Showing 31–40 of 40 results
-
Signal Generator
RIGOL DSG3065B
The DSG3000B series is a high-performance RF signal generator. It provides comprehensive modulation solutions: AM/FM/ΦM analog modulation; pulse modulation with user-defined pulse train; and I/Q modulation. All the modulations support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000B series has undergone a strict verification through the experiments in its design and
production stages to ensure its high stability and reliability. The DSG3000B series also features a clear user interface, compact size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool in various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.Features:
Highest frequency: 6.5GHz
Amplitude accuracy: <0.5 dB (typical)
Output amplitude range: -130 dBm to +27 dBm (setting range)
High signal purity, phase noise: <-116 dBc/Hz@20 kHz (typical)
Standard 1 ppm internal clock; optional 5 ppb high stable clock
Standard AM/FM/ΦM analog modulation
Support pulse modulation; on/off ratio up to 70 dB; user-defined pulse train generator
I/Q modulation and I/Q baseband output
All modulations support internal and external modulation modes
Standard 2U height design to save rack space; rack mount kit is available
Support USB/LAN/GPIB remote control; SCPI command set
Wear-free electronic attenuator designSKU: n/a€7,295.00 View Product -
Signal Generator
RIGOL DSG3065B-IQ
The DSG3000B series is a high-performance RF signal generator. It provides comprehensive modulation solutions: AM/FM/ΦM analog modulation; pulse modulation with user-defined pulse train; and I/Q modulation. All the modulations support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000B series has undergone a strict verification through the experiments in its design and
production stages to ensure its high stability and reliability. The DSG3000B series also features a clear user interface, compact size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool in various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.Features:
Highest frequency: 6.5GHz
Amplitude accuracy: <0.5 dB (typical) Output amplitude range: -130 dBm to +27 dBm (setting range) High signal purity, phase noise: <-116 dBc/Hz@20 kHz (typical) Standard 1 ppm internal clock; optional 5 ppb high stable clock Standard AM/FM/ΦM analog modulation Support pulse modulation; on/off ratio up to 70 dB; user-defined pulse train generator I/Q modulation and I/Q baseband output All modulations support internal and external modulation modes Standard 2U height design to save rack space; rack mount kit is available Support USB/LAN/GPIB remote control; SCPI command set Wear-free electronic attenuator design DatasheetSKU: n/a€10,595.00 View Product -
Signal Generator
Rigol DSG815
9 kHZ TO 1,5 GHz
The DSG800 series covers output frequencies from 9 kHz to 3.0GHz. The instruments provide maximum output power up to +20 dBm and low SSB phase noise -115 dBc/Hz, amplitude accuracy of +/- 0.5 dB, and frequency resolution 0.01 Hz at any frequency. An oven-controlled crystal oscillator time-base option provides < 5 ppb temperature stability and < 30 ppb/year aging stability, the most accurate and stable available in this class. For IoT and RF applications from design to debug the DSG800 series provides uncompromised RF signal generation capabilities at an unprecedented value.
SKU: 918€1,875.00 View Product -
Signal Generator
RIGOL DSG821
RF SIGNAL GENERATOR 9 kHz to 2.1 GHz
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
DatasheetSKU: n/a€2,094.00 View Product -
Signal Generator
RIGOL DSG821A
RF SIGNAL GENERATOR 9 kHz to 2.1 GHz with I/Q Modulation
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
DatasheetSKU: n/a€3,394.00 View Product -
Signal Generator
RIGOL DSG836
RF SIGNAL GENERATOR 9 kHz to 3.6 GHz
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
DatasheetSKU: n/a€3,394.00 View Product -
Signal Generator
RIGOL DSG836A
RF SIGNAL GENERATOR 9 kHz to 3.6 GHz with I/Q Modulation
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
DatasheetSKU: n/a€4,694.00 View Product -
Signal Generator
ROHDE & SCHWARZ SML03
he RSSML signal generators offer all the functionalities of a state-of-the-art, general-purpose signal generators: wide frequency range, large variety of modulation functions and high reliability, at an extremely attractive price. It is ideal as a flexible signal source in automatic test systems in development, servicing or production.
FEATURESSSB phase noise: <- 122 dBc (1Hz) (at f=1GHZ, .f - 20kHz) High level accuracy (deviation – 120 dBm)
High reliability through electronic attenuator
Digital frequency and level sweep
Precise DC-coupled FM enables usage as accurage VCO
Optional pulse modulator with integrated pulse generator
Three year calibration cycle
Unit Size: 427 mm high x 88 mm wide x 450 mm deep ; < 8.5 kg. DatasheetSKU: n/a -
Signal Generator
ROHDE & SCHWARZ SMY01
Signal generators of the Rohde & Schwarz SMY family from Rohde&Schwarz are cost-effective instruments for testing AM, FM and jM receivers as well as for component measurements.
Designed exclusively for the main applications of signal generators by cutting out the unnecessaries, R&S SMY features an outstanding price/performance ratio. Thanks to its comprehensive basic features and excellent signal characteristics, it is an economical solution for universal use in lab, production and servicing environments.
Level range -140 dBm to +13 dBm (19 dBm overrange) , sufficient even for receivers of highest sensitivity
High level accuracy and low RF leakage allowing accurate and undegraded sensitivity measurements
FM-DC with high accuracy of carrier frequency for testing pagers and receivers fitted with digital squelches
Low SSB phase noise( -114 dBc/Hz) and high spurious rejection for all in-channel and blocking measurements
Low residual FM affording ample of margin for S/N measurements
Modulation generator 1 Hz to 500 kHz for modulation frequency response measurements
Stereo channel separation of 50 dB and low harmonic distortion for testing FM stereo receivers
Non-interrupting level setting over a range of 20 dB for reproducible measurement of squelch hysteresis
Frequency resolution 1 Hz, suitable also for narrowband test items
FM-DC, deviation up to 20 MHz for VCO simulation
FM bandwidth 2 MHz for fast FSK and telemetry applications
High output level up to 19 dBm (25 dBm with option R&S SMY-B40) for component and overdrive testing
AF synthesizer 1 Hz to 500 kHz, separate use as AF signal source for external applications possible, eg recording of AF frequency response
Remote-control interface IEC625/IEEE488 for use in automatic test systems
RF sweep
Sequence function and SEQ input for semi-automatic useSKU: n/a
-
Signal Generator
RIGOL DSG3065B
The DSG3000B series is a high-performance RF signal generator. It provides comprehensive modulation solutions: AM/FM/ΦM analog modulation; pulse modulation with user-defined pulse train; and I/Q modulation. All the modulations support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000B series has undergone a strict verification through the experiments in its design and
production stages to ensure its high stability and reliability. The DSG3000B series also features a clear user interface, compact size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool in various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.Features:
Highest frequency: 6.5GHz
Amplitude accuracy: <0.5 dB (typical)
Output amplitude range: -130 dBm to +27 dBm (setting range)
High signal purity, phase noise: <-116 dBc/Hz@20 kHz (typical)
Standard 1 ppm internal clock; optional 5 ppb high stable clock
Standard AM/FM/ΦM analog modulation
Support pulse modulation; on/off ratio up to 70 dB; user-defined pulse train generator
I/Q modulation and I/Q baseband output
All modulations support internal and external modulation modes
Standard 2U height design to save rack space; rack mount kit is available
Support USB/LAN/GPIB remote control; SCPI command set
Wear-free electronic attenuator design -
Signal Generator
RIGOL DSG3065B-IQ
The DSG3000B series is a high-performance RF signal generator. It provides comprehensive modulation solutions: AM/FM/ΦM analog modulation; pulse modulation with user-defined pulse train; and I/Q modulation. All the modulations support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000B series has undergone a strict verification through the experiments in its design and
production stages to ensure its high stability and reliability. The DSG3000B series also features a clear user interface, compact size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool in various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.Features:
Highest frequency: 6.5GHz
Amplitude accuracy: <0.5 dB (typical) Output amplitude range: -130 dBm to +27 dBm (setting range) High signal purity, phase noise: <-116 dBc/Hz@20 kHz (typical) Standard 1 ppm internal clock; optional 5 ppb high stable clock Standard AM/FM/ΦM analog modulation Support pulse modulation; on/off ratio up to 70 dB; user-defined pulse train generator I/Q modulation and I/Q baseband output All modulations support internal and external modulation modes Standard 2U height design to save rack space; rack mount kit is available Support USB/LAN/GPIB remote control; SCPI command set Wear-free electronic attenuator design Datasheet -
Signal Generator
Rigol DSG815
9 kHZ TO 1,5 GHz
The DSG800 series covers output frequencies from 9 kHz to 3.0GHz. The instruments provide maximum output power up to +20 dBm and low SSB phase noise -115 dBc/Hz, amplitude accuracy of +/- 0.5 dB, and frequency resolution 0.01 Hz at any frequency. An oven-controlled crystal oscillator time-base option provides < 5 ppb temperature stability and < 30 ppb/year aging stability, the most accurate and stable available in this class. For IoT and RF applications from design to debug the DSG800 series provides uncompromised RF signal generation capabilities at an unprecedented value.
-
Signal Generator
RIGOL DSG821
RF SIGNAL GENERATOR 9 kHz to 2.1 GHz
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet -
Signal Generator
RIGOL DSG821A
RF SIGNAL GENERATOR 9 kHz to 2.1 GHz with I/Q Modulation
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet -
Signal Generator
RIGOL DSG836
RF SIGNAL GENERATOR 9 kHz to 3.6 GHz
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet -
Signal Generator
RIGOL DSG836A
RF SIGNAL GENERATOR 9 kHz to 3.6 GHz with I/Q Modulation
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet -
Signal Generator
ROHDE & SCHWARZ SML03
he RSSML signal generators offer all the functionalities of a state-of-the-art, general-purpose signal generators: wide frequency range, large variety of modulation functions and high reliability, at an extremely attractive price. It is ideal as a flexible signal source in automatic test systems in development, servicing or production.
FEATURESSSB phase noise: <- 122 dBc (1Hz) (at f=1GHZ, .f - 20kHz) High level accuracy (deviation – 120 dBm)
High reliability through electronic attenuator
Digital frequency and level sweep
Precise DC-coupled FM enables usage as accurage VCO
Optional pulse modulator with integrated pulse generator
Three year calibration cycle
Unit Size: 427 mm high x 88 mm wide x 450 mm deep ; < 8.5 kg. Datasheet -
Signal Generator
ROHDE & SCHWARZ SMY01
Signal generators of the Rohde & Schwarz SMY family from Rohde&Schwarz are cost-effective instruments for testing AM, FM and jM receivers as well as for component measurements.
Designed exclusively for the main applications of signal generators by cutting out the unnecessaries, R&S SMY features an outstanding price/performance ratio. Thanks to its comprehensive basic features and excellent signal characteristics, it is an economical solution for universal use in lab, production and servicing environments.
Level range -140 dBm to +13 dBm (19 dBm overrange) , sufficient even for receivers of highest sensitivity
High level accuracy and low RF leakage allowing accurate and undegraded sensitivity measurements
FM-DC with high accuracy of carrier frequency for testing pagers and receivers fitted with digital squelches
Low SSB phase noise( -114 dBc/Hz) and high spurious rejection for all in-channel and blocking measurements
Low residual FM affording ample of margin for S/N measurements
Modulation generator 1 Hz to 500 kHz for modulation frequency response measurements
Stereo channel separation of 50 dB and low harmonic distortion for testing FM stereo receivers
Non-interrupting level setting over a range of 20 dB for reproducible measurement of squelch hysteresis
Frequency resolution 1 Hz, suitable also for narrowband test items
FM-DC, deviation up to 20 MHz for VCO simulation
FM bandwidth 2 MHz for fast FSK and telemetry applications
High output level up to 19 dBm (25 dBm with option R&S SMY-B40) for component and overdrive testing
AF synthesizer 1 Hz to 500 kHz, separate use as AF signal source for external applications possible, eg recording of AF frequency response
Remote-control interface IEC625/IEEE488 for use in automatic test systems
RF sweep
Sequence function and SEQ input for semi-automatic use
-
Signal Generator
RIGOL DSG3065B
The DSG3000B series is a high-performance RF signal generator. It provides comprehensive modulation solutions: AM/FM/ΦM analog modulation; pulse modulation with user-defined pulse train; and I/Q modulation. All the modulations support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000B series has undergone a strict verification through the experiments in its design and
production stages to ensure its high stability and reliability. The DSG3000B series also features a clear user interface, compact size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool in various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.Features:
Highest frequency: 6.5GHz
Amplitude accuracy: <0.5 dB (typical)
Output amplitude range: -130 dBm to +27 dBm (setting range)
High signal purity, phase noise: <-116 dBc/Hz@20 kHz (typical)
Standard 1 ppm internal clock; optional 5 ppb high stable clock
Standard AM/FM/ΦM analog modulation
Support pulse modulation; on/off ratio up to 70 dB; user-defined pulse train generator
I/Q modulation and I/Q baseband output
All modulations support internal and external modulation modes
Standard 2U height design to save rack space; rack mount kit is available
Support USB/LAN/GPIB remote control; SCPI command set
Wear-free electronic attenuator design€7,295.00 View Product -
Signal Generator
RIGOL DSG3065B-IQ
The DSG3000B series is a high-performance RF signal generator. It provides comprehensive modulation solutions: AM/FM/ΦM analog modulation; pulse modulation with user-defined pulse train; and I/Q modulation. All the modulations support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG3000B series has undergone a strict verification through the experiments in its design and
production stages to ensure its high stability and reliability. The DSG3000B series also features a clear user interface, compact size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool in various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.Features:
Highest frequency: 6.5GHz
Amplitude accuracy: <0.5 dB (typical) Output amplitude range: -130 dBm to +27 dBm (setting range) High signal purity, phase noise: <-116 dBc/Hz@20 kHz (typical) Standard 1 ppm internal clock; optional 5 ppb high stable clock Standard AM/FM/ΦM analog modulation Support pulse modulation; on/off ratio up to 70 dB; user-defined pulse train generator I/Q modulation and I/Q baseband output All modulations support internal and external modulation modes Standard 2U height design to save rack space; rack mount kit is available Support USB/LAN/GPIB remote control; SCPI command set Wear-free electronic attenuator design Datasheet€10,595.00 View Product -
Signal Generator
Rigol DSG815
9 kHZ TO 1,5 GHz
The DSG800 series covers output frequencies from 9 kHz to 3.0GHz. The instruments provide maximum output power up to +20 dBm and low SSB phase noise -115 dBc/Hz, amplitude accuracy of +/- 0.5 dB, and frequency resolution 0.01 Hz at any frequency. An oven-controlled crystal oscillator time-base option provides < 5 ppb temperature stability and < 30 ppb/year aging stability, the most accurate and stable available in this class. For IoT and RF applications from design to debug the DSG800 series provides uncompromised RF signal generation capabilities at an unprecedented value.
€1,875.00 View Product -
Signal Generator
RIGOL DSG821
RF SIGNAL GENERATOR 9 kHz to 2.1 GHz
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet€2,094.00 View Product -
Signal Generator
RIGOL DSG821A
RF SIGNAL GENERATOR 9 kHz to 2.1 GHz with I/Q Modulation
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet€3,394.00 View Product -
Signal Generator
RIGOL DSG836
RF SIGNAL GENERATOR 9 kHz to 3.6 GHz
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet€3,394.00 View Product -
Signal Generator
RIGOL DSG836A
RF SIGNAL GENERATOR 9 kHz to 3.6 GHz with I/Q Modulation
The DSG800(A) RF signal generator offers standard AM/FM/ØM analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available.
The DSG800(A) series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
The DSG800 series is a high-performance RF signal generator. It provides comprehensive modulation solutions such as: Pulse modulation (optional) with customizable pulse train (optional) and standard AM/FM/FM analog modulation. All modulation schemes support internal and external modulation sources. In addition, to meet the demands of production environments, the DSG800 is designed to be both, highly stable and reliable.
The DSG800 series also features a clear user interface, small size and light weight. It is easy to operate and can output stable, precise and pure signals. It is an ideal tool for various fields such as communication, computers, instrumentation, R&D, education, production and maintenance.
Highly cost-effective economical RF signal generator
* Up to -112 dBc/Hz (typical) phase noise
* Up to +20 dBm (typical) maximum output power
* Higher level of amplitude accuracy, up to 0.5 dB (typical)
* Superb signal stability
Functions almost matching those of high-level RF signal generators
* Flexible frequency and amplitude sweep functions
* Complete AM/FM/ØM analog modulation functions
* Standard LF output function
* Powerful pulse modulation function
* Open vector modulation function
* System flatness calibration function
* Simple and easy to operate
Special design ensuring its reliability and durability
* Use electronic attenuator to avoid wearing
* Specially designed protection functions
* Digital ALC circuit
* Simple structure
Smallest in size among the like products
* Occupy the least workbench space
* Occupy less rack space
* Light weight; the handle offers comfortable grip
Special Features
* Highest frequency: 1.5 GHz / 3.6 GHz
* Amplitude accuracy: < 0.5 dB (typical)
* Output amplitude range: -110 dBm to +13 dBm
* High signal purity, phase noise: < -105 dBc/Hz @ 20 kHz (typical)
* Standard 2 ppm internal clock; 5 ppb high stable clock for option
* Standard AM/FM/ΦM analog modulation
* Optional pulse modulation; on/off ratio up to 70 dB
* Pulse Train Generator (optional)
* All modulationschemes support internal and external modulation modes
* Standard 2U height design to save rack space. Rack mount kit is available
* Standard USB/LAN remote control interfaces. SCPI command set for remote control
* Wear-free electronic attenuator design
Datasheet€4,694.00 View Product -
Signal Generator
ROHDE & SCHWARZ SML03
he RSSML signal generators offer all the functionalities of a state-of-the-art, general-purpose signal generators: wide frequency range, large variety of modulation functions and high reliability, at an extremely attractive price. It is ideal as a flexible signal source in automatic test systems in development, servicing or production.
FEATURESSSB phase noise: <- 122 dBc (1Hz) (at f=1GHZ, .f - 20kHz) High level accuracy (deviation – 120 dBm)
High reliability through electronic attenuator
Digital frequency and level sweep
Precise DC-coupled FM enables usage as accurage VCO
Optional pulse modulator with integrated pulse generator
Three year calibration cycle
Unit Size: 427 mm high x 88 mm wide x 450 mm deep ; < 8.5 kg. Datasheet -
Signal Generator
ROHDE & SCHWARZ SMY01
Signal generators of the Rohde & Schwarz SMY family from Rohde&Schwarz are cost-effective instruments for testing AM, FM and jM receivers as well as for component measurements.
Designed exclusively for the main applications of signal generators by cutting out the unnecessaries, R&S SMY features an outstanding price/performance ratio. Thanks to its comprehensive basic features and excellent signal characteristics, it is an economical solution for universal use in lab, production and servicing environments.
Level range -140 dBm to +13 dBm (19 dBm overrange) , sufficient even for receivers of highest sensitivity
High level accuracy and low RF leakage allowing accurate and undegraded sensitivity measurements
FM-DC with high accuracy of carrier frequency for testing pagers and receivers fitted with digital squelches
Low SSB phase noise( -114 dBc/Hz) and high spurious rejection for all in-channel and blocking measurements
Low residual FM affording ample of margin for S/N measurements
Modulation generator 1 Hz to 500 kHz for modulation frequency response measurements
Stereo channel separation of 50 dB and low harmonic distortion for testing FM stereo receivers
Non-interrupting level setting over a range of 20 dB for reproducible measurement of squelch hysteresis
Frequency resolution 1 Hz, suitable also for narrowband test items
FM-DC, deviation up to 20 MHz for VCO simulation
FM bandwidth 2 MHz for fast FSK and telemetry applications
High output level up to 19 dBm (25 dBm with option R&S SMY-B40) for component and overdrive testing
AF synthesizer 1 Hz to 500 kHz, separate use as AF signal source for external applications possible, eg recording of AF frequency response
Remote-control interface IEC625/IEEE488 for use in automatic test systems
RF sweep
Sequence function and SEQ input for semi-automatic use
