Spectrum Analyzer
Rigol DSA832E-TG
The Rigol DSA832E-TG is a compact and light weight Spectrum Analyzer with premium performance for portable applications. The use of digital IF (intermediate frequency) technology guarantees reliability and performance to meet the most demanding RF applications.
The very large display (20.3 cm / 8″) of the Rigol DSA832E-TG Spectrum Analyzer provides a resolution of 800×480 pixels allowing a very good overview of all its comfortable functions like Auto Tune, Auto Range, Auto Scale and Auto Couple. These functions enable the analyzer to acquire signals and match parameters automatically, compared to the manual process necessary with a traditional analyzer. The Rigol Spectrum Analyzers have a sophisticated and easy to use user interface offering multiple functions for all tasks.
The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
DatasheetSKU: 1040€2,390.00 View Product -
Spectrum Analyzer
Rigol DSA875-TG
The Rigol DSA875-TG is a compact and light weight Spectrum Analyzer with premium performance for portable applications. The use of digital IF (intermediate frequency) technology guarantees reliability and performance to meet the most demanding RF applications. The very large display (20.3 cm / 8″) of the Rigol DSA875-TG Spectrum Analyzer provides a resolution of 800×480 pixels allowing a very good overview of all its comfortable functions like Auto Tune, Auto Range, Auto Scale and Auto Couple. These functions enable the analyzer to acquire signals and match parameters automatically, compared to the manual process necessary with a traditional analyzer. The Rigol Spectrum Analyzers have a sophisticated and easy to use user interface offering multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
DatasheetSKU: 864€4,990.00 View Product -
Signal Generator
RIGOL DSG3030-IQ
The DSG3030-IQ RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for I/Q modulation and I/Q baseband output with a maximum frequency 3 GHz. Featuring a high signal purity with phase noise measuring <-110 dBc/Hz @ 20 kHz (typical) and a wide output range of -130 dBm to +13 dBm, the DSG3000 RF signal generator has standard pulse modulation with an on/off ratio of up to 80dB, with optional pulse train generator available. The DSG3000 series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG3000 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation with customizable pulse train and I/Q modulation (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000 is designed to be both, highly stable and reliable. The DSG3000 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Special Features
- Highest frequency: 3 GHz/6 GHz
- Amplitude accuracy: < 0.5 dB (typical)
- Output amplitude range: -130 dBm to +13 dBm
- High signal purity, phase noise: < -110 dBc/Hz @ 20 kHz (typical)
- Standard 0.5 ppm internal clock; 5 ppb high stable clock for option
- Standard AM/FM/ΦM analog modulation
- Standard pulse modulation; on/off ratio up to 80 dB; pulse train generator (optional)
- I/Q modulation and I/Q baseband output
- All modulationschemes support internal and external modulation modes
- Standard 2U height design to save rack space. Rack mount kit is available
- Standard USB/LAN/GPIB remote control interfaces. SCPI command set for remote control
- Wear-free electronic attenuator design
- Well-designed automatic flatness calibration function (Cables, attenuators, amplifiers and so on) for test systems with power meter control
SKU: n/a€8,490.00 View Product -
Signal Generator
Rigol DSG3060
The DSG3060 RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for I/Q modulation and I/Q baseband output with a maximum frequency 6 GHz. Featuring a high signal purity with phase noise measuring <-110 dBc/Hz @ 20 kHz (typical) and a wide output range of -130 dBm to +13 dBm, the DSG3000 RF signal generator has standard pulse modulation with an on/off ratio of up to 80dB, with optional pulse train generator available. The DSG3000 series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface. The DSG3000 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation with customizable pulse train and I/Q modulation (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000 is designed to be both, highly stable and reliable. The DSG3000 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance. * Highest frequency: 3 GHz/6 GHz * Amplitude accuracy: < 0.5 dB (typical) * Output amplitude range: -130 dBm to +13 dBm * High signal purity, phase noise: < -110 dBc/Hz @ 20 kHz (typical) * Standard 0.5 ppm internal clock; 5 ppb high stable clock for option * Standard AM/FM/ΦM analog modulation * Standard pulse modulation; on/off ratio up to 80 dB; pulse train generator (optional) * I/Q modulation and I/Q baseband output * All modulationschemes support internal and external modulation modes * Standard 2U height design to save rack space. Rack mount kit is available * Standard USB/LAN/GPIB remote control interfaces. SCPI command set for remote control * Wear-free electronic attenuator design * Well-designed automatic flatness calibration function (Cables, attenuators, amplifiers and so on) for test systems with power meter control
SKU: 743 -
Signal Generator
RIGOL DSG3060-IQ
The DSG3060-IQ RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for I/Q modulation and I/Q baseband output with a maximum frequency 6 GHz. Featuring a high signal purity with phase noise measuring <-110 dBc/Hz @ 20 kHz (typical) and a wide output range of -130 dBm to +13 dBm, the DSG3000 RF signal generator has standard pulse modulation with an on/off ratio of up to 80dB, with optional pulse train generator available. The DSG3000 series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG3000 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation with customizable pulse train and I/Q modulation (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000 is designed to be both, highly stable and reliable. The DSG3000 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Special Features
- Highest frequency: 3 GHz/6 GHz
- Amplitude accuracy: < 0.5 dB (typical)
- Output amplitude range: -130 dBm to +13 dBm
- High signal purity, phase noise: < -110 dBc/Hz @ 20 kHz (typical)
- Standard 0.5 ppm internal clock; 5 ppb high stable clock for option
- Standard AM/FM/ΦM analog modulation
- Standard pulse modulation; on/off ratio up to 80 dB; pulse train generator (optional)
- I/Q modulation and I/Q baseband output
- All modulationschemes support internal and external modulation modes
- Standard 2U height design to save rack space. Rack mount kit is available
- Standard USB/LAN/GPIB remote control interfaces. SCPI command set for remote control
- Wear-free electronic attenuator design
- Well-designed automatic flatness calibration function (Cables, attenuators, amplifiers and so on) for test systems with power meter control
SKU: n/a€10,490.00 View Product -
Signal Generator
RIGOL DSG3065B
The DSG3000B series is a high-performance RF signal generator. It provides comprehensive modulation solutions: AM/FM/ΦM analog modulation; pulse modulation with user-defined pulse train; and I/Q modulation. All the modulations support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000B series has undergone a strict verification through the experiments in its design and
production stages to ensure its high stability and reliability. The DSG3000B series also features a clear user interface, compact size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool in various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.Features:
Highest frequency: 6.5GHz
Amplitude accuracy: <0.5 dB (typical)
Output amplitude range: -130 dBm to +27 dBm (setting range)
High signal purity, phase noise: <-116 dBc/Hz@20 kHz (typical)
Standard 1 ppm internal clock; optional 5 ppb high stable clock
Standard AM/FM/ΦM analog modulation
Support pulse modulation; on/off ratio up to 70 dB; user-defined pulse train generator
I/Q modulation and I/Q baseband output
All modulations support internal and external modulation modes
Standard 2U height design to save rack space; rack mount kit is available
Support USB/LAN/GPIB remote control; SCPI command set
Wear-free electronic attenuator designSKU: n/a€7,295.00 View Product -
Signal Generator
RIGOL DSG3065B-IQ
The DSG3000B series is a high-performance RF signal generator. It provides comprehensive modulation solutions: AM/FM/ΦM analog modulation; pulse modulation with user-defined pulse train; and I/Q modulation. All the modulations support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000B series has undergone a strict verification through the experiments in its design and
production stages to ensure its high stability and reliability. The DSG3000B series also features a clear user interface, compact size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool in various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.Features:
Highest frequency: 6.5GHz
Amplitude accuracy: <0.5 dB (typical) Output amplitude range: -130 dBm to +27 dBm (setting range) High signal purity, phase noise: <-116 dBc/Hz@20 kHz (typical) Standard 1 ppm internal clock; optional 5 ppb high stable clock Standard AM/FM/ΦM analog modulation Support pulse modulation; on/off ratio up to 70 dB; user-defined pulse train generator I/Q modulation and I/Q baseband output All modulations support internal and external modulation modes Standard 2U height design to save rack space; rack mount kit is available Support USB/LAN/GPIB remote control; SCPI command set Wear-free electronic attenuator design DatasheetSKU: n/a€10,595.00 View Product -
Signal Generator
Rigol DSG815
9 kHZ TO 1,5 GHz
The DSG800 series covers output frequencies from 9 kHz to 3.0GHz. The instruments provide maximum output power up to +20 dBm and low SSB phase noise -115 dBc/Hz, amplitude accuracy of +/- 0.5 dB, and frequency resolution 0.01 Hz at any frequency. An oven-controlled crystal oscillator time-base option provides < 5 ppb temperature stability and < 30 ppb/year aging stability, the most accurate and stable available in this class. For IoT and RF applications from design to debug the DSG800 series provides uncompromised RF signal generation capabilities at an unprecedented value.
SKU: 918€1,875.00 View Product -
Signal Generator
RIGOL DSG821
RF SIGNAL GENERATOR 9 kHz to 2.1 GHz
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
DatasheetSKU: n/a€2,094.00 View Product -
Signal Generator
RIGOL DSG821A
RF SIGNAL GENERATOR 9 kHz to 2.1 GHz with I/Q Modulation
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
DatasheetSKU: n/a€3,394.00 View Product -
Signal Generator
RIGOL DSG836
RF SIGNAL GENERATOR 9 kHz to 3.6 GHz
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
DatasheetSKU: n/a€3,394.00 View Product -
Signal Generator
RIGOL DSG836A
RF SIGNAL GENERATOR 9 kHz to 3.6 GHz with I/Q Modulation
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
DatasheetSKU: n/a€4,694.00 View Product -
Mainframe
Rigol M300
The M300 series data acquisition/switch system provides 5 slots to accept any combination of 11 kinds of plug-in modules, including a DMM module, multiple multiplexers, an actuator, a matrix switch module and a multifunction module. With its modular structure, it combines precision measurement capability with flexible signal connections and can provide versatile solutions for the applications that require multiple points or signals to be tested. This can be especially useful in product performance testing during the R&D phase, and automatic test during production process.
It comes with a 4.3 inch high-resolution color LCD, user-friendly interface design, easy-to-use keyboard layout as well as clear key backlight and operation prompts. The M300 is extremly flexible and easy to use. For remote control versatility, it comes with RS232, USB, LAN and GPIB interfaces standard.
Key Applications
CJC Compensated Temperature measurements
Voltage and 2-Wire Resistance
4 Wire Resistance Measurements
Current Measurements
Matrix applications for flexible signal routing
Mixed and Multifunction Applications (Digital I/O, DAC, Totalizer)
Actuator Systems (up to 300 Vrms / 2 Arms, 60 VA, without connection to the DMM)Special Features
Up to 320 switch channels per mainframe
Can run independently without PC
USB data logging
Interval scanning with storage of up to 100,000 time-stamped readings
6½ digit DMM can be inserted into any slot. It also supports multiple measurement functions, including DCV, DCI, ACV, ACI, 2WR, 4WR, PERIOD, FREQ, TEMP (Thermocouple, Thermistor and RTD) and any sensor
4.3 inch color LCD with friendly interface and built-in help system
Powerful PC control and analysis software
Standard multiple communication interface: USB Device, USB Host, GPIB, LAN(LXI Core Device 2011) and RS232
DatasheetSKU: 831€894.00 View Product -
Mainframe
Rigol M301
The M301 Data Acquisition System is designed for automated multichannel measurement and switch applications. This includes environmental measurements like temperature for burn in tests as well as voltage, frequency, or resistance measurements from a wide variety of sensors used from research to production test.
The M300 series data acquisition/switch system provides 5 slots to accept any combination of 11 kinds of plug-in modules, including a DMM module, multiple multiplexers, an actuator, a matrix switch module and a multifunction module. With its modular structure, it combines precision measurement capability with flexible signal connections and can provide versatile solutions for the applications that require multiple points or signals to be tested. This can be especially useful in product performance testing during the R&D phase, and automatic test during production process.
It comes with a 4.3 inch high-resolution color LCD, user-friendly interface design, easy-to-use keyboard layout as well as clear key backlight and operation prompts. The M300 is extremly flexible and easy to use. For remote control versatility, it comes with RS232, USB, LAN and GPIB interfaces standard.
Key Applications
CJC Compensated Temperature measurements
Voltage and 2-Wire Resistance
4 Wire Resistance Measurements
Current Measurements
Matrix applications for flexible signal routing
Mixed and Multifunction Applications (Digital I/O, DAC, Totalizer)
Actuator Systems (up to 300 Vrms / 2 Arms, 60 VA, without connection to the DMM)Special Features
Up to 320 switch channels per mainframe
Can run independently without PC
USB data logging
Interval scanning with storage of up to 100,000 time-stamped readings
6½ digit DMM can be inserted into any slot. It also supports multiple measurement functions, including DCV, DCI, ACV, ACI, 2WR, 4WR, PERIOD, FREQ, TEMP (Thermocouple, Thermistor and RTD) and any sensor
4.3 inch color LCD with friendly interface and built-in help system
Powerful PC control and analysis software
Standard multiple communication interface: USB Device, USB Host, GPIB, LAN(LXI Core Device 2011) and RS232
DatasheetSKU: 832€1,290.00 View Product -
Date Acquisition/Switch Unit, Mainframe
RIGOL M302
The M300 series data acquisition/switch system provides 5 slots to accept any combination of 11 kinds of plug-in modules, including a DMM module, multiple multiplexers, an actuator, a matrix switch module and a multifunction module. With its modular structure, it combines precision measurement capability with flexible signal connections and can provide versatile solutions for the applications that require multiple points or signals to be tested. This can be especially useful in product performance testing during the R&D phase, and automatic test during production process.
It comes with a 4.3 inch high-resolution color LCD, user-friendly interface design, easy-to-use keyboard layout as well as clear key backlight and operation prompts. The M300 is extremly flexible and easy to use. For remote control versatility, it comes with RS232, USB, LAN and GPIB interfaces standard.
Key Applications
- CJC Compensated Temperature measurements
- Voltage and 2-Wire Resistance
- 4 Wire Resistance Measurements
- Current Measurements
- Matrix applications for flexible signal routing
- Mixed and Multifunction Applications (Digital I/O, DAC, Totalizer)
- Actuator Systems (up to 300 Vrms / 2 Arms, 60 VA, without connection to the DMM)
Special Features
- Up to 320 switch channels per mainframe
- Can run independently without PC
- USB data logging
- Interval scanning with storage of up to 100,000 time-stamped readings
- 6½ digit DMM can be inserted into any slot. It also supports multiple measurement functions, including DCV, DCI, ACV, ACI, 2WR, 4WR, PERIOD, FREQ, TEMP (Thermocouple, Thermistor and RTD) and any sensor
- 4.3 inch color LCD with friendly interface and built-in help system
- Powerful PC control and analysis software
- Standard multiple communication interface: USB Device, USB Host, GPIB, LAN(LXI Core Device 2011) and RS232
SKU: 920€1,580.00 View Product -
Oscilloscope 4 channles
RIGOL MHO2024
The RIGOL MHO2024 is a high-resolution digital oscilloscope with a 200 MHz bandwidth and 4 analog channels, designed to meet the most advanced design, debugging, and testing requirements. Based on the latest-generation Centaurus platform, it combines 12-bit vertical resolution, deep memory, fast waveform acquisition, and comprehensive analysis tools. Its compact design and battery operation make it ideal for both laboratory and field use.
Key Features:
Bandwidth: 200 MHz (4 analog channels + 1 external trigger channel)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 2 GSa/s
Maximum memory depth: 500 Mpts (half channel), 250 Mpts (full channels)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode), 200,000 wfms/s (vector mode)
Vertical sensitivity: 100 μV/div to 10 V/div (1 MΩ), 100 μV/div to 1 V/div (50 Ω)
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
Input coupling: DC, AC, or GND
10.1″ capacitive multi-touch display (1280×800), 256-level grayscale16 standard digital channels (requires logic analyzer probe)
Standard interfaces: USB Device, USB Host, LAN (LXI), HDMI, AUX OUT
Advanced features: hardware mask test, digital voltmeter, 6-digit frequency counter, search & navigation, Bode plot (with AWG option), power analysis (optional), histogram, segmented memory, pass/fail test, and online firmware update
Standard package4 PVP2350 passive probes
AC power adapter
USB cable
Quick start guideSKU: n/a€2,394.00 View Product -
Oscilloscope 4 channles
RIGOL MHO2034
The RIGOL MHO2034 is a high-resolution digital oscilloscope with a 350 MHz bandwidth and 4 analog channels, designed to meet the most advanced design, debugging, and testing requirements. Based on the latest-generation Centaurus platform, it combines 12-bit vertical resolution, deep memory, fast waveform acquisition, and comprehensive analysis tools. Its compact design and battery operation make it ideal for both laboratory and field use.
Key Features:
Bandwidth: 350 MHz (4 analog channels + 1 external trigger channel)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 2 GSa/s
Maximum memory depth: 500 Mpts (half channel), 250 Mpts (full channels)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode), 200,000 wfms/s (vector mode)
Vertical sensitivity: 100 μV/div to 10 V/div (1 MΩ), 100 μV/div to 1 V/div (50 Ω)
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
Input coupling: DC, AC, or GND
10.1″ capacitive multi-touch display (1280×800), 256-level grayscale
16 standard digital channels (requires logic analyzer probe)
Standard interfaces: USB Device, USB Host, LAN (LXI), HDMI, AUX OUT
Advanced features: hardware mask test, digital voltmeter, 6-digit frequency counter, search & navigation, Bode plot (with AWG option), power analysis (optional), histogram, segmented memory, pass/fail testing, and online firmware update
Standard package4 PVP2350 passive probes
AC power adapter
USB cable
Quick start guideSKU: n/a€3,294.00 View Product -
Oscilloscope
RIGOL MHO934
The RIGOL MHO934 is a compact, high-performance mixed-signal digital oscilloscope with a bandwidth of 350 MHz and 4 analog channels. Designed to redefine the standard for instruments in this category, it offers 12-bit hardware vertical resolution for detailed signal analysis, deep memory, and extremely high waveform capture speed. Thanks to its 16 integrated digital channels (optional PLA2216 probe) and a comprehensive set of decoding options, it is the ideal solution for debugging embedded systems, testing power supplies, and for the educational sector.
Key Features
Bandwidth: 350 MHz
4 analog channels + 16 digital channels with PLA2216 probe (optional)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 4 GSa/s (single channel)
Memory depth: 100 Mpts (standard), 500 Mpts (optional)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode)
Vertical sensitivity: 200 μV/div to 10 V/div
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
7″ capacitive multi-touch display (1024×600 px), 256-level grayscale
Standard interfaces: USB Device & Host, LAN (10/100), HDMI
Advanced features: 2-channel waveform generator (50/100 MHz, optional), Bode plot analysis (with AFG option), serial decoding (RS232, I²C, SPI, CAN, LIN standard; CAN-FD, FlexRay, I²S optional) and web-based control
Standard accessories4 PVP2350 passive probes (350 MHz)
Type-C power adapter
USB cable
Ground cableSKU: n/a€814.00 View Product -
Oscilloscope
RIGOL MHO954
The RIGOL MHO954 is a mixed-signal digital oscilloscope that offers a bandwidth of 500 MHz across 4 analog channels, making it ideal for analyzing high-speed signals. This instrument combines 12-bit hardware vertical resolution—which ensures 16 times better signal fidelity than 8-bit oscilloscopes—with ultra-deep memory and ultra-fast waveform capture. With its 16 integrated digital channels, it is perfect for complex applications such as automotive bus debugging, power electronics testing, and research and development.
Key Features
Bandwidth: 500 MHz
4 analog channels + 16 digital channels with PLA2216 probe (optional)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 4 GSa/s (single channel)
Memory depth: 100 Mpts (standard), 500 Mpts (optional)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode)
Vertical sensitivity: 200 μV/div to 10 V/div
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
7″ capacitive multi-touch display (1024×600 px), 256-level grayscale display
Standard interfaces: USB Device & Host, LAN (10/100), HDMI
Advanced features: 2-channel waveform generator (50/100 MHz, optional), Bode plot analysis (with AFG option), serial decoding (RS232, I²C, SPI, CAN, LIN standard; CAN-FD, FlexRay, I²S optional), and web-based control
Standard equipment4 RP3500A passive probes (500 MHz)
Type-C power adapter
USB cable
Ground cableSKU: n/a€914.00 View Product -
Oscilloscope
RIGOL MHO984
The RIGOL MHO984 is a high-performance mixed-signal digital oscilloscope with an 800 MHz bandwidth across 4 analog channels, designed to tackle the most demanding challenges. It offers 12-bit hardware vertical resolution to capture even the finest signal details, exceptionally deep memory, and lightning-fast capture speed to detect rare events. The 16 integrated digital channels make it a powerful and versatile tool for advanced debugging of embedded systems, high-speed bus testing, and power electronics applications.
Key Features:
Bandwidth: 800 MHz
4 analog channels + 16 digital channels with PLA2216 probe (optional)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 4 GSa/s (single channel)
Memory depth: 100 Mpts (standard), 500 Mpts (optional)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode)
Vertical sensitivity: 200 μV/div to 10 V/div
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
7″ capacitive multi-touch display (1024×600 px), 256-level grayscale display
Standard interfaces: USB Device & Host, LAN (10/100), HDMI
Advanced features: 2-channel waveform generator (50/100 MHz, optional), Bode plot analysis (with AFG option), serial decoding (RS232, I²C, SPI, CAN, LIN standard; CAN-FD, FlexRay, I²S optional), and web-based control
Standard equipment4 RP3500A passive probes (500 MHz)
Type-C power adapter
USB cable
Ground cableSKU: n/a€1,004.00 View Product -
Oscilloscope 4 channles
Rigol MSO1074Z
The Rigol MSO1074Z is a very high quality four channel digital storage oscilloscope. It features a real-time sample rate of up to 1 GSa/s and a bandwidth of 70 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls also offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO1074Z has a refresh rate of up to 30.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
DatascheetSKU: 830€679.00 View Product -
Oscilloscope 4 channles
Rigol MSO1074Z-S
The Rigol MSO1074Z-S is a very high quality four channel digital storage oscilloscope with built-in 25 MHz bandwidth 2CH arbitrary waveform generator. The scope features a real-time sample rate of up to 1 GSa/s and a bandwidth of 70 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls also offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO1074Z-S has a refresh rate of up to 30.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
DatascheetSKU: 829€869.00 View Product -
Oscilloscope 4 channles
Rigol MSO1104Z
The Rigol MSO1104Z is a very high quality four channel digital storage oscilloscope. It features a real-time sample rate of up to 1 GSa/s and a bandwidth of 100 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls also offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO1074Z has a refresh rate of up to 30.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
DatascheetSKU: 828€799.00 View Product -
Oscilloscope 4 channles
Rigol MSO1104Z-S
The Rigol MSO1104Z-S is a very high quality four channel digital storage oscilloscope with built-in 25 MHz bandwidth 2CH arbitrary waveform generator. The scope features a real-time sample rate of up to 1 GSa/s and a bandwidth of 100 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls also offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO1074Z-S has a refresh rate of up to 30.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
DatascheetSKU: 827€999.00 View Product -
Oscilloscope 2 channels
Rigol MSO2102A
The Rigol MSO2102A is a very high quality two channel digital storage oscilloscope. It features a real-time sample rate of up to 2 GSa/s and a bandwidth of 100 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages. This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO2072A has a refresh rate of up to 50.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
DatascheetSKU: 822€905.00 View Product
-
Spectrum Analyzer
Rigol DSA832E-TG
The Rigol DSA832E-TG is a compact and light weight Spectrum Analyzer with premium performance for portable applications. The use of digital IF (intermediate frequency) technology guarantees reliability and performance to meet the most demanding RF applications.
The very large display (20.3 cm / 8″) of the Rigol DSA832E-TG Spectrum Analyzer provides a resolution of 800×480 pixels allowing a very good overview of all its comfortable functions like Auto Tune, Auto Range, Auto Scale and Auto Couple. These functions enable the analyzer to acquire signals and match parameters automatically, compared to the manual process necessary with a traditional analyzer. The Rigol Spectrum Analyzers have a sophisticated and easy to use user interface offering multiple functions for all tasks.
The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
Datasheet -
Spectrum Analyzer
Rigol DSA875-TG
The Rigol DSA875-TG is a compact and light weight Spectrum Analyzer with premium performance for portable applications. The use of digital IF (intermediate frequency) technology guarantees reliability and performance to meet the most demanding RF applications. The very large display (20.3 cm / 8″) of the Rigol DSA875-TG Spectrum Analyzer provides a resolution of 800×480 pixels allowing a very good overview of all its comfortable functions like Auto Tune, Auto Range, Auto Scale and Auto Couple. These functions enable the analyzer to acquire signals and match parameters automatically, compared to the manual process necessary with a traditional analyzer. The Rigol Spectrum Analyzers have a sophisticated and easy to use user interface offering multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
Datasheet -
Signal Generator
RIGOL DSG3030-IQ
The DSG3030-IQ RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for I/Q modulation and I/Q baseband output with a maximum frequency 3 GHz. Featuring a high signal purity with phase noise measuring <-110 dBc/Hz @ 20 kHz (typical) and a wide output range of -130 dBm to +13 dBm, the DSG3000 RF signal generator has standard pulse modulation with an on/off ratio of up to 80dB, with optional pulse train generator available. The DSG3000 series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG3000 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation with customizable pulse train and I/Q modulation (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000 is designed to be both, highly stable and reliable. The DSG3000 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Special Features
- Highest frequency: 3 GHz/6 GHz
- Amplitude accuracy: < 0.5 dB (typical)
- Output amplitude range: -130 dBm to +13 dBm
- High signal purity, phase noise: < -110 dBc/Hz @ 20 kHz (typical)
- Standard 0.5 ppm internal clock; 5 ppb high stable clock for option
- Standard AM/FM/ΦM analog modulation
- Standard pulse modulation; on/off ratio up to 80 dB; pulse train generator (optional)
- I/Q modulation and I/Q baseband output
- All modulationschemes support internal and external modulation modes
- Standard 2U height design to save rack space. Rack mount kit is available
- Standard USB/LAN/GPIB remote control interfaces. SCPI command set for remote control
- Wear-free electronic attenuator design
- Well-designed automatic flatness calibration function (Cables, attenuators, amplifiers and so on) for test systems with power meter control
-
Signal Generator
Rigol DSG3060
The DSG3060 RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for I/Q modulation and I/Q baseband output with a maximum frequency 6 GHz. Featuring a high signal purity with phase noise measuring <-110 dBc/Hz @ 20 kHz (typical) and a wide output range of -130 dBm to +13 dBm, the DSG3000 RF signal generator has standard pulse modulation with an on/off ratio of up to 80dB, with optional pulse train generator available. The DSG3000 series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface. The DSG3000 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation with customizable pulse train and I/Q modulation (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000 is designed to be both, highly stable and reliable. The DSG3000 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance. * Highest frequency: 3 GHz/6 GHz * Amplitude accuracy: < 0.5 dB (typical) * Output amplitude range: -130 dBm to +13 dBm * High signal purity, phase noise: < -110 dBc/Hz @ 20 kHz (typical) * Standard 0.5 ppm internal clock; 5 ppb high stable clock for option * Standard AM/FM/ΦM analog modulation * Standard pulse modulation; on/off ratio up to 80 dB; pulse train generator (optional) * I/Q modulation and I/Q baseband output * All modulationschemes support internal and external modulation modes * Standard 2U height design to save rack space. Rack mount kit is available * Standard USB/LAN/GPIB remote control interfaces. SCPI command set for remote control * Wear-free electronic attenuator design * Well-designed automatic flatness calibration function (Cables, attenuators, amplifiers and so on) for test systems with power meter control
-
Signal Generator
RIGOL DSG3060-IQ
The DSG3060-IQ RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for I/Q modulation and I/Q baseband output with a maximum frequency 6 GHz. Featuring a high signal purity with phase noise measuring <-110 dBc/Hz @ 20 kHz (typical) and a wide output range of -130 dBm to +13 dBm, the DSG3000 RF signal generator has standard pulse modulation with an on/off ratio of up to 80dB, with optional pulse train generator available. The DSG3000 series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG3000 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation with customizable pulse train and I/Q modulation (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000 is designed to be both, highly stable and reliable. The DSG3000 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Special Features
- Highest frequency: 3 GHz/6 GHz
- Amplitude accuracy: < 0.5 dB (typical)
- Output amplitude range: -130 dBm to +13 dBm
- High signal purity, phase noise: < -110 dBc/Hz @ 20 kHz (typical)
- Standard 0.5 ppm internal clock; 5 ppb high stable clock for option
- Standard AM/FM/ΦM analog modulation
- Standard pulse modulation; on/off ratio up to 80 dB; pulse train generator (optional)
- I/Q modulation and I/Q baseband output
- All modulationschemes support internal and external modulation modes
- Standard 2U height design to save rack space. Rack mount kit is available
- Standard USB/LAN/GPIB remote control interfaces. SCPI command set for remote control
- Wear-free electronic attenuator design
- Well-designed automatic flatness calibration function (Cables, attenuators, amplifiers and so on) for test systems with power meter control
-
Signal Generator
RIGOL DSG3065B
The DSG3000B series is a high-performance RF signal generator. It provides comprehensive modulation solutions: AM/FM/ΦM analog modulation; pulse modulation with user-defined pulse train; and I/Q modulation. All the modulations support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000B series has undergone a strict verification through the experiments in its design and
production stages to ensure its high stability and reliability. The DSG3000B series also features a clear user interface, compact size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool in various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.Features:
Highest frequency: 6.5GHz
Amplitude accuracy: <0.5 dB (typical)
Output amplitude range: -130 dBm to +27 dBm (setting range)
High signal purity, phase noise: <-116 dBc/Hz@20 kHz (typical)
Standard 1 ppm internal clock; optional 5 ppb high stable clock
Standard AM/FM/ΦM analog modulation
Support pulse modulation; on/off ratio up to 70 dB; user-defined pulse train generator
I/Q modulation and I/Q baseband output
All modulations support internal and external modulation modes
Standard 2U height design to save rack space; rack mount kit is available
Support USB/LAN/GPIB remote control; SCPI command set
Wear-free electronic attenuator design -
Signal Generator
RIGOL DSG3065B-IQ
The DSG3000B series is a high-performance RF signal generator. It provides comprehensive modulation solutions: AM/FM/ΦM analog modulation; pulse modulation with user-defined pulse train; and I/Q modulation. All the modulations support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000B series has undergone a strict verification through the experiments in its design and
production stages to ensure its high stability and reliability. The DSG3000B series also features a clear user interface, compact size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool in various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.Features:
Highest frequency: 6.5GHz
Amplitude accuracy: <0.5 dB (typical) Output amplitude range: -130 dBm to +27 dBm (setting range) High signal purity, phase noise: <-116 dBc/Hz@20 kHz (typical) Standard 1 ppm internal clock; optional 5 ppb high stable clock Standard AM/FM/ΦM analog modulation Support pulse modulation; on/off ratio up to 70 dB; user-defined pulse train generator I/Q modulation and I/Q baseband output All modulations support internal and external modulation modes Standard 2U height design to save rack space; rack mount kit is available Support USB/LAN/GPIB remote control; SCPI command set Wear-free electronic attenuator design Datasheet -
Signal Generator
Rigol DSG815
9 kHZ TO 1,5 GHz
The DSG800 series covers output frequencies from 9 kHz to 3.0GHz. The instruments provide maximum output power up to +20 dBm and low SSB phase noise -115 dBc/Hz, amplitude accuracy of +/- 0.5 dB, and frequency resolution 0.01 Hz at any frequency. An oven-controlled crystal oscillator time-base option provides < 5 ppb temperature stability and < 30 ppb/year aging stability, the most accurate and stable available in this class. For IoT and RF applications from design to debug the DSG800 series provides uncompromised RF signal generation capabilities at an unprecedented value.
-
Signal Generator
RIGOL DSG821
RF SIGNAL GENERATOR 9 kHz to 2.1 GHz
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet -
Signal Generator
RIGOL DSG821A
RF SIGNAL GENERATOR 9 kHz to 2.1 GHz with I/Q Modulation
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet -
Signal Generator
RIGOL DSG836
RF SIGNAL GENERATOR 9 kHz to 3.6 GHz
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet -
Signal Generator
RIGOL DSG836A
RF SIGNAL GENERATOR 9 kHz to 3.6 GHz with I/Q Modulation
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet -
Mainframe
Rigol M300
The M300 series data acquisition/switch system provides 5 slots to accept any combination of 11 kinds of plug-in modules, including a DMM module, multiple multiplexers, an actuator, a matrix switch module and a multifunction module. With its modular structure, it combines precision measurement capability with flexible signal connections and can provide versatile solutions for the applications that require multiple points or signals to be tested. This can be especially useful in product performance testing during the R&D phase, and automatic test during production process.
It comes with a 4.3 inch high-resolution color LCD, user-friendly interface design, easy-to-use keyboard layout as well as clear key backlight and operation prompts. The M300 is extremly flexible and easy to use. For remote control versatility, it comes with RS232, USB, LAN and GPIB interfaces standard.
Key Applications
CJC Compensated Temperature measurements
Voltage and 2-Wire Resistance
4 Wire Resistance Measurements
Current Measurements
Matrix applications for flexible signal routing
Mixed and Multifunction Applications (Digital I/O, DAC, Totalizer)
Actuator Systems (up to 300 Vrms / 2 Arms, 60 VA, without connection to the DMM)Special Features
Up to 320 switch channels per mainframe
Can run independently without PC
USB data logging
Interval scanning with storage of up to 100,000 time-stamped readings
6½ digit DMM can be inserted into any slot. It also supports multiple measurement functions, including DCV, DCI, ACV, ACI, 2WR, 4WR, PERIOD, FREQ, TEMP (Thermocouple, Thermistor and RTD) and any sensor
4.3 inch color LCD with friendly interface and built-in help system
Powerful PC control and analysis software
Standard multiple communication interface: USB Device, USB Host, GPIB, LAN(LXI Core Device 2011) and RS232
Datasheet -
Mainframe
Rigol M301
The M301 Data Acquisition System is designed for automated multichannel measurement and switch applications. This includes environmental measurements like temperature for burn in tests as well as voltage, frequency, or resistance measurements from a wide variety of sensors used from research to production test.
The M300 series data acquisition/switch system provides 5 slots to accept any combination of 11 kinds of plug-in modules, including a DMM module, multiple multiplexers, an actuator, a matrix switch module and a multifunction module. With its modular structure, it combines precision measurement capability with flexible signal connections and can provide versatile solutions for the applications that require multiple points or signals to be tested. This can be especially useful in product performance testing during the R&D phase, and automatic test during production process.
It comes with a 4.3 inch high-resolution color LCD, user-friendly interface design, easy-to-use keyboard layout as well as clear key backlight and operation prompts. The M300 is extremly flexible and easy to use. For remote control versatility, it comes with RS232, USB, LAN and GPIB interfaces standard.
Key Applications
CJC Compensated Temperature measurements
Voltage and 2-Wire Resistance
4 Wire Resistance Measurements
Current Measurements
Matrix applications for flexible signal routing
Mixed and Multifunction Applications (Digital I/O, DAC, Totalizer)
Actuator Systems (up to 300 Vrms / 2 Arms, 60 VA, without connection to the DMM)Special Features
Up to 320 switch channels per mainframe
Can run independently without PC
USB data logging
Interval scanning with storage of up to 100,000 time-stamped readings
6½ digit DMM can be inserted into any slot. It also supports multiple measurement functions, including DCV, DCI, ACV, ACI, 2WR, 4WR, PERIOD, FREQ, TEMP (Thermocouple, Thermistor and RTD) and any sensor
4.3 inch color LCD with friendly interface and built-in help system
Powerful PC control and analysis software
Standard multiple communication interface: USB Device, USB Host, GPIB, LAN(LXI Core Device 2011) and RS232
Datasheet -
Date Acquisition/Switch Unit, Mainframe
RIGOL M302
The M300 series data acquisition/switch system provides 5 slots to accept any combination of 11 kinds of plug-in modules, including a DMM module, multiple multiplexers, an actuator, a matrix switch module and a multifunction module. With its modular structure, it combines precision measurement capability with flexible signal connections and can provide versatile solutions for the applications that require multiple points or signals to be tested. This can be especially useful in product performance testing during the R&D phase, and automatic test during production process.
It comes with a 4.3 inch high-resolution color LCD, user-friendly interface design, easy-to-use keyboard layout as well as clear key backlight and operation prompts. The M300 is extremly flexible and easy to use. For remote control versatility, it comes with RS232, USB, LAN and GPIB interfaces standard.
Key Applications
- CJC Compensated Temperature measurements
- Voltage and 2-Wire Resistance
- 4 Wire Resistance Measurements
- Current Measurements
- Matrix applications for flexible signal routing
- Mixed and Multifunction Applications (Digital I/O, DAC, Totalizer)
- Actuator Systems (up to 300 Vrms / 2 Arms, 60 VA, without connection to the DMM)
Special Features
- Up to 320 switch channels per mainframe
- Can run independently without PC
- USB data logging
- Interval scanning with storage of up to 100,000 time-stamped readings
- 6½ digit DMM can be inserted into any slot. It also supports multiple measurement functions, including DCV, DCI, ACV, ACI, 2WR, 4WR, PERIOD, FREQ, TEMP (Thermocouple, Thermistor and RTD) and any sensor
- 4.3 inch color LCD with friendly interface and built-in help system
- Powerful PC control and analysis software
- Standard multiple communication interface: USB Device, USB Host, GPIB, LAN(LXI Core Device 2011) and RS232
-
Oscilloscope 4 channles
RIGOL MHO2024
The RIGOL MHO2024 is a high-resolution digital oscilloscope with a 200 MHz bandwidth and 4 analog channels, designed to meet the most advanced design, debugging, and testing requirements. Based on the latest-generation Centaurus platform, it combines 12-bit vertical resolution, deep memory, fast waveform acquisition, and comprehensive analysis tools. Its compact design and battery operation make it ideal for both laboratory and field use.
Key Features:
Bandwidth: 200 MHz (4 analog channels + 1 external trigger channel)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 2 GSa/s
Maximum memory depth: 500 Mpts (half channel), 250 Mpts (full channels)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode), 200,000 wfms/s (vector mode)
Vertical sensitivity: 100 μV/div to 10 V/div (1 MΩ), 100 μV/div to 1 V/div (50 Ω)
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
Input coupling: DC, AC, or GND
10.1″ capacitive multi-touch display (1280×800), 256-level grayscale16 standard digital channels (requires logic analyzer probe)
Standard interfaces: USB Device, USB Host, LAN (LXI), HDMI, AUX OUT
Advanced features: hardware mask test, digital voltmeter, 6-digit frequency counter, search & navigation, Bode plot (with AWG option), power analysis (optional), histogram, segmented memory, pass/fail test, and online firmware update
Standard package4 PVP2350 passive probes
AC power adapter
USB cable
Quick start guide -
Oscilloscope 4 channles
RIGOL MHO2034
The RIGOL MHO2034 is a high-resolution digital oscilloscope with a 350 MHz bandwidth and 4 analog channels, designed to meet the most advanced design, debugging, and testing requirements. Based on the latest-generation Centaurus platform, it combines 12-bit vertical resolution, deep memory, fast waveform acquisition, and comprehensive analysis tools. Its compact design and battery operation make it ideal for both laboratory and field use.
Key Features:
Bandwidth: 350 MHz (4 analog channels + 1 external trigger channel)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 2 GSa/s
Maximum memory depth: 500 Mpts (half channel), 250 Mpts (full channels)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode), 200,000 wfms/s (vector mode)
Vertical sensitivity: 100 μV/div to 10 V/div (1 MΩ), 100 μV/div to 1 V/div (50 Ω)
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
Input coupling: DC, AC, or GND
10.1″ capacitive multi-touch display (1280×800), 256-level grayscale
16 standard digital channels (requires logic analyzer probe)
Standard interfaces: USB Device, USB Host, LAN (LXI), HDMI, AUX OUT
Advanced features: hardware mask test, digital voltmeter, 6-digit frequency counter, search & navigation, Bode plot (with AWG option), power analysis (optional), histogram, segmented memory, pass/fail testing, and online firmware update
Standard package4 PVP2350 passive probes
AC power adapter
USB cable
Quick start guide -
Oscilloscope
RIGOL MHO934
The RIGOL MHO934 is a compact, high-performance mixed-signal digital oscilloscope with a bandwidth of 350 MHz and 4 analog channels. Designed to redefine the standard for instruments in this category, it offers 12-bit hardware vertical resolution for detailed signal analysis, deep memory, and extremely high waveform capture speed. Thanks to its 16 integrated digital channels (optional PLA2216 probe) and a comprehensive set of decoding options, it is the ideal solution for debugging embedded systems, testing power supplies, and for the educational sector.
Key Features
Bandwidth: 350 MHz
4 analog channels + 16 digital channels with PLA2216 probe (optional)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 4 GSa/s (single channel)
Memory depth: 100 Mpts (standard), 500 Mpts (optional)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode)
Vertical sensitivity: 200 μV/div to 10 V/div
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
7″ capacitive multi-touch display (1024×600 px), 256-level grayscale
Standard interfaces: USB Device & Host, LAN (10/100), HDMI
Advanced features: 2-channel waveform generator (50/100 MHz, optional), Bode plot analysis (with AFG option), serial decoding (RS232, I²C, SPI, CAN, LIN standard; CAN-FD, FlexRay, I²S optional) and web-based control
Standard accessories4 PVP2350 passive probes (350 MHz)
Type-C power adapter
USB cable
Ground cable -
Oscilloscope
RIGOL MHO954
The RIGOL MHO954 is a mixed-signal digital oscilloscope that offers a bandwidth of 500 MHz across 4 analog channels, making it ideal for analyzing high-speed signals. This instrument combines 12-bit hardware vertical resolution—which ensures 16 times better signal fidelity than 8-bit oscilloscopes—with ultra-deep memory and ultra-fast waveform capture. With its 16 integrated digital channels, it is perfect for complex applications such as automotive bus debugging, power electronics testing, and research and development.
Key Features
Bandwidth: 500 MHz
4 analog channels + 16 digital channels with PLA2216 probe (optional)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 4 GSa/s (single channel)
Memory depth: 100 Mpts (standard), 500 Mpts (optional)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode)
Vertical sensitivity: 200 μV/div to 10 V/div
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
7″ capacitive multi-touch display (1024×600 px), 256-level grayscale display
Standard interfaces: USB Device & Host, LAN (10/100), HDMI
Advanced features: 2-channel waveform generator (50/100 MHz, optional), Bode plot analysis (with AFG option), serial decoding (RS232, I²C, SPI, CAN, LIN standard; CAN-FD, FlexRay, I²S optional), and web-based control
Standard equipment4 RP3500A passive probes (500 MHz)
Type-C power adapter
USB cable
Ground cable -
Oscilloscope
RIGOL MHO984
The RIGOL MHO984 is a high-performance mixed-signal digital oscilloscope with an 800 MHz bandwidth across 4 analog channels, designed to tackle the most demanding challenges. It offers 12-bit hardware vertical resolution to capture even the finest signal details, exceptionally deep memory, and lightning-fast capture speed to detect rare events. The 16 integrated digital channels make it a powerful and versatile tool for advanced debugging of embedded systems, high-speed bus testing, and power electronics applications.
Key Features:
Bandwidth: 800 MHz
4 analog channels + 16 digital channels with PLA2216 probe (optional)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 4 GSa/s (single channel)
Memory depth: 100 Mpts (standard), 500 Mpts (optional)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode)
Vertical sensitivity: 200 μV/div to 10 V/div
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
7″ capacitive multi-touch display (1024×600 px), 256-level grayscale display
Standard interfaces: USB Device & Host, LAN (10/100), HDMI
Advanced features: 2-channel waveform generator (50/100 MHz, optional), Bode plot analysis (with AFG option), serial decoding (RS232, I²C, SPI, CAN, LIN standard; CAN-FD, FlexRay, I²S optional), and web-based control
Standard equipment4 RP3500A passive probes (500 MHz)
Type-C power adapter
USB cable
Ground cable -
Oscilloscope 4 channles
Rigol MSO1074Z
The Rigol MSO1074Z is a very high quality four channel digital storage oscilloscope. It features a real-time sample rate of up to 1 GSa/s and a bandwidth of 70 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls also offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO1074Z has a refresh rate of up to 30.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
Datascheet -
Oscilloscope 4 channles
Rigol MSO1074Z-S
The Rigol MSO1074Z-S is a very high quality four channel digital storage oscilloscope with built-in 25 MHz bandwidth 2CH arbitrary waveform generator. The scope features a real-time sample rate of up to 1 GSa/s and a bandwidth of 70 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls also offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO1074Z-S has a refresh rate of up to 30.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
Datascheet -
Oscilloscope 4 channles
Rigol MSO1104Z
The Rigol MSO1104Z is a very high quality four channel digital storage oscilloscope. It features a real-time sample rate of up to 1 GSa/s and a bandwidth of 100 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls also offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO1074Z has a refresh rate of up to 30.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
Datascheet -
Oscilloscope 4 channles
Rigol MSO1104Z-S
The Rigol MSO1104Z-S is a very high quality four channel digital storage oscilloscope with built-in 25 MHz bandwidth 2CH arbitrary waveform generator. The scope features a real-time sample rate of up to 1 GSa/s and a bandwidth of 100 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls also offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO1074Z-S has a refresh rate of up to 30.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
Datascheet -
Oscilloscope 2 channels
Rigol MSO2102A
The Rigol MSO2102A is a very high quality two channel digital storage oscilloscope. It features a real-time sample rate of up to 2 GSa/s and a bandwidth of 100 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages. This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO2072A has a refresh rate of up to 50.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
Datascheet
-
Spectrum Analyzer
Rigol DSA832E-TG
The Rigol DSA832E-TG is a compact and light weight Spectrum Analyzer with premium performance for portable applications. The use of digital IF (intermediate frequency) technology guarantees reliability and performance to meet the most demanding RF applications.
The very large display (20.3 cm / 8″) of the Rigol DSA832E-TG Spectrum Analyzer provides a resolution of 800×480 pixels allowing a very good overview of all its comfortable functions like Auto Tune, Auto Range, Auto Scale and Auto Couple. These functions enable the analyzer to acquire signals and match parameters automatically, compared to the manual process necessary with a traditional analyzer. The Rigol Spectrum Analyzers have a sophisticated and easy to use user interface offering multiple functions for all tasks.
The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
Datasheet€2,390.00 View Product -
Spectrum Analyzer
Rigol DSA875-TG
The Rigol DSA875-TG is a compact and light weight Spectrum Analyzer with premium performance for portable applications. The use of digital IF (intermediate frequency) technology guarantees reliability and performance to meet the most demanding RF applications. The very large display (20.3 cm / 8″) of the Rigol DSA875-TG Spectrum Analyzer provides a resolution of 800×480 pixels allowing a very good overview of all its comfortable functions like Auto Tune, Auto Range, Auto Scale and Auto Couple. These functions enable the analyzer to acquire signals and match parameters automatically, compared to the manual process necessary with a traditional analyzer. The Rigol Spectrum Analyzers have a sophisticated and easy to use user interface offering multiple functions for all tasks. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface.
Datasheet€4,990.00 View Product -
Signal Generator
RIGOL DSG3030-IQ
The DSG3030-IQ RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for I/Q modulation and I/Q baseband output with a maximum frequency 3 GHz. Featuring a high signal purity with phase noise measuring <-110 dBc/Hz @ 20 kHz (typical) and a wide output range of -130 dBm to +13 dBm, the DSG3000 RF signal generator has standard pulse modulation with an on/off ratio of up to 80dB, with optional pulse train generator available. The DSG3000 series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG3000 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation with customizable pulse train and I/Q modulation (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000 is designed to be both, highly stable and reliable. The DSG3000 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Special Features
- Highest frequency: 3 GHz/6 GHz
- Amplitude accuracy: < 0.5 dB (typical)
- Output amplitude range: -130 dBm to +13 dBm
- High signal purity, phase noise: < -110 dBc/Hz @ 20 kHz (typical)
- Standard 0.5 ppm internal clock; 5 ppb high stable clock for option
- Standard AM/FM/ΦM analog modulation
- Standard pulse modulation; on/off ratio up to 80 dB; pulse train generator (optional)
- I/Q modulation and I/Q baseband output
- All modulationschemes support internal and external modulation modes
- Standard 2U height design to save rack space. Rack mount kit is available
- Standard USB/LAN/GPIB remote control interfaces. SCPI command set for remote control
- Wear-free electronic attenuator design
- Well-designed automatic flatness calibration function (Cables, attenuators, amplifiers and so on) for test systems with power meter control
€8,490.00 View Product -
Signal Generator
Rigol DSG3060
The DSG3060 RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for I/Q modulation and I/Q baseband output with a maximum frequency 6 GHz. Featuring a high signal purity with phase noise measuring <-110 dBc/Hz @ 20 kHz (typical) and a wide output range of -130 dBm to +13 dBm, the DSG3000 RF signal generator has standard pulse modulation with an on/off ratio of up to 80dB, with optional pulse train generator available. The DSG3000 series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface. The DSG3000 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation with customizable pulse train and I/Q modulation (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000 is designed to be both, highly stable and reliable. The DSG3000 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance. * Highest frequency: 3 GHz/6 GHz * Amplitude accuracy: < 0.5 dB (typical) * Output amplitude range: -130 dBm to +13 dBm * High signal purity, phase noise: < -110 dBc/Hz @ 20 kHz (typical) * Standard 0.5 ppm internal clock; 5 ppb high stable clock for option * Standard AM/FM/ΦM analog modulation * Standard pulse modulation; on/off ratio up to 80 dB; pulse train generator (optional) * I/Q modulation and I/Q baseband output * All modulationschemes support internal and external modulation modes * Standard 2U height design to save rack space. Rack mount kit is available * Standard USB/LAN/GPIB remote control interfaces. SCPI command set for remote control * Wear-free electronic attenuator design * Well-designed automatic flatness calibration function (Cables, attenuators, amplifiers and so on) for test systems with power meter control
-
Signal Generator
RIGOL DSG3060-IQ
The DSG3060-IQ RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for I/Q modulation and I/Q baseband output with a maximum frequency 6 GHz. Featuring a high signal purity with phase noise measuring <-110 dBc/Hz @ 20 kHz (typical) and a wide output range of -130 dBm to +13 dBm, the DSG3000 RF signal generator has standard pulse modulation with an on/off ratio of up to 80dB, with optional pulse train generator available. The DSG3000 series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG3000 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation with customizable pulse train and I/Q modulation (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000 is designed to be both, highly stable and reliable. The DSG3000 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Special Features
- Highest frequency: 3 GHz/6 GHz
- Amplitude accuracy: < 0.5 dB (typical)
- Output amplitude range: -130 dBm to +13 dBm
- High signal purity, phase noise: < -110 dBc/Hz @ 20 kHz (typical)
- Standard 0.5 ppm internal clock; 5 ppb high stable clock for option
- Standard AM/FM/ΦM analog modulation
- Standard pulse modulation; on/off ratio up to 80 dB; pulse train generator (optional)
- I/Q modulation and I/Q baseband output
- All modulationschemes support internal and external modulation modes
- Standard 2U height design to save rack space. Rack mount kit is available
- Standard USB/LAN/GPIB remote control interfaces. SCPI command set for remote control
- Wear-free electronic attenuator design
- Well-designed automatic flatness calibration function (Cables, attenuators, amplifiers and so on) for test systems with power meter control
€10,490.00 View Product -
Signal Generator
RIGOL DSG3065B
The DSG3000B series is a high-performance RF signal generator. It provides comprehensive modulation solutions: AM/FM/ΦM analog modulation; pulse modulation with user-defined pulse train; and I/Q modulation. All the modulations support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000B series has undergone a strict verification through the experiments in its design and
production stages to ensure its high stability and reliability. The DSG3000B series also features a clear user interface, compact size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool in various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.Features:
Highest frequency: 6.5GHz
Amplitude accuracy: <0.5 dB (typical)
Output amplitude range: -130 dBm to +27 dBm (setting range)
High signal purity, phase noise: <-116 dBc/Hz@20 kHz (typical)
Standard 1 ppm internal clock; optional 5 ppb high stable clock
Standard AM/FM/ΦM analog modulation
Support pulse modulation; on/off ratio up to 70 dB; user-defined pulse train generator
I/Q modulation and I/Q baseband output
All modulations support internal and external modulation modes
Standard 2U height design to save rack space; rack mount kit is available
Support USB/LAN/GPIB remote control; SCPI command set
Wear-free electronic attenuator design€7,295.00 View Product -
Signal Generator
RIGOL DSG3065B-IQ
The DSG3000B series is a high-performance RF signal generator. It provides comprehensive modulation solutions: AM/FM/ΦM analog modulation; pulse modulation with user-defined pulse train; and I/Q modulation. All the modulations support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000B series has undergone a strict verification through the experiments in its design and
production stages to ensure its high stability and reliability. The DSG3000B series also features a clear user interface, compact size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool in various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.Features:
Highest frequency: 6.5GHz
Amplitude accuracy: <0.5 dB (typical) Output amplitude range: -130 dBm to +27 dBm (setting range) High signal purity, phase noise: <-116 dBc/Hz@20 kHz (typical) Standard 1 ppm internal clock; optional 5 ppb high stable clock Standard AM/FM/ΦM analog modulation Support pulse modulation; on/off ratio up to 70 dB; user-defined pulse train generator I/Q modulation and I/Q baseband output All modulations support internal and external modulation modes Standard 2U height design to save rack space; rack mount kit is available Support USB/LAN/GPIB remote control; SCPI command set Wear-free electronic attenuator design Datasheet€10,595.00 View Product -
Signal Generator
Rigol DSG815
9 kHZ TO 1,5 GHz
The DSG800 series covers output frequencies from 9 kHz to 3.0GHz. The instruments provide maximum output power up to +20 dBm and low SSB phase noise -115 dBc/Hz, amplitude accuracy of +/- 0.5 dB, and frequency resolution 0.01 Hz at any frequency. An oven-controlled crystal oscillator time-base option provides < 5 ppb temperature stability and < 30 ppb/year aging stability, the most accurate and stable available in this class. For IoT and RF applications from design to debug the DSG800 series provides uncompromised RF signal generation capabilities at an unprecedented value.
€1,875.00 View Product -
Signal Generator
RIGOL DSG821
RF SIGNAL GENERATOR 9 kHz to 2.1 GHz
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet€2,094.00 View Product -
Signal Generator
RIGOL DSG821A
RF SIGNAL GENERATOR 9 kHz to 2.1 GHz with I/Q Modulation
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet€3,394.00 View Product -
Signal Generator
RIGOL DSG836
RF SIGNAL GENERATOR 9 kHz to 3.6 GHz
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet€3,394.00 View Product -
Signal Generator
RIGOL DSG836A
RF SIGNAL GENERATOR 9 kHz to 3.6 GHz with I/Q Modulation
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet€4,694.00 View Product -
Mainframe
Rigol M300
The M300 series data acquisition/switch system provides 5 slots to accept any combination of 11 kinds of plug-in modules, including a DMM module, multiple multiplexers, an actuator, a matrix switch module and a multifunction module. With its modular structure, it combines precision measurement capability with flexible signal connections and can provide versatile solutions for the applications that require multiple points or signals to be tested. This can be especially useful in product performance testing during the R&D phase, and automatic test during production process.
It comes with a 4.3 inch high-resolution color LCD, user-friendly interface design, easy-to-use keyboard layout as well as clear key backlight and operation prompts. The M300 is extremly flexible and easy to use. For remote control versatility, it comes with RS232, USB, LAN and GPIB interfaces standard.
Key Applications
CJC Compensated Temperature measurements
Voltage and 2-Wire Resistance
4 Wire Resistance Measurements
Current Measurements
Matrix applications for flexible signal routing
Mixed and Multifunction Applications (Digital I/O, DAC, Totalizer)
Actuator Systems (up to 300 Vrms / 2 Arms, 60 VA, without connection to the DMM)Special Features
Up to 320 switch channels per mainframe
Can run independently without PC
USB data logging
Interval scanning with storage of up to 100,000 time-stamped readings
6½ digit DMM can be inserted into any slot. It also supports multiple measurement functions, including DCV, DCI, ACV, ACI, 2WR, 4WR, PERIOD, FREQ, TEMP (Thermocouple, Thermistor and RTD) and any sensor
4.3 inch color LCD with friendly interface and built-in help system
Powerful PC control and analysis software
Standard multiple communication interface: USB Device, USB Host, GPIB, LAN(LXI Core Device 2011) and RS232
Datasheet€894.00 View Product -
Mainframe
Rigol M301
The M301 Data Acquisition System is designed for automated multichannel measurement and switch applications. This includes environmental measurements like temperature for burn in tests as well as voltage, frequency, or resistance measurements from a wide variety of sensors used from research to production test.
The M300 series data acquisition/switch system provides 5 slots to accept any combination of 11 kinds of plug-in modules, including a DMM module, multiple multiplexers, an actuator, a matrix switch module and a multifunction module. With its modular structure, it combines precision measurement capability with flexible signal connections and can provide versatile solutions for the applications that require multiple points or signals to be tested. This can be especially useful in product performance testing during the R&D phase, and automatic test during production process.
It comes with a 4.3 inch high-resolution color LCD, user-friendly interface design, easy-to-use keyboard layout as well as clear key backlight and operation prompts. The M300 is extremly flexible and easy to use. For remote control versatility, it comes with RS232, USB, LAN and GPIB interfaces standard.
Key Applications
CJC Compensated Temperature measurements
Voltage and 2-Wire Resistance
4 Wire Resistance Measurements
Current Measurements
Matrix applications for flexible signal routing
Mixed and Multifunction Applications (Digital I/O, DAC, Totalizer)
Actuator Systems (up to 300 Vrms / 2 Arms, 60 VA, without connection to the DMM)Special Features
Up to 320 switch channels per mainframe
Can run independently without PC
USB data logging
Interval scanning with storage of up to 100,000 time-stamped readings
6½ digit DMM can be inserted into any slot. It also supports multiple measurement functions, including DCV, DCI, ACV, ACI, 2WR, 4WR, PERIOD, FREQ, TEMP (Thermocouple, Thermistor and RTD) and any sensor
4.3 inch color LCD with friendly interface and built-in help system
Powerful PC control and analysis software
Standard multiple communication interface: USB Device, USB Host, GPIB, LAN(LXI Core Device 2011) and RS232
Datasheet€1,290.00 View Product -
Date Acquisition/Switch Unit, Mainframe
RIGOL M302
The M300 series data acquisition/switch system provides 5 slots to accept any combination of 11 kinds of plug-in modules, including a DMM module, multiple multiplexers, an actuator, a matrix switch module and a multifunction module. With its modular structure, it combines precision measurement capability with flexible signal connections and can provide versatile solutions for the applications that require multiple points or signals to be tested. This can be especially useful in product performance testing during the R&D phase, and automatic test during production process.
It comes with a 4.3 inch high-resolution color LCD, user-friendly interface design, easy-to-use keyboard layout as well as clear key backlight and operation prompts. The M300 is extremly flexible and easy to use. For remote control versatility, it comes with RS232, USB, LAN and GPIB interfaces standard.
Key Applications
- CJC Compensated Temperature measurements
- Voltage and 2-Wire Resistance
- 4 Wire Resistance Measurements
- Current Measurements
- Matrix applications for flexible signal routing
- Mixed and Multifunction Applications (Digital I/O, DAC, Totalizer)
- Actuator Systems (up to 300 Vrms / 2 Arms, 60 VA, without connection to the DMM)
Special Features
- Up to 320 switch channels per mainframe
- Can run independently without PC
- USB data logging
- Interval scanning with storage of up to 100,000 time-stamped readings
- 6½ digit DMM can be inserted into any slot. It also supports multiple measurement functions, including DCV, DCI, ACV, ACI, 2WR, 4WR, PERIOD, FREQ, TEMP (Thermocouple, Thermistor and RTD) and any sensor
- 4.3 inch color LCD with friendly interface and built-in help system
- Powerful PC control and analysis software
- Standard multiple communication interface: USB Device, USB Host, GPIB, LAN(LXI Core Device 2011) and RS232
€1,580.00 View Product -
Oscilloscope 4 channles
RIGOL MHO2024
The RIGOL MHO2024 is a high-resolution digital oscilloscope with a 200 MHz bandwidth and 4 analog channels, designed to meet the most advanced design, debugging, and testing requirements. Based on the latest-generation Centaurus platform, it combines 12-bit vertical resolution, deep memory, fast waveform acquisition, and comprehensive analysis tools. Its compact design and battery operation make it ideal for both laboratory and field use.
Key Features:
Bandwidth: 200 MHz (4 analog channels + 1 external trigger channel)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 2 GSa/s
Maximum memory depth: 500 Mpts (half channel), 250 Mpts (full channels)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode), 200,000 wfms/s (vector mode)
Vertical sensitivity: 100 μV/div to 10 V/div (1 MΩ), 100 μV/div to 1 V/div (50 Ω)
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
Input coupling: DC, AC, or GND
10.1″ capacitive multi-touch display (1280×800), 256-level grayscale16 standard digital channels (requires logic analyzer probe)
Standard interfaces: USB Device, USB Host, LAN (LXI), HDMI, AUX OUT
Advanced features: hardware mask test, digital voltmeter, 6-digit frequency counter, search & navigation, Bode plot (with AWG option), power analysis (optional), histogram, segmented memory, pass/fail test, and online firmware update
Standard package4 PVP2350 passive probes
AC power adapter
USB cable
Quick start guide€2,394.00 View Product -
Oscilloscope 4 channles
RIGOL MHO2034
The RIGOL MHO2034 is a high-resolution digital oscilloscope with a 350 MHz bandwidth and 4 analog channels, designed to meet the most advanced design, debugging, and testing requirements. Based on the latest-generation Centaurus platform, it combines 12-bit vertical resolution, deep memory, fast waveform acquisition, and comprehensive analysis tools. Its compact design and battery operation make it ideal for both laboratory and field use.
Key Features:
Bandwidth: 350 MHz (4 analog channels + 1 external trigger channel)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 2 GSa/s
Maximum memory depth: 500 Mpts (half channel), 250 Mpts (full channels)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode), 200,000 wfms/s (vector mode)
Vertical sensitivity: 100 μV/div to 10 V/div (1 MΩ), 100 μV/div to 1 V/div (50 Ω)
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
Input coupling: DC, AC, or GND
10.1″ capacitive multi-touch display (1280×800), 256-level grayscale
16 standard digital channels (requires logic analyzer probe)
Standard interfaces: USB Device, USB Host, LAN (LXI), HDMI, AUX OUT
Advanced features: hardware mask test, digital voltmeter, 6-digit frequency counter, search & navigation, Bode plot (with AWG option), power analysis (optional), histogram, segmented memory, pass/fail testing, and online firmware update
Standard package4 PVP2350 passive probes
AC power adapter
USB cable
Quick start guide€3,294.00 View Product -
Oscilloscope
RIGOL MHO934
The RIGOL MHO934 is a compact, high-performance mixed-signal digital oscilloscope with a bandwidth of 350 MHz and 4 analog channels. Designed to redefine the standard for instruments in this category, it offers 12-bit hardware vertical resolution for detailed signal analysis, deep memory, and extremely high waveform capture speed. Thanks to its 16 integrated digital channels (optional PLA2216 probe) and a comprehensive set of decoding options, it is the ideal solution for debugging embedded systems, testing power supplies, and for the educational sector.
Key Features
Bandwidth: 350 MHz
4 analog channels + 16 digital channels with PLA2216 probe (optional)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 4 GSa/s (single channel)
Memory depth: 100 Mpts (standard), 500 Mpts (optional)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode)
Vertical sensitivity: 200 μV/div to 10 V/div
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
7″ capacitive multi-touch display (1024×600 px), 256-level grayscale
Standard interfaces: USB Device & Host, LAN (10/100), HDMI
Advanced features: 2-channel waveform generator (50/100 MHz, optional), Bode plot analysis (with AFG option), serial decoding (RS232, I²C, SPI, CAN, LIN standard; CAN-FD, FlexRay, I²S optional) and web-based control
Standard accessories4 PVP2350 passive probes (350 MHz)
Type-C power adapter
USB cable
Ground cable€814.00 View Product -
Oscilloscope
RIGOL MHO954
The RIGOL MHO954 is a mixed-signal digital oscilloscope that offers a bandwidth of 500 MHz across 4 analog channels, making it ideal for analyzing high-speed signals. This instrument combines 12-bit hardware vertical resolution—which ensures 16 times better signal fidelity than 8-bit oscilloscopes—with ultra-deep memory and ultra-fast waveform capture. With its 16 integrated digital channels, it is perfect for complex applications such as automotive bus debugging, power electronics testing, and research and development.
Key Features
Bandwidth: 500 MHz
4 analog channels + 16 digital channels with PLA2216 probe (optional)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 4 GSa/s (single channel)
Memory depth: 100 Mpts (standard), 500 Mpts (optional)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode)
Vertical sensitivity: 200 μV/div to 10 V/div
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
7″ capacitive multi-touch display (1024×600 px), 256-level grayscale display
Standard interfaces: USB Device & Host, LAN (10/100), HDMI
Advanced features: 2-channel waveform generator (50/100 MHz, optional), Bode plot analysis (with AFG option), serial decoding (RS232, I²C, SPI, CAN, LIN standard; CAN-FD, FlexRay, I²S optional), and web-based control
Standard equipment4 RP3500A passive probes (500 MHz)
Type-C power adapter
USB cable
Ground cable€914.00 View Product -
Oscilloscope
RIGOL MHO984
The RIGOL MHO984 is a high-performance mixed-signal digital oscilloscope with an 800 MHz bandwidth across 4 analog channels, designed to tackle the most demanding challenges. It offers 12-bit hardware vertical resolution to capture even the finest signal details, exceptionally deep memory, and lightning-fast capture speed to detect rare events. The 16 integrated digital channels make it a powerful and versatile tool for advanced debugging of embedded systems, high-speed bus testing, and power electronics applications.
Key Features:
Bandwidth: 800 MHz
4 analog channels + 16 digital channels with PLA2216 probe (optional)
Vertical resolution: 12 bits (up to 16 bits in high-resolution mode)
Real-time sampling rate: up to 4 GSa/s (single channel)
Memory depth: 100 Mpts (standard), 500 Mpts (optional)
Waveform acquisition rate: up to 1,000,000 wfms/s (record mode)
Vertical sensitivity: 200 μV/div to 10 V/div
Input impedance: 1 MΩ ±1%, 50 Ω ±1%
7″ capacitive multi-touch display (1024×600 px), 256-level grayscale display
Standard interfaces: USB Device & Host, LAN (10/100), HDMI
Advanced features: 2-channel waveform generator (50/100 MHz, optional), Bode plot analysis (with AFG option), serial decoding (RS232, I²C, SPI, CAN, LIN standard; CAN-FD, FlexRay, I²S optional), and web-based control
Standard equipment4 RP3500A passive probes (500 MHz)
Type-C power adapter
USB cable
Ground cable€1,004.00 View Product -
Oscilloscope 4 channles
Rigol MSO1074Z
The Rigol MSO1074Z is a very high quality four channel digital storage oscilloscope. It features a real-time sample rate of up to 1 GSa/s and a bandwidth of 70 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls also offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO1074Z has a refresh rate of up to 30.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
Datascheet€679.00 View Product -
Oscilloscope 4 channles
Rigol MSO1074Z-S
The Rigol MSO1074Z-S is a very high quality four channel digital storage oscilloscope with built-in 25 MHz bandwidth 2CH arbitrary waveform generator. The scope features a real-time sample rate of up to 1 GSa/s and a bandwidth of 70 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls also offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO1074Z-S has a refresh rate of up to 30.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
Datascheet€869.00 View Product -
Oscilloscope 4 channles
Rigol MSO1104Z
The Rigol MSO1104Z is a very high quality four channel digital storage oscilloscope. It features a real-time sample rate of up to 1 GSa/s and a bandwidth of 100 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls also offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO1074Z has a refresh rate of up to 30.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
Datascheet€799.00 View Product -
Oscilloscope 4 channles
Rigol MSO1104Z-S
The Rigol MSO1104Z-S is a very high quality four channel digital storage oscilloscope with built-in 25 MHz bandwidth 2CH arbitrary waveform generator. The scope features a real-time sample rate of up to 1 GSa/s and a bandwidth of 100 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls also offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO1074Z-S has a refresh rate of up to 30.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
Datascheet€999.00 View Product -
Oscilloscope 2 channels
Rigol MSO2102A
The Rigol MSO2102A is a very high quality two channel digital storage oscilloscope. It features a real-time sample rate of up to 2 GSa/s and a bandwidth of 100 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages. This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The MSO2072A has a refresh rate of up to 50.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
Datascheet€905.00 View Product
