Peak Power Meter
The HP 8991A peak power analyzer provides complete and accurate characterization of today's complex pulsed signals. It is capable of performing seven automatic timing measurements (rise time, fall time, pulse width, PRI, PRF, duty cycle, and delay) and five automatic power measurement (peak power, average power, pulse top/base amplitude, and overshoot) with push-button ease. Front-panel operation is intuitive and straightforward. Data entries can be typed in or made with the front panel knob; automatic measurements are made with simple keystroke. The 8990A offers two sensor channels plus two external triggering/oscilloscope channels, allowing the simultaneous measurement of modulating signals and detector power envelopes.
* Amplitude and time markers for measuring power exactly where its needed
* Two oscilloscope channels for measuring time delay between video and microwave pulse
* Versatile triggering enables the capturing of exclusive glitches
* Waveform math functions for measuring scalar pulse parameters
* Dynamic Range: >45 dB
* Minimum Pulse Width: 20 ns
* Rise Time: <5 ns * Sensor and Video Inputs: 1 and 4; 2 and 3 -
Power Supply
HP E3616A 60W Power Supply, 35V, 1.7A
Keysight basic DC power supplies offer essential features for a tight budget.
The single output, 30-60 W, E3610A-E3617A provide small, compact size for bench use; low-noise and excellent regulation; and dual-range outputs (E3610A/11A/12A).
The Keysight 60W, single output E3616A is a reliable and convenient power for benchtop use, and offers solid performance and a variety of basic and enhanced capabilities.Output Ratings (Maximum current is derated 1% per °C between 40° to 55°C)
> Range 1: 0 to 35 V, 0 to 1.7 A
> Range 2: NA
> Power (max): 60 WRipple & Noise from 20 Hz to 20 MHz
> Voltage rms: 200 µV
> Peak-to-Peak: 1 mVLoad & Line Regulation
> 0.01% + 2 mVMeter Resolution
> Voltage: 10 mV (0-20 V), 100 mV (>20 V)
> Current: 1 mA -
Power Supply
HP-Agilent/Keysight E3620A
50W Dual Output Power Supply, Two 25V, 1A
Keysight basic DC power supplies offer essential features for a tight budget.
The multiple output, 35-50 W, E3620A and E3630A provide dual and triple outputs; small, compact size for bench use; low-noise and excellent regulation; and overload indicator to monitor output.
The Keysight 50W, dual output E3620A has two clean, reliable outputs for general purpose application; and is compact, affordable for versatile benchtop testing.Output ratings (Maximum current is derated 3.3% per °C from 40°C to 55°C)
> Output 1: 0 to 25 V, 0 to 1 A
> Output 2: 0 to 25 V, 0 to 1 A
> Power (max): 50 WRipple & noise from 20 Hz to 20 MHz
> Normal Mode Voltage rms: 350 µV
> Peak-to-Peak: 1.5 mVLoad & line regulation
> 0.01% + 2mVMeter resolution
> Voltage: 10 mV (0-20 V), 100 mV, (>20 V)
> Current: 1 mA -
Cable
HP-Agilent/Keysight 11730A Sensore di potenza / Cavo sorgente rumore SNS (1,5 m / 5 piedi)
The Keysight 11730A/B/C/D/E cables are used with the N8480/8480 and E-series power sensors (except the E9320 family of peak and average sensors). These cables are designed to reduce RFI effects on low power readings with an improved shielding design in the cable itself. Cables may be ordered individually or in pairs in any combination desired for single and dual-channel measurements. The Keysight 11730A/B/C can also be used in conjunction with the SNS series noise sources which are designed to operate with the NFA Series Noise Figure Analyzers
-
Power Sensor
HP-Agilent/Keysight 8481A
HP AGILENT KEYSIGHT 8481A POWER SENSOR 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
The 8481A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 10 MHz to 18 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• N (m) connector -
Network Analyzer
HP/Agilent-Keysight 8753D
The HP 8753D is a vector network analyzer and it offers even more flexibility and measurement capability than the HP 8752C in the following areas:
* Frequency range from 30 kHz to 3 GHz.
* Built-in S-parameter test set provides complete forward and reverse measurements, allowing you to completely characterize your component with a single connection.
* 50 and 75 ohm solutions.
* Superb accuracy. The most comprehensive calibration available guarantees accurate measurements. TRL**nRMt makes calibration in non-coaxial environments easier and more convenient.
* Mixer testing. Quickly and easily characterize frequency translating devices such as mixers.
* Add swept harmonic measurements. Characterize amplifter parameters – gain, 1 dB compression, match – and 2nd and 3rd harmonic distortion with the same test setup.
* Built-in 3.5 inch floppy disk drive provides convenient storage of instrument states and data.
* Parallel and serial ports provide interfaces to popular printers and plotters. The parallel port can also be used as a general U0 bus, with user-controllable TI’L inputs and outputs. Users can also connect a DIN keyboard to speed up entry of titles, labels, or file names, and for remote hnt panel operation.Two excellent choices, the HP 8752C and HP 8753D continue the tradition of affordable excellence in RF component measurements for the lab and production test areas. The HP 8752C and HP 8753D network analyzers bring superior performance and useful productivity features to simplify and speed your device, component, or network measurements in the 30 kHz to 6 GHz frequency range. A swept synthesized source, sensitive receiver, and crisp color display ensure rapid, accurate, and easy-to-read test results. Since the HP 8752C and HP 8753D are vector network analyzers, they not only provide magnitude and phase information, but also offer up to 1 10 dB dynamic range, make group delay and time domain measurements, and utilize vector accuracy enhancement to minimize measurement uncertainty.
Datasheet -
Frequency Counter
HP/Agilent-Keysight 53131A
The two-channel 53131A counter offers 10 digits per second of frequency/period resolution and a bandwidth of 225 MHz. Time interval resolution is specified at 500 ps. An optional third channel provides frequency measurements up to 3, 5, or 12.4 GHz. Standard measurements include frequency, period, ratio, time interval, pulse width, rise/fall time, phase angle, duty cycle, totalize, and peak voltage.
Two 225 MHz input channels, plus optional third channel up to 12.4 GHz
10 digits per second, 500 ps time interval resolution
GPIB Standard
option 010 > Optional High Stability Timebase with Oven and Electronic Calibration
option 030 > 100 MHz to 3 GHzThe Keysight Technologies, Inc. 53131A/132A/181A high-performance counters give you fast, precise frequency measurements at an affordable price. These counters feature an intuitive user interface and one-button access to frequently used functions so you can make accurate measurements quickly and easily. Real-time digital signal processing technology is used to analyze data while simultaneously taking new readings, speeding measurement throughput. The technology, developed for Keysight’s high-end line of modulation domain analyzers, allows the counters to gather more data for each measurement, so you get higher-resolution measurements in a fraction of the time it takes other counters. The 53131A/132A/181A counters offer built-in statistics and math functions so you can scale measurements and simultaneously measure and track average, min/max and standard deviation. Automated limit testing lets you set upper and lower limits for any measurement. An analog display mode lets you see at a glance whether a measurement is within pass/fail limits. The counters flag out-of-limit conditions and can generate an output signal to trigger external devices when a limit is exceeded. For quick access to frequently used tests, a single keystroke recalls up to 20 different stored front-panel set-ups. For computer-controlled systems applications, each counter includes a standard GPIB interface with full SCPI-compatible programmability and a data transfer rate of up to 200 fully formatted measurements per second. The standard RS-232 talk-only interface provides printer support or data transfer to a computer through a terminal-emulation program.
Datasheet -
Low-Profile Modular Power System Mainframe
AGILENT – Hp/ Keysight N6700B
The Keysight N6700B is a 400 W 1U high, 4-slot modular power system mainframe that accepts from 1 to 4 N6700 series DC power modules in any combination. Modules are ordered separately. The N6700B offers GPIB, LAN, and USB, interfaces standard, and LXI compliance. Select from more than 20 different DC power modules, ranging in capability from basic to high precision, and in power from 20 – 300 W.
-
Frequency Counter
AGILENT – Hp/Keysight 53181A OPT 030 /3 GHZ
Optimized for RF applications, the single-channel 10 digit/s 53181A measures frequency, period and peak voltage. A digit-blanking function lets you easily eliminate unnecessary digits when you want to read measurements quickly. For higher-frequency measurements, choose an optional second channel that provides measurements up to 1.5, 3, 5, or 12.4 GHz. A self-guided shallow menu makes this counter exceptionally easy to use
RF Frequency Counter, 10 digits/s
One 225 MHz input channel, plus optional second channel up to 12.4 GHz
10 digits/second resolution
GPIB StandardThe Keysight Technologies, Inc. 53131A/132A/181A high-performance counters give you fast, precise frequency measurements at an affordable price. These counters feature an intuitive user interface and one-button access to frequently used functions so you can make accurate measurements quickly and easily. Real-time digital signal processing technology is used to analyze data while simultaneously taking new readings, speeding measurement throughput. The technology, developed for Keysight’s high-end line of modulation domain analyzers, allows the counters to gather more data for each measurement, so you get higher-resolution measurements in a fraction of the time it takes other counters. The 53131A/132A/181A counters offer built-in statistics and math functions so you can scale measurements and simultaneously measure and track average, min/max and standard deviation. Automated limit testing lets you set upper and lower limits for any measurement. An analog display mode lets you see at a glance whether a measurement is within pass/fail limits. The counters flag out-of-limit conditions and can generate an output signal to trigger external devices when a limit is exceeded. For quick access to frequently used tests, a single keystroke recalls up to 20 different stored front-panel set-ups. For computer-controlled systems applications, each counter includes a standard GPIB interface with full SCPI-compatible programmability and a data transfer rate of up to 200 fully formatted measurements per second. The standard RS-232 talk-only interface provides printer support or data transfer to a computer through a terminal-emulation program.
Datasheet -
Power Sensor
AGILENT – Hp/Keysight 8487A
HP AGILENT KEYSIGHT 8487A POWER SENSOR 50 MHz to 50 GHz
The 8487A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters. The 8487A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 50 MHz to 50 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• 2.4 mm(m) connector
Scheda Tecnica -
Module
AGILENT 34903A – 20 Channel Actuator/GP Switch Module for 34970A/34972A
The Agilent 34903A is a general-purpose switch module for the 34970A/34972A Data Acquisition/Switch Unit. It has 20 independent single-pole, double-throw (SPDT) relays and is used to cycle power to products under test, control indicator and status lights, and to actuate external power relays and solenoids. Combine it with matrix and multiplexer modules to build custom switch systems. Its 300 V, 1 A contacts can handle up to 50 W, enough for many power line switching applications.
* 20 Channel Actuator/GP Switch
* SPDT (Form C) latching relays
* 300 V, 1 A actuation and control -
Module
AGILENT 34907A Multifunction Module for 34970A/34972A
The HP 34907A module for the 34970A/34972A Data Acquisition/Switch Unit allows great flexibility for a variety of sense and control applications. It combines two 8-bit ports of digital input and output, a 100 kHz gated totalizer, and two ±12V analog outputs – all on a single earth-referenced module. The digital inputs and totalizer input may be included in a scan. Alarm limits for the digital and event counter inputs are evaluated continuously, capturing and logging alarm conditions even between scans.
Use the digital outputs with an external power supply to control microwave switches and attenuators, solenoids, power relays, indicators, and more. Use the digital inputs to sense limit switch and digital bus status. There are no complex handshake modes; reads and writes are initiated either from the front panel or the bus.
Count events from devices like photo interrupters, limit switches, and Hall-effect sensors.
It keeps an updated total which can be read via the front panel or programmatically at any time. With 26 bits of resolution, it can count events at full speed for nearly 45 minutes without an overflow.
Use the two electronically calibrated analog outputs to source bias voltages to your device under test, to control your analog programmable power supplies, or use the outputs as setpoints for your control systems. The outputs are programmed directly in volts, either from the front panel or from the bus.
Key Features & Specifications:
– 16 bits of digital input and output
– 100 kHz totalizer input
– Two +/-12V analog outputs -
Power Sensor
AGILENT E9323A
AGILENT E9323A E-Series Power Sensor, 50 MHz to 6 GHz
The E9323A diode power sensor has a 5 MHz video bandwidth and is ideal for time-gated peak, average and peak-to-average ratio power measurements on W-CDMA wireless formats such as cdma2000.Key Features & Specifications:
– 5 MHz video bandwidth, ideal for W-CDMA and cdma2000 applications
– Fast measurement speed, up to 1000 corrected readings per second, via the GPIB
– Wide dynamic range
– Calibration factors, linearity, temperature and bandwidth correction stored in EEPROM
– Precision type-N connector as standard
– Operates with the EPM-P (E4416A/ 17A) series and P-Series (N1911A/ 12A) power meters
Datasheet -
USB/GPIB Interface High-Speed USB 2.0
AGILENT-Hp/Keysight 82357B
The Agilent 82357B USB/GPIB Interface provides a direct connection from a USB port on your laptop or desktop PC to GPIB instruments. There are no switches to set, no PC cards to install, and no external power supplies required. Getting connected has never been easier.
Easy connection – plug-and-play interface
USB 2.0 interface (USB 1.1 compatible) and IEEE-488 interface (connect up to 14 GPIB instruments)
High-speed – transfer over 1.15MB/sec
Parallel Polling (check response of up to 8 devices at one single poll)
Standard industry libraries with Keysight IO Libraries Suite -
Function/Arbitrary Waveform Generator
AGILENT-Hp/Keysight 33120A
The 33120A function generator has a proven legacy, 15 MHz bandwidth, arbitrary waveforms & modulation capability. DDS technology provides precise adjustment and frequency stability.
15 MHz sine & square waveforms
Ramp, triangle, noise & DC waveforms
12-bit, 40 MSa/s, 16,000 points arbitrary waveforms
AM (int/ext), FM (int), FSK (internal/external), burst (int/extl)
Linear & logarithmic sweeps and burst operation
IntuiLink software plus GPIB & RS-232 interfaces included
Option 001 provides improved stability & a multiple-unit link
Datasheet -
Date Acquisition/Switch Unit
AGILENT-Hp/Keysight 34970A
The Agilent 34970A data acquisition / data logger switch consists of a three-slot mainframe with a built-in 6 1/2 digit digital multimeter. Each channel can be configured independently to measure one of 11 different functions without the added cost or hassles of signal-conditioning accessories. Choose from eight optional plug-in modules to create a compact data logger, full-featured data acquisition system or low-cost switching unit. On-module screw-terminal connections eliminate the need for terminal blocks and a unique relay maintenance feature counts every closure on every switch for easy, predictable relay maintenance. Our most popular module 34901A features a built-in thermocouple reference and 20 two-wire channels.
* 3-slot mainframe with built-in GPIB and RS232 interfaces
* 6 1/2-digit (22-bit) internal DMM, scanning up to 250 channels per second
* 8 switch and control plug-in modules to choose from
* Built-in signal conditioning measures thermocouples, RTDs and thermistors, AC/DC volts and current; resistance; frequency and period
* 50k readings of non-volatile memory holds data when power is removed
* Hi/LO alarm limits on each channel, plus 4 TTL alarm outputs
* A BenchVue software license (BV0006B) is now included with your instrument. BenchVue makes it simple to connect, control instruments, and automate test sequences -
Power Supply
AGILENT-Hp/Keysight 6644A
Output Ratings
Output voltage: 0 to 60 V
Output current (40° C): 0 to 3.5 A
Maximum current (50° C/55° C): 3.2 A/3 AProgramming Accuracy at 25°C ±5°C
Voltage 0.06% + 26 mV
Current 0.15% + 4.1 mARipple & Noise (20 Hz – 20 MHz)
Voltage rms: 500 µV
Voltage peak-to-peak: 5 mV
Current rms: 1.5 mAKeysight high performance DC power supplies offer speed and accuracy for test optimization. The single output, 200 W, GPIB 6641A-6645A provide fast, low-noise outputs; analog control of output voltage and current; fan-speed control to minimize acoustic noise; as well as parallel and series connections of multiple units.
The Keysight 210W, GPIB, single output 6644A is a versatile programmable supply designed to maximize test throughput during design verification or on the production line, and is fully programmable to help reduce test time through a variety of automated capabilities.
Datasheet -
Power Supply
AGILENT-Hp/Keysight 6645A
Questa serie di alimentatori CC regolati lineari da 200 W è progettata per massimizzare la produttività dei DUT attraverso il processo di test di produzione con tempi di programmazione rapidi su e giù.
I preziosi insiemi possono essere distrutti da un guasto minore di un componente che può consentire un flusso di tensione o corrente che fluisce verso il DUT. Le funzioni di protezione rapida, tra cui il piede di porco rapido, la protezione crossover in modalità e la possibilità di collegare i circuiti di protezione di più alimentatori possono aumentare il rendimento di produzione.
La programmazione dell'uscita CC e delle funzioni di protezione può essere effettuata dal pannello frontale o utilizzando i comandi SCPI standard del settore, tramite GPIB. Utilizzando il collegamento seriale, è possibile collegare fino a 16 alimentatori tramite un indirizzo GPIB. L'integrazione del sistema di test può essere ulteriormente semplificata utilizzando i driver VXIplug & play. La tensione e la corrente di uscita possono anche essere controllate con segnali analogici. Ciò è utile per alcuni tipi di ambienti rumorosi e anche per reazioni immediate ai cambiamenti di processo.Tensione flottante CC: i terminali di uscita possono essere fatti galleggiare fino a ± 240 V CC dalla terra del telaio.
Telerilevamento: è possibile far cadere fino a metà della tensione di uscita nominale in ciascun cavo di carico. La caduta del carico comporta la sottrazione della tensione disponibile per il carico.
Tempo di elaborazione del comando: il tempo medio necessario affinché la tensione di uscita inizi a cambiare in seguito alla ricezione di dati digitali è di 20 ms per gli alimentatori collegati direttamente al GPIB.
Tempo di risposta della programmazione dell'uscita: il tempo di salita e discesa (10/90% e 90/10%) della tensione di uscita è inferiore a 15 ms. La variazione della tensione di uscita si assesta entro 1 LSB (0,025% x tensione nominale) del valore finale in meno di 60 ms.
Programmazione verso il basso: un programmatore attivo verso il basso affonda circa il 20% della corrente di uscita nominale.Valori nominali di uscita
Tensione di uscita: da 0 a 120 V.
Corrente di uscita (40 ° C): da 0 a 1,5 A
Corrente massima (50 ° C / 55 ° C): 1,4 A / 1,3 APrecisione di programmazione a 25 ° C ± 5 ° C
Tensione 0,06% + 51 mV
Corrente 0,15% + 1,7 mARipple & Noise (20 Hz – 20 MHz)
Voltaggio rms: 700 µV
Tensione picco-picco: 7 mV
Corrente efficace: 1 mA
Scheda Tecnica -
Power Supply
AGILENT-Hp/Keysight 6675A
Output Ratings
Output voltage: 0 to 120 V
Output current (40°C): 0 to 18 AProgramming Accuracy at 25°C ±5°C
Voltage 0.04% + 120 mV
Current 0.1% + 12 mARipple & Noise from 20 Hz to 20 MHz
Voltage rms: 1.9 mV
Peak-to-Peak: 16 mV
Current rms: 12 mAHp high performance DC power supplies offer speed and accuracy for test optimization. The single output, 2000 W GPIB 6671A-6675A provide fast, low-noise outputs; analog control of output voltage and current; and fan-speed control to minimize acoustic noise.
The Hp 2160W, GPIB, single output 6675A is a highly efficient low-noise supply that maximize test throughput and is designed to offer excellent reliability, low ripple and noise, and extremely accurate built-in measurements of voltage and current.
Datasheet -
Power Sensor
AGILENT-Hp/Keysight 8481A
HP AGILENT KEYSIGHT 8481A POWER SENSOR 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
The 8481A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 10 MHz to 18 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• N (m) connector
-
Transmission Analyzers
HP 37721A Digital Transmission Analyzer opt. 001-003
The 37718A communications performance analyzer is a single-box portable multi-rate BER and jitter tester up to 2.5 Gb/s (OC-48/STM-16) for development, qualification and manufacture of SONET, SDH, ATM and POS network equipment, sub-assemblies, line cards and devices.
* ATM and POS test capability to 2.5 Gb/s
* Concatenated payloads at all synchronous rates up to 2.5 Gb/s
* SmartTest facility for fast test setup
* Automatic detection of mixed payload signal structures
* Accurate measurement of protection switching times (ring and linear networks)
* Jitter generation and measurement at all rates (1.5, 2, 8, 34, 45, 140, 52, 155, 622 and 2,488 Mb/s)
* Jitter testing to ITU-T and Telcordia recommendations -
Attenuator
HP 11708A 30 dB Attenuator Pad, 50 MHz
The HP 11708A 30 dB attenuator is supplied with 8480 series power sensors with the “D” suffix, for calibration with the power meter 0 dBm, 50 MHz reference.
* Frequency Range: 50 MHz
* Attenuation: 30 dB ± 0.05 dB
* 50 ohm impedance
* SWR: <1.05 at 50 MHz -
Power Meter
HP438A Dual Sensor Power Meter
The HP 438A power meter is a dual-channel power meter designed specifically for ATE systems. The compact front panel saves critical rack space, while the dual-channel design allows simple and accurate measurements of the ratio and difference of power levels from two separate sensors. This meter is compatible with the 8480 series of power sensors.
GPIB capability is standard on the 438A. For U.S. Air Force Modular Automatic Test Equipment (MATE) system application, Option 700 provides the 438A with the internal capability to be controlled by the MATE Control Interface Intermediate Language (CIIL).
* Two power sensors for multi-port measurement
* Ratio mode for measuring gain compression
* Programmable high and low power limits for unattended power monitoring
* Frequency: 100 kHz to 26.5 GHz
* Power Range: -70 to +44 dBm
* Dynamic Range: 50 dB
* Measurement Modes: A, B, A-B, B-A, A/B, B/A -
Microwave Counter/Power Meter
HP 5347A – 20 GHz Microwave Counter/Power Meter
The HP 5347A 20 GHz Microwave Counter/Power Meter offers the convenience of a single instrument that makes frequency and power measurements with accuracy and resolution comparable to stand-alone instruments. As a true power meter, the HP 5347A offers excellent dynamic range, linearity, and accuracy. It uses the same proven power sensors as HP's standalone power meters. The high-performance frequency counter measures frequency from 10 Hz to 20 GHz.
With only five function keys, the HP 5347A is especially easy to use. Its rugged, lightweight package, along with an optional internal battery that provides up to two hours of cordless measurements, makes the HP 5347A ideal for taking portable measurements.
* True power meter performance
* Negligible power meter error
* Outstanding frequency measurements
* Built-in sensor calibration tables save time
* External DC operation for greater measurement flexibility
* Supports three HP power sensors -
Power Sensor
HP 84812A Peak Power Sensor, 0.5-18 GHz, -40 dBm to 20 dBm
The HP 84812A peak power sensor is compatible with the obsolete 8990/1A peak power analyzers and the obsolete 8992A digital video power analyzer. This sensor gives you outstanding measurement accuracy in demanding situations and includes automatic temperature sensing and correction.
* Outstanding measurement accuracy
* Automatic temperature sensing and correction -
Attenuator
HP 8494G Programmable Step Attenuator, DC to 4 GHz
The 8494G dc to 4 GHz programmable step attenuator offers exceptional repeatability and reliability. Attenuation is provided in 1 dB steps from 0 to 11 dB. Precision gold-plated leaf springs ensure long-life (over 5 million cycles) and very high attenuator repeatability (typically 0.01 dB). To improve measurement accuracy, NIST traceable data (SWR and attenuation) is available as Option UK6. A maximum switching time of 20 ms (including contact settling) speeds automatic testing. Custom step attenuator/switch combinations are possible. The Keysight 11716A/B/C interconnect kits provide quick connection of Keysight 8494/5/6/7 1 dB and 10 dB step attenuators in series for greater dynamic range with 1 dB steps.
* Frequency range: dc to 4 GHz
* Insertion loss at 0 dB: 0.6 dB + 0.09 dB/GHz
* Maximum SWR: 1.5
* Repeatability life: 0.03 dB max 5 million cycles per section, typical
* 5 million cycles per section
* Maximum RF input power: 1 W (average), 100 W (peak)
* Connector type: choice of Type-N female, SMA female, APC-7
* Programming connector: 12-pin Viking, optional 14-pin DIP -
PEAK POWER SENSOR
HP 8991A Peak Power Meter
The HP 8991A peak power analyzer provides complete and accurate characterization of today's complex pulsed signals. It is capable of performing seven automatic timing measurements (rise time, fall time, pulse width, PRI, PRF, duty cycle, and delay) and five automatic power measurement (peak power, average power, pulse top/base amplitude, and overshoot) with push-button ease. Front-panel operation is intuitive and straightforward. Data entries can be typed in or made with the front panel knob; automatic measurements are made with simple keystroke. The 8990A offers two sensor channels plus two external triggering/oscilloscope channels, allowing the simultaneous measurement of modulating signals and detector power envelopes.
* Amplitude and time markers for measuring power exactly where its needed
* Two oscilloscope channels for measuring time delay between video and microwave pulse
* Versatile triggering enables the capturing of exclusive glitches
* Waveform math functions for measuring scalar pulse parameters
* Dynamic Range: >45 dB
* Minimum Pulse Width: 20 ns
* Rise Time: <5 ns * Sensor and Video Inputs: 1 and 4; 2 and 3 -
Power Supply
HP E3616A 60W Power Supply, 35V, 1.7A
Keysight basic DC power supplies offer essential features for a tight budget.
The single output, 30-60 W, E3610A-E3617A provide small, compact size for bench use; low-noise and excellent regulation; and dual-range outputs (E3610A/11A/12A).
The Keysight 60W, single output E3616A is a reliable and convenient power for benchtop use, and offers solid performance and a variety of basic and enhanced capabilities.Output Ratings (Maximum current is derated 1% per °C between 40° to 55°C)
> Range 1: 0 to 35 V, 0 to 1.7 A
> Range 2: NA
> Power (max): 60 WRipple & Noise from 20 Hz to 20 MHz
> Voltage rms: 200 µV
> Peak-to-Peak: 1 mVLoad & Line Regulation
> 0.01% + 2 mVMeter Resolution
> Voltage: 10 mV (0-20 V), 100 mV (>20 V)
> Current: 1 mA -
Power Supply
HP-Agilent/Keysight E3620A
50W Dual Output Power Supply, Two 25V, 1A
Keysight basic DC power supplies offer essential features for a tight budget.
The multiple output, 35-50 W, E3620A and E3630A provide dual and triple outputs; small, compact size for bench use; low-noise and excellent regulation; and overload indicator to monitor output.
The Keysight 50W, dual output E3620A has two clean, reliable outputs for general purpose application; and is compact, affordable for versatile benchtop testing.Output ratings (Maximum current is derated 3.3% per °C from 40°C to 55°C)
> Output 1: 0 to 25 V, 0 to 1 A
> Output 2: 0 to 25 V, 0 to 1 A
> Power (max): 50 WRipple & noise from 20 Hz to 20 MHz
> Normal Mode Voltage rms: 350 µV
> Peak-to-Peak: 1.5 mVLoad & line regulation
> 0.01% + 2mVMeter resolution
> Voltage: 10 mV (0-20 V), 100 mV, (>20 V)
> Current: 1 mA -
Cable
HP-Agilent/Keysight 11730A Sensore di potenza / Cavo sorgente rumore SNS (1,5 m / 5 piedi)
The Keysight 11730A/B/C/D/E cables are used with the N8480/8480 and E-series power sensors (except the E9320 family of peak and average sensors). These cables are designed to reduce RFI effects on low power readings with an improved shielding design in the cable itself. Cables may be ordered individually or in pairs in any combination desired for single and dual-channel measurements. The Keysight 11730A/B/C can also be used in conjunction with the SNS series noise sources which are designed to operate with the NFA Series Noise Figure Analyzers
€0.00 View Product -
Power Sensor
HP-Agilent/Keysight 8481A
HP AGILENT KEYSIGHT 8481A POWER SENSOR 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
The 8481A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 10 MHz to 18 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• N (m) connector -
Network Analyzer
HP/Agilent-Keysight 8753D
The HP 8753D is a vector network analyzer and it offers even more flexibility and measurement capability than the HP 8752C in the following areas:
* Frequency range from 30 kHz to 3 GHz.
* Built-in S-parameter test set provides complete forward and reverse measurements, allowing you to completely characterize your component with a single connection.
* 50 and 75 ohm solutions.
* Superb accuracy. The most comprehensive calibration available guarantees accurate measurements. TRL**nRMt makes calibration in non-coaxial environments easier and more convenient.
* Mixer testing. Quickly and easily characterize frequency translating devices such as mixers.
* Add swept harmonic measurements. Characterize amplifter parameters – gain, 1 dB compression, match – and 2nd and 3rd harmonic distortion with the same test setup.
* Built-in 3.5 inch floppy disk drive provides convenient storage of instrument states and data.
* Parallel and serial ports provide interfaces to popular printers and plotters. The parallel port can also be used as a general U0 bus, with user-controllable TI’L inputs and outputs. Users can also connect a DIN keyboard to speed up entry of titles, labels, or file names, and for remote hnt panel operation.Two excellent choices, the HP 8752C and HP 8753D continue the tradition of affordable excellence in RF component measurements for the lab and production test areas. The HP 8752C and HP 8753D network analyzers bring superior performance and useful productivity features to simplify and speed your device, component, or network measurements in the 30 kHz to 6 GHz frequency range. A swept synthesized source, sensitive receiver, and crisp color display ensure rapid, accurate, and easy-to-read test results. Since the HP 8752C and HP 8753D are vector network analyzers, they not only provide magnitude and phase information, but also offer up to 1 10 dB dynamic range, make group delay and time domain measurements, and utilize vector accuracy enhancement to minimize measurement uncertainty.
Datasheet -
Frequency Counter
HP/Agilent-Keysight 53131A
The two-channel 53131A counter offers 10 digits per second of frequency/period resolution and a bandwidth of 225 MHz. Time interval resolution is specified at 500 ps. An optional third channel provides frequency measurements up to 3, 5, or 12.4 GHz. Standard measurements include frequency, period, ratio, time interval, pulse width, rise/fall time, phase angle, duty cycle, totalize, and peak voltage.
Two 225 MHz input channels, plus optional third channel up to 12.4 GHz
10 digits per second, 500 ps time interval resolution
GPIB Standard
option 010 > Optional High Stability Timebase with Oven and Electronic Calibration
option 030 > 100 MHz to 3 GHzThe Keysight Technologies, Inc. 53131A/132A/181A high-performance counters give you fast, precise frequency measurements at an affordable price. These counters feature an intuitive user interface and one-button access to frequently used functions so you can make accurate measurements quickly and easily. Real-time digital signal processing technology is used to analyze data while simultaneously taking new readings, speeding measurement throughput. The technology, developed for Keysight’s high-end line of modulation domain analyzers, allows the counters to gather more data for each measurement, so you get higher-resolution measurements in a fraction of the time it takes other counters. The 53131A/132A/181A counters offer built-in statistics and math functions so you can scale measurements and simultaneously measure and track average, min/max and standard deviation. Automated limit testing lets you set upper and lower limits for any measurement. An analog display mode lets you see at a glance whether a measurement is within pass/fail limits. The counters flag out-of-limit conditions and can generate an output signal to trigger external devices when a limit is exceeded. For quick access to frequently used tests, a single keystroke recalls up to 20 different stored front-panel set-ups. For computer-controlled systems applications, each counter includes a standard GPIB interface with full SCPI-compatible programmability and a data transfer rate of up to 200 fully formatted measurements per second. The standard RS-232 talk-only interface provides printer support or data transfer to a computer through a terminal-emulation program.
Datasheet -
Low-Profile Modular Power System Mainframe
AGILENT – Hp/ Keysight N6700B
The Keysight N6700B is a 400 W 1U high, 4-slot modular power system mainframe that accepts from 1 to 4 N6700 series DC power modules in any combination. Modules are ordered separately. The N6700B offers GPIB, LAN, and USB, interfaces standard, and LXI compliance. Select from more than 20 different DC power modules, ranging in capability from basic to high precision, and in power from 20 – 300 W.
€1,020.00€1,200.00View Product -
Frequency Counter
AGILENT – Hp/Keysight 53181A OPT 030 /3 GHZ
Optimized for RF applications, the single-channel 10 digit/s 53181A measures frequency, period and peak voltage. A digit-blanking function lets you easily eliminate unnecessary digits when you want to read measurements quickly. For higher-frequency measurements, choose an optional second channel that provides measurements up to 1.5, 3, 5, or 12.4 GHz. A self-guided shallow menu makes this counter exceptionally easy to use
RF Frequency Counter, 10 digits/s
One 225 MHz input channel, plus optional second channel up to 12.4 GHz
10 digits/second resolution
GPIB StandardThe Keysight Technologies, Inc. 53131A/132A/181A high-performance counters give you fast, precise frequency measurements at an affordable price. These counters feature an intuitive user interface and one-button access to frequently used functions so you can make accurate measurements quickly and easily. Real-time digital signal processing technology is used to analyze data while simultaneously taking new readings, speeding measurement throughput. The technology, developed for Keysight’s high-end line of modulation domain analyzers, allows the counters to gather more data for each measurement, so you get higher-resolution measurements in a fraction of the time it takes other counters. The 53131A/132A/181A counters offer built-in statistics and math functions so you can scale measurements and simultaneously measure and track average, min/max and standard deviation. Automated limit testing lets you set upper and lower limits for any measurement. An analog display mode lets you see at a glance whether a measurement is within pass/fail limits. The counters flag out-of-limit conditions and can generate an output signal to trigger external devices when a limit is exceeded. For quick access to frequently used tests, a single keystroke recalls up to 20 different stored front-panel set-ups. For computer-controlled systems applications, each counter includes a standard GPIB interface with full SCPI-compatible programmability and a data transfer rate of up to 200 fully formatted measurements per second. The standard RS-232 talk-only interface provides printer support or data transfer to a computer through a terminal-emulation program.
Datasheet -
Power Sensor
AGILENT – Hp/Keysight 8487A
HP AGILENT KEYSIGHT 8487A POWER SENSOR 50 MHz to 50 GHz
The 8487A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters. The 8487A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 50 MHz to 50 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• 2.4 mm(m) connector
Scheda Tecnica -
Module
AGILENT 34903A – 20 Channel Actuator/GP Switch Module for 34970A/34972A
The Agilent 34903A is a general-purpose switch module for the 34970A/34972A Data Acquisition/Switch Unit. It has 20 independent single-pole, double-throw (SPDT) relays and is used to cycle power to products under test, control indicator and status lights, and to actuate external power relays and solenoids. Combine it with matrix and multiplexer modules to build custom switch systems. Its 300 V, 1 A contacts can handle up to 50 W, enough for many power line switching applications.
* 20 Channel Actuator/GP Switch
* SPDT (Form C) latching relays
* 300 V, 1 A actuation and control -
Module
AGILENT 34907A Multifunction Module for 34970A/34972A
The HP 34907A module for the 34970A/34972A Data Acquisition/Switch Unit allows great flexibility for a variety of sense and control applications. It combines two 8-bit ports of digital input and output, a 100 kHz gated totalizer, and two ±12V analog outputs – all on a single earth-referenced module. The digital inputs and totalizer input may be included in a scan. Alarm limits for the digital and event counter inputs are evaluated continuously, capturing and logging alarm conditions even between scans.
Use the digital outputs with an external power supply to control microwave switches and attenuators, solenoids, power relays, indicators, and more. Use the digital inputs to sense limit switch and digital bus status. There are no complex handshake modes; reads and writes are initiated either from the front panel or the bus.
Count events from devices like photo interrupters, limit switches, and Hall-effect sensors.
It keeps an updated total which can be read via the front panel or programmatically at any time. With 26 bits of resolution, it can count events at full speed for nearly 45 minutes without an overflow.
Use the two electronically calibrated analog outputs to source bias voltages to your device under test, to control your analog programmable power supplies, or use the outputs as setpoints for your control systems. The outputs are programmed directly in volts, either from the front panel or from the bus.
Key Features & Specifications:
– 16 bits of digital input and output
– 100 kHz totalizer input
– Two +/-12V analog outputs -
Power Sensor
AGILENT E9323A
AGILENT E9323A E-Series Power Sensor, 50 MHz to 6 GHz
The E9323A diode power sensor has a 5 MHz video bandwidth and is ideal for time-gated peak, average and peak-to-average ratio power measurements on W-CDMA wireless formats such as cdma2000.Key Features & Specifications:
– 5 MHz video bandwidth, ideal for W-CDMA and cdma2000 applications
– Fast measurement speed, up to 1000 corrected readings per second, via the GPIB
– Wide dynamic range
– Calibration factors, linearity, temperature and bandwidth correction stored in EEPROM
– Precision type-N connector as standard
– Operates with the EPM-P (E4416A/ 17A) series and P-Series (N1911A/ 12A) power meters
Datasheet -
USB/GPIB Interface High-Speed USB 2.0
AGILENT-Hp/Keysight 82357B
The Agilent 82357B USB/GPIB Interface provides a direct connection from a USB port on your laptop or desktop PC to GPIB instruments. There are no switches to set, no PC cards to install, and no external power supplies required. Getting connected has never been easier.
Easy connection – plug-and-play interface
USB 2.0 interface (USB 1.1 compatible) and IEEE-488 interface (connect up to 14 GPIB instruments)
High-speed – transfer over 1.15MB/sec
Parallel Polling (check response of up to 8 devices at one single poll)
Standard industry libraries with Keysight IO Libraries Suite -
Function/Arbitrary Waveform Generator
AGILENT-Hp/Keysight 33120A
The 33120A function generator has a proven legacy, 15 MHz bandwidth, arbitrary waveforms & modulation capability. DDS technology provides precise adjustment and frequency stability.
15 MHz sine & square waveforms
Ramp, triangle, noise & DC waveforms
12-bit, 40 MSa/s, 16,000 points arbitrary waveforms
AM (int/ext), FM (int), FSK (internal/external), burst (int/extl)
Linear & logarithmic sweeps and burst operation
IntuiLink software plus GPIB & RS-232 interfaces included
Option 001 provides improved stability & a multiple-unit link
Datasheet -
Date Acquisition/Switch Unit
AGILENT-Hp/Keysight 34970A
The Agilent 34970A data acquisition / data logger switch consists of a three-slot mainframe with a built-in 6 1/2 digit digital multimeter. Each channel can be configured independently to measure one of 11 different functions without the added cost or hassles of signal-conditioning accessories. Choose from eight optional plug-in modules to create a compact data logger, full-featured data acquisition system or low-cost switching unit. On-module screw-terminal connections eliminate the need for terminal blocks and a unique relay maintenance feature counts every closure on every switch for easy, predictable relay maintenance. Our most popular module 34901A features a built-in thermocouple reference and 20 two-wire channels.
* 3-slot mainframe with built-in GPIB and RS232 interfaces
* 6 1/2-digit (22-bit) internal DMM, scanning up to 250 channels per second
* 8 switch and control plug-in modules to choose from
* Built-in signal conditioning measures thermocouples, RTDs and thermistors, AC/DC volts and current; resistance; frequency and period
* 50k readings of non-volatile memory holds data when power is removed
* Hi/LO alarm limits on each channel, plus 4 TTL alarm outputs
* A BenchVue software license (BV0006B) is now included with your instrument. BenchVue makes it simple to connect, control instruments, and automate test sequences -
Power Supply
AGILENT-Hp/Keysight 6644A
Output Ratings
Output voltage: 0 to 60 V
Output current (40° C): 0 to 3.5 A
Maximum current (50° C/55° C): 3.2 A/3 AProgramming Accuracy at 25°C ±5°C
Voltage 0.06% + 26 mV
Current 0.15% + 4.1 mARipple & Noise (20 Hz – 20 MHz)
Voltage rms: 500 µV
Voltage peak-to-peak: 5 mV
Current rms: 1.5 mAKeysight high performance DC power supplies offer speed and accuracy for test optimization. The single output, 200 W, GPIB 6641A-6645A provide fast, low-noise outputs; analog control of output voltage and current; fan-speed control to minimize acoustic noise; as well as parallel and series connections of multiple units.
The Keysight 210W, GPIB, single output 6644A is a versatile programmable supply designed to maximize test throughput during design verification or on the production line, and is fully programmable to help reduce test time through a variety of automated capabilities.
Datasheet -
Power Supply
AGILENT-Hp/Keysight 6645A
Questa serie di alimentatori CC regolati lineari da 200 W è progettata per massimizzare la produttività dei DUT attraverso il processo di test di produzione con tempi di programmazione rapidi su e giù.
I preziosi insiemi possono essere distrutti da un guasto minore di un componente che può consentire un flusso di tensione o corrente che fluisce verso il DUT. Le funzioni di protezione rapida, tra cui il piede di porco rapido, la protezione crossover in modalità e la possibilità di collegare i circuiti di protezione di più alimentatori possono aumentare il rendimento di produzione.
La programmazione dell'uscita CC e delle funzioni di protezione può essere effettuata dal pannello frontale o utilizzando i comandi SCPI standard del settore, tramite GPIB. Utilizzando il collegamento seriale, è possibile collegare fino a 16 alimentatori tramite un indirizzo GPIB. L'integrazione del sistema di test può essere ulteriormente semplificata utilizzando i driver VXIplug & play. La tensione e la corrente di uscita possono anche essere controllate con segnali analogici. Ciò è utile per alcuni tipi di ambienti rumorosi e anche per reazioni immediate ai cambiamenti di processo.Tensione flottante CC: i terminali di uscita possono essere fatti galleggiare fino a ± 240 V CC dalla terra del telaio.
Telerilevamento: è possibile far cadere fino a metà della tensione di uscita nominale in ciascun cavo di carico. La caduta del carico comporta la sottrazione della tensione disponibile per il carico.
Tempo di elaborazione del comando: il tempo medio necessario affinché la tensione di uscita inizi a cambiare in seguito alla ricezione di dati digitali è di 20 ms per gli alimentatori collegati direttamente al GPIB.
Tempo di risposta della programmazione dell'uscita: il tempo di salita e discesa (10/90% e 90/10%) della tensione di uscita è inferiore a 15 ms. La variazione della tensione di uscita si assesta entro 1 LSB (0,025% x tensione nominale) del valore finale in meno di 60 ms.
Programmazione verso il basso: un programmatore attivo verso il basso affonda circa il 20% della corrente di uscita nominale.Valori nominali di uscita
Tensione di uscita: da 0 a 120 V.
Corrente di uscita (40 ° C): da 0 a 1,5 A
Corrente massima (50 ° C / 55 ° C): 1,4 A / 1,3 APrecisione di programmazione a 25 ° C ± 5 ° C
Tensione 0,06% + 51 mV
Corrente 0,15% + 1,7 mARipple & Noise (20 Hz – 20 MHz)
Voltaggio rms: 700 µV
Tensione picco-picco: 7 mV
Corrente efficace: 1 mA
Scheda Tecnica -
Power Supply
AGILENT-Hp/Keysight 6675A
Output Ratings
Output voltage: 0 to 120 V
Output current (40°C): 0 to 18 AProgramming Accuracy at 25°C ±5°C
Voltage 0.04% + 120 mV
Current 0.1% + 12 mARipple & Noise from 20 Hz to 20 MHz
Voltage rms: 1.9 mV
Peak-to-Peak: 16 mV
Current rms: 12 mAHp high performance DC power supplies offer speed and accuracy for test optimization. The single output, 2000 W GPIB 6671A-6675A provide fast, low-noise outputs; analog control of output voltage and current; and fan-speed control to minimize acoustic noise.
The Hp 2160W, GPIB, single output 6675A is a highly efficient low-noise supply that maximize test throughput and is designed to offer excellent reliability, low ripple and noise, and extremely accurate built-in measurements of voltage and current.
Datasheet -
Power Sensor
AGILENT-Hp/Keysight 8481A
HP AGILENT KEYSIGHT 8481A POWER SENSOR 10 MHz to 18 GHz
The 8481A power sensor is designed for use with the 435A/B, 436A, 437A, 438A, 70100A, EPM series, EPM-P series, E1416A, N1911A, N1912A, N1913A, and N1914A power meters.
The 8481A provides extraordinary accuracy, stability, and lower SWR.
• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -30 to +20 dBm
• Frequency range 10 MHz to 18 GHz
• Thermocouple power sensing element
• Measurement range: 1 µW to 100 mW ( -30 dBm to +20 dBm)
• 50 ohm impedance
• N (m) connector
