Showing all 8 results
-
Mainframe
HP-Agilent/Keysight 66000A
The Hp 66000A modular power system simplifies test-system assembly, cabling, programming, debugging and operation. The 66000A is 4 U, 8 slot mainframe that accepts 1 to 8 modules below in any combination. Modules are ordered separately.
Features:High density: eight slots in 7 inches of rack space
Output sequencing
Low ripple and noise
High-accuracy read-back of voltage and current over GPIB
Standard Commands for Programmable Instruments (SCPI)
Optional keyboard and display unit
Serial link to connect two mainframes at one GPIB address
Optional isolation and polarity-reversal relays
Built-in self-test
DatasheetSKU: n/a -
Mainframe
Rigol M300
The M300 series data acquisition/switch system provides 5 slots to accept any combination of 11 kinds of plug-in modules, including a DMM module, multiple multiplexers, an actuator, a matrix switch module and a multifunction module. With its modular structure, it combines precision measurement capability with flexible signal connections and can provide versatile solutions for the applications that require multiple points or signals to be tested. This can be especially useful in product performance testing during the R&D phase, and automatic test during production process.
It comes with a 4.3 inch high-resolution color LCD, user-friendly interface design, easy-to-use keyboard layout as well as clear key backlight and operation prompts. The M300 is extremly flexible and easy to use. For remote control versatility, it comes with RS232, USB, LAN and GPIB interfaces standard.
Key Applications
CJC Compensated Temperature measurements
Voltage and 2-Wire Resistance
4 Wire Resistance Measurements
Current Measurements
Matrix applications for flexible signal routing
Mixed and Multifunction Applications (Digital I/O, DAC, Totalizer)
Actuator Systems (up to 300 Vrms / 2 Arms, 60 VA, without connection to the DMM)Special Features
Up to 320 switch channels per mainframe
Can run independently without PC
USB data logging
Interval scanning with storage of up to 100,000 time-stamped readings
6½ digit DMM can be inserted into any slot. It also supports multiple measurement functions, including DCV, DCI, ACV, ACI, 2WR, 4WR, PERIOD, FREQ, TEMP (Thermocouple, Thermistor and RTD) and any sensor
4.3 inch color LCD with friendly interface and built-in help system
Powerful PC control and analysis software
Standard multiple communication interface: USB Device, USB Host, GPIB, LAN(LXI Core Device 2011) and RS232
DatasheetSKU: 831€899.00 View Product -
Mainframe
Rigol M301
The M301 Data Acquisition System is designed for automated multichannel measurement and switch applications. This includes environmental measurements like temperature for burn in tests as well as voltage, frequency, or resistance measurements from a wide variety of sensors used from research to production test.
The M300 series data acquisition/switch system provides 5 slots to accept any combination of 11 kinds of plug-in modules, including a DMM module, multiple multiplexers, an actuator, a matrix switch module and a multifunction module. With its modular structure, it combines precision measurement capability with flexible signal connections and can provide versatile solutions for the applications that require multiple points or signals to be tested. This can be especially useful in product performance testing during the R&D phase, and automatic test during production process.
It comes with a 4.3 inch high-resolution color LCD, user-friendly interface design, easy-to-use keyboard layout as well as clear key backlight and operation prompts. The M300 is extremly flexible and easy to use. For remote control versatility, it comes with RS232, USB, LAN and GPIB interfaces standard.
Key Applications
CJC Compensated Temperature measurements
Voltage and 2-Wire Resistance
4 Wire Resistance Measurements
Current Measurements
Matrix applications for flexible signal routing
Mixed and Multifunction Applications (Digital I/O, DAC, Totalizer)
Actuator Systems (up to 300 Vrms / 2 Arms, 60 VA, without connection to the DMM)Special Features
Up to 320 switch channels per mainframe
Can run independently without PC
USB data logging
Interval scanning with storage of up to 100,000 time-stamped readings
6½ digit DMM can be inserted into any slot. It also supports multiple measurement functions, including DCV, DCI, ACV, ACI, 2WR, 4WR, PERIOD, FREQ, TEMP (Thermocouple, Thermistor and RTD) and any sensor
4.3 inch color LCD with friendly interface and built-in help system
Powerful PC control and analysis software
Standard multiple communication interface: USB Device, USB Host, GPIB, LAN(LXI Core Device 2011) and RS232
DatasheetSKU: 832€1,295.00 View Product -
Date Acquisition/Switch Unit, Mainframe
RIGOL M302
The M300 series data acquisition/switch system provides 5 slots to accept any combination of 11 kinds of plug-in modules, including a DMM module, multiple multiplexers, an actuator, a matrix switch module and a multifunction module. With its modular structure, it combines precision measurement capability with flexible signal connections and can provide versatile solutions for the applications that require multiple points or signals to be tested. This can be especially useful in product performance testing during the R&D phase, and automatic test during production process.
It comes with a 4.3 inch high-resolution color LCD, user-friendly interface design, easy-to-use keyboard layout as well as clear key backlight and operation prompts. The M300 is extremly flexible and easy to use. For remote control versatility, it comes with RS232, USB, LAN and GPIB interfaces standard.
Key Applications
- CJC Compensated Temperature measurements
- Voltage and 2-Wire Resistance
- 4 Wire Resistance Measurements
- Current Measurements
- Matrix applications for flexible signal routing
- Mixed and Multifunction Applications (Digital I/O, DAC, Totalizer)
- Actuator Systems (up to 300 Vrms / 2 Arms, 60 VA, without connection to the DMM)
Special Features
- Up to 320 switch channels per mainframe
- Can run independently without PC
- USB data logging
- Interval scanning with storage of up to 100,000 time-stamped readings
- 6½ digit DMM can be inserted into any slot. It also supports multiple measurement functions, including DCV, DCI, ACV, ACI, 2WR, 4WR, PERIOD, FREQ, TEMP (Thermocouple, Thermistor and RTD) and any sensor
- 4.3 inch color LCD with friendly interface and built-in help system
- Powerful PC control and analysis software
- Standard multiple communication interface: USB Device, USB Host, GPIB, LAN(LXI Core Device 2011) and RS232
SKU: 920€1,585.00 View Product -
Mainframe
Tektronix TM502A
Tektronix TM502A Power Module, 2 Compartment
The TM502A power module accepts up to 2 single width TM500 series modules.
Features:Compartments: 2
Compatibility: TM500 series plug-ins
100, 110, 120, 200, 240 Vac; 48-400 Hz operation
Weight: 9 lb; Size: 140 mm (5.5 in)H x 145 mm (5.7 in)W x 407 mm (16.0 in)D
DatasheetSKU: 432 -
Current Probe Amplifiter, Mainframe
TEKTRONIX TM502A+AM503+A6303
Tektronix AM503 Current Probe Amplifier
The AM503 Current Probe Amplifier allows display of current on any oscilloscope having 10 mV/div sensitivity, 50 ohm or 1 megohm input, and at least 100 MHz bandwidth. It is compatible with A6302, A6303, P6302, P6303 current probes. It requires a TM500 or TM5000 series mainframe for operation.
Features:Allows for current display on any oscilloscope
Maximum input current: 20A for 6302; 100A for 6303
Bandwidth: >50 MHz 6302; >15 MHz 6303
Rise time: <7 ns 6302; <23 ns 6303
Deflection factor: 1 mA/div to 5 A/div for 6302; 20 mA/div to 50 A/div for 6303
Weight: 4 lb; Size: single width moduleSKU: n/a
-
