RIGOL DSG3060-IQ

The DSG3060-IQ RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for I/Q modulation and I/Q baseband output with a maximum frequency 6 GHz. Featuring a high signal purity with phase noise measuring <-110 dBc/Hz @ 20 kHz (typical) and a wide output range of -130 dBm to +13 dBm, the DSG3000 RF signal generator has standard pulse modulation with an on/off ratio of up to 80dB, with optional pulse train generator available. The DSG3000 series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.

The DSG3000 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation with customizable pulse train and I/Q modulation (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000 is designed to be both, highly stable and reliable. The DSG3000 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.

Special Features

  • Highest frequency: 3 GHz/6 GHz
  • Amplitude accuracy: < 0.5 dB (typical)
  • Output amplitude range: -130 dBm to +13 dBm
  • High signal purity, phase noise: < -110 dBc/Hz @ 20 kHz (typical)
  • Standard 0.5 ppm internal clock; 5 ppb high stable clock for option
  • Standard AM/FM/ΦM analog modulation
  • Standard pulse modulation; on/off ratio up to 80 dB; pulse train generator (optional)
  • I/Q modulation and I/Q baseband output
  • All modulationschemes support internal and external modulation modes
  • Standard 2U height design to save rack space. Rack mount kit is available
  • Standard USB/LAN/GPIB remote control interfaces. SCPI command set for remote control
  • Wear-free electronic attenuator design
  • Well-designed automatic flatness calibration function (Cables, attenuators, amplifiers and so on) for test systems with power meter control

Datasheet

10,490.00

Brand

Rigol
