Lukey 850D is a hot air single-channel soldering/desoldering station for working with SMD, QFP, PLCC, SOP, SOIC, CHIP, BGA components.

· Ultra-fast heating up to the required temperature.

· Temperature and blast control of the hot air station.

· Temperature control of the air stream by means of digital display and microprocessor system using “UP” and “DOWN” buttons with +/- 1C accuracy.

· Set automatic interrupting time at 30, 60 minutes and permanently (Sleep Timer) to prolong life time of the heating element.

· Station is completed with 4 exchangeable tips with different diameter to ensure universal application of the equipment.

· Heating element type: metallic incandescent wire

· Compressor type: diaphragm pump

· Airstream: 23 l/min (max)

· Operating surface resistivity on the

· Light and handy hot air station handle.

· Digital indication of real and fixed temperature

· Operating temperature range of hot air station: 100 – 420C “case”: up to 2Ohm

· ”Case” – to – operating surface potential difference: up to 2mV

· Galvanic isolation

· Made from anti-static materials.

· Hot air station power – 350W

· Automatic retroactive temperature control, holding up of constant temperature, irrespective of airspeed.

· Automatic cooling system. After soldering station is switched off, the hot air station is cold aired falling up less then 50C. This option prevents casual burns and prolongs the life time of the heating element.

· Supply voltage of the station: 220-240V AC

· Power consumption: 300W

· Heating element power consumption: 250W

· Compressor power consumption: 20W
