Showing 121–150 of 484 results
-
RF Impedance/Material Analyzer
HP-Agilent/Keysight 4291B
Four component test fixtures (DUT size: 0.5 mm to 20 mm)
Independent parameter selection in 2 channels
Direct read-out permittivity, permeability (option)
Two material fixtures (operating temperature: -55deg C to + 200deg C)
Versatile analysis (temperature, cole-cole plot, relaxation time)
Sweep parameters (frequency, ac level, dc bias, temperature)The Keysight 4291B RF impedance / material analyzer provides a total solution for high-accuracy and easy measurement of surface-mount components and dielectric / magnetic materials. The Keysight 4291B uses a direct current-voltage measurement technique, opposing the reflection measurement technique, for more accurate impedance measurement over wide impedance range.
Basic impedance accuracy is +/- 0.8%. High Q accuracy enables low-loss component analysis. An internal synthesizer sweeps frequency from 1 MHz to 1.8 GHz with 1 mHz resolution. A 1.8-m error-less cable connects the analyzer to a test station so you can extend your test point away from the analyzer without losing accuracy. Advanced calibration and error compensation function eliminate measurement error factors in fixtures and assure high accuracy and repeatability at DUT / MUT.
The Hp 4291B also provides automatic level control and monitor of test signals by using IBASIC programming function; devices can be measured under a constant voltage or current. Measure bias dependent impedance characteristics with optional dc bias (up to 40 V and 100 mA). At the push of a button, the built-in Equivalent Circuit Analysis Function automatically calculates the circuit constant values of five circuit models.
The Hp 4291B has two measurement channels; each channel can be set to measure a single (e.g. Z) or dual (e.g. Z-theta) impedance parameter. The color TFT with split-display can show both active traces and memory traces (stored in RAM). A built-in floppy disk drive stores programs and test data in either LIF or MS-DOS format. With built-in IBASIC, you can control external test equipment such as a temperature chamber or wafer prober directly from the Keysight 4291B. You do not need a separate instrument controller.
Material Evaluation
The Hp 4291B enables easy and sophisticated material evaluation and improves material evaluation quality and efficiency. The Hp 4291B provides the total dielectric / magnetic material measurement solutions in wide frequency range (1 MHz to 1 GHz).
DatasheetSKU: n/a -
Power Meter
HP-Agilent/Keysight 435B
The HP 435B power meter is an analog power meter, compatible with the entire series of 8480 power sensors. Depending on which sensor is used, the 435B can measure power from -65 dBm to +44 dBm, full scale, at frequencies from 100 kHz to 110 GHz. This versatile instrument also features <1 percent instrumentation uncertainty, low noise and drift, auto-zero, recorder output, optional battery operation, and long cable options up to 61 m (200 ft). * Optional battery for fully portable operation * Accurate internal calibration source for long-term accuracy * Nine interchangeable sensors for a wide range of applications * Frequency Range: 100 kHz to 110 GHz * Power Range: -65 to +44 dBm * Instrumentation Accuracy: ±1% * Power Reference Output: 50 MHz/1MW
SKU: 23€85.00 View Product -
Power Meter
HP-Agilent/Keysight 436A
The Keysight 436A power meter is a general-purpose digital power meter intended for manual and automatic radio-frequency (RF) and microwave-power measurements. It is compatible with the entire series of 8480 power sensors. The 436A measures either absolute or relative power. It displays absolute power in either watts or dBm, and relative power in dB. The 436A offers intuitive and straightforward manual operation as well as optional GPIB programmability (Option 022).
Display readings in Watts, dBm or dB relative eliminating measurement conversion
Peaking meter for analog adjustments
Cal factor to compensate each sensor for improved accuracy
Frequency Range: 100 kHz to 110 GHz
Power Range: -70 to +44 dBm
Power Accuracy: ±0.5%
Power Reference: Internal 50 MHz oscillator/Type-N output
DatasheetSKU: 1069 -
Power Meter
HP-Agilent/Keysight 437B
The Keysight 437B power meter is a low-cost, high-performance, single-channel, programmable, average power meter compatible with the 8480 family of power sensors. Depending on which power sensor is used, the 437B can measure from -70 dBm (100pW) to +44 dBm (25W) at frequencies from 100 kHz to 110 GHz.
Designed for the ATE systems and demanding benchtop measurements, the 437B power meter makes fast, accurate, and reliable average power measurements. Only three inches high and half rack wide, the 437B minimizes the use of critical rack space in ATE systems. The advanced plastics technology used in the 437B cabinet combines the light weight of plastic with the shielding effectiveness of metal, making the 437B the only power meter to meet MIL-STD-461C EMI specifications.
Power reference for automatic calibration and zeroing
Duty cycle entry for a convenient peak power representation of the measurement average power
Ten preloaded sensor card factors versus frequency
Frequency Range: 100 kHz to 110 GHz
DatasheetSKU: 815 -
Electronic Counter
HP-Agilent/Keysight 5345A
The Keysight 5345A universal counter is a high-performance microwave and millimeter-wave pulse frequency counter. Operating from dc to 500 MHz, the counter also makes sub-microwave measurements including frequency, period, totalization, ratio, and time interval. As a full universal counter, the 5345A features 2 ns single-shot timing resolution, improving to 2 ps with averaging.
The 5345A mainframe accommodates additional microwave products, including the 5355A Automatic Frequency Converter that extends operation to 1.5 GHz, and the 5356C Converter Head for measurements to 40 GHz. Together, the instruments provide an expandable range of capabilities for characterizing complex radar systems and components.
Output of more than 9000 measurements per second reduces test time
Flexible external gating extends application
Automatic averaging improves accuracy
Standard high-stability timebase lowers cost of ownership
25 mV sensitivity
Frequency with resolution of 9 digits per second
DatasheetSKU: n/a
-
RF Impedance/Material Analyzer
HP-Agilent/Keysight 4291B
Four component test fixtures (DUT size: 0.5 mm to 20 mm)
Independent parameter selection in 2 channels
Direct read-out permittivity, permeability (option)
Two material fixtures (operating temperature: -55deg C to + 200deg C)
Versatile analysis (temperature, cole-cole plot, relaxation time)
Sweep parameters (frequency, ac level, dc bias, temperature)The Keysight 4291B RF impedance / material analyzer provides a total solution for high-accuracy and easy measurement of surface-mount components and dielectric / magnetic materials. The Keysight 4291B uses a direct current-voltage measurement technique, opposing the reflection measurement technique, for more accurate impedance measurement over wide impedance range.
Basic impedance accuracy is +/- 0.8%. High Q accuracy enables low-loss component analysis. An internal synthesizer sweeps frequency from 1 MHz to 1.8 GHz with 1 mHz resolution. A 1.8-m error-less cable connects the analyzer to a test station so you can extend your test point away from the analyzer without losing accuracy. Advanced calibration and error compensation function eliminate measurement error factors in fixtures and assure high accuracy and repeatability at DUT / MUT.
The Hp 4291B also provides automatic level control and monitor of test signals by using IBASIC programming function; devices can be measured under a constant voltage or current. Measure bias dependent impedance characteristics with optional dc bias (up to 40 V and 100 mA). At the push of a button, the built-in Equivalent Circuit Analysis Function automatically calculates the circuit constant values of five circuit models.
The Hp 4291B has two measurement channels; each channel can be set to measure a single (e.g. Z) or dual (e.g. Z-theta) impedance parameter. The color TFT with split-display can show both active traces and memory traces (stored in RAM). A built-in floppy disk drive stores programs and test data in either LIF or MS-DOS format. With built-in IBASIC, you can control external test equipment such as a temperature chamber or wafer prober directly from the Keysight 4291B. You do not need a separate instrument controller.
Material Evaluation
The Hp 4291B enables easy and sophisticated material evaluation and improves material evaluation quality and efficiency. The Hp 4291B provides the total dielectric / magnetic material measurement solutions in wide frequency range (1 MHz to 1 GHz).
Datasheet -
Power Meter
HP-Agilent/Keysight 435B
The HP 435B power meter is an analog power meter, compatible with the entire series of 8480 power sensors. Depending on which sensor is used, the 435B can measure power from -65 dBm to +44 dBm, full scale, at frequencies from 100 kHz to 110 GHz. This versatile instrument also features <1 percent instrumentation uncertainty, low noise and drift, auto-zero, recorder output, optional battery operation, and long cable options up to 61 m (200 ft). * Optional battery for fully portable operation * Accurate internal calibration source for long-term accuracy * Nine interchangeable sensors for a wide range of applications * Frequency Range: 100 kHz to 110 GHz * Power Range: -65 to +44 dBm * Instrumentation Accuracy: ±1% * Power Reference Output: 50 MHz/1MW
-
Power Meter
HP-Agilent/Keysight 436A
The Keysight 436A power meter is a general-purpose digital power meter intended for manual and automatic radio-frequency (RF) and microwave-power measurements. It is compatible with the entire series of 8480 power sensors. The 436A measures either absolute or relative power. It displays absolute power in either watts or dBm, and relative power in dB. The 436A offers intuitive and straightforward manual operation as well as optional GPIB programmability (Option 022).
Display readings in Watts, dBm or dB relative eliminating measurement conversion
Peaking meter for analog adjustments
Cal factor to compensate each sensor for improved accuracy
Frequency Range: 100 kHz to 110 GHz
Power Range: -70 to +44 dBm
Power Accuracy: ±0.5%
Power Reference: Internal 50 MHz oscillator/Type-N output
Datasheet -
Power Meter
HP-Agilent/Keysight 437B
The Keysight 437B power meter is a low-cost, high-performance, single-channel, programmable, average power meter compatible with the 8480 family of power sensors. Depending on which power sensor is used, the 437B can measure from -70 dBm (100pW) to +44 dBm (25W) at frequencies from 100 kHz to 110 GHz.
Designed for the ATE systems and demanding benchtop measurements, the 437B power meter makes fast, accurate, and reliable average power measurements. Only three inches high and half rack wide, the 437B minimizes the use of critical rack space in ATE systems. The advanced plastics technology used in the 437B cabinet combines the light weight of plastic with the shielding effectiveness of metal, making the 437B the only power meter to meet MIL-STD-461C EMI specifications.
Power reference for automatic calibration and zeroing
Duty cycle entry for a convenient peak power representation of the measurement average power
Ten preloaded sensor card factors versus frequency
Frequency Range: 100 kHz to 110 GHz
Datasheet -
Electronic Counter
HP-Agilent/Keysight 5345A
The Keysight 5345A universal counter is a high-performance microwave and millimeter-wave pulse frequency counter. Operating from dc to 500 MHz, the counter also makes sub-microwave measurements including frequency, period, totalization, ratio, and time interval. As a full universal counter, the 5345A features 2 ns single-shot timing resolution, improving to 2 ps with averaging.
The 5345A mainframe accommodates additional microwave products, including the 5355A Automatic Frequency Converter that extends operation to 1.5 GHz, and the 5356C Converter Head for measurements to 40 GHz. Together, the instruments provide an expandable range of capabilities for characterizing complex radar systems and components.
Output of more than 9000 measurements per second reduces test time
Flexible external gating extends application
Automatic averaging improves accuracy
Standard high-stability timebase lowers cost of ownership
25 mV sensitivity
Frequency with resolution of 9 digits per second
Datasheet
-
RF Impedance/Material Analyzer
HP-Agilent/Keysight 4291B
Four component test fixtures (DUT size: 0.5 mm to 20 mm)
Independent parameter selection in 2 channels
Direct read-out permittivity, permeability (option)
Two material fixtures (operating temperature: -55deg C to + 200deg C)
Versatile analysis (temperature, cole-cole plot, relaxation time)
Sweep parameters (frequency, ac level, dc bias, temperature)The Keysight 4291B RF impedance / material analyzer provides a total solution for high-accuracy and easy measurement of surface-mount components and dielectric / magnetic materials. The Keysight 4291B uses a direct current-voltage measurement technique, opposing the reflection measurement technique, for more accurate impedance measurement over wide impedance range.
Basic impedance accuracy is +/- 0.8%. High Q accuracy enables low-loss component analysis. An internal synthesizer sweeps frequency from 1 MHz to 1.8 GHz with 1 mHz resolution. A 1.8-m error-less cable connects the analyzer to a test station so you can extend your test point away from the analyzer without losing accuracy. Advanced calibration and error compensation function eliminate measurement error factors in fixtures and assure high accuracy and repeatability at DUT / MUT.
The Hp 4291B also provides automatic level control and monitor of test signals by using IBASIC programming function; devices can be measured under a constant voltage or current. Measure bias dependent impedance characteristics with optional dc bias (up to 40 V and 100 mA). At the push of a button, the built-in Equivalent Circuit Analysis Function automatically calculates the circuit constant values of five circuit models.
The Hp 4291B has two measurement channels; each channel can be set to measure a single (e.g. Z) or dual (e.g. Z-theta) impedance parameter. The color TFT with split-display can show both active traces and memory traces (stored in RAM). A built-in floppy disk drive stores programs and test data in either LIF or MS-DOS format. With built-in IBASIC, you can control external test equipment such as a temperature chamber or wafer prober directly from the Keysight 4291B. You do not need a separate instrument controller.
Material Evaluation
The Hp 4291B enables easy and sophisticated material evaluation and improves material evaluation quality and efficiency. The Hp 4291B provides the total dielectric / magnetic material measurement solutions in wide frequency range (1 MHz to 1 GHz).
Datasheet -
Power Meter
HP-Agilent/Keysight 435B
The HP 435B power meter is an analog power meter, compatible with the entire series of 8480 power sensors. Depending on which sensor is used, the 435B can measure power from -65 dBm to +44 dBm, full scale, at frequencies from 100 kHz to 110 GHz. This versatile instrument also features <1 percent instrumentation uncertainty, low noise and drift, auto-zero, recorder output, optional battery operation, and long cable options up to 61 m (200 ft). * Optional battery for fully portable operation * Accurate internal calibration source for long-term accuracy * Nine interchangeable sensors for a wide range of applications * Frequency Range: 100 kHz to 110 GHz * Power Range: -65 to +44 dBm * Instrumentation Accuracy: ±1% * Power Reference Output: 50 MHz/1MW
€85.00 View Product -
Power Meter
HP-Agilent/Keysight 436A
The Keysight 436A power meter is a general-purpose digital power meter intended for manual and automatic radio-frequency (RF) and microwave-power measurements. It is compatible with the entire series of 8480 power sensors. The 436A measures either absolute or relative power. It displays absolute power in either watts or dBm, and relative power in dB. The 436A offers intuitive and straightforward manual operation as well as optional GPIB programmability (Option 022).
Display readings in Watts, dBm or dB relative eliminating measurement conversion
Peaking meter for analog adjustments
Cal factor to compensate each sensor for improved accuracy
Frequency Range: 100 kHz to 110 GHz
Power Range: -70 to +44 dBm
Power Accuracy: ±0.5%
Power Reference: Internal 50 MHz oscillator/Type-N output
Datasheet -
Power Meter
HP-Agilent/Keysight 437B
The Keysight 437B power meter is a low-cost, high-performance, single-channel, programmable, average power meter compatible with the 8480 family of power sensors. Depending on which power sensor is used, the 437B can measure from -70 dBm (100pW) to +44 dBm (25W) at frequencies from 100 kHz to 110 GHz.
Designed for the ATE systems and demanding benchtop measurements, the 437B power meter makes fast, accurate, and reliable average power measurements. Only three inches high and half rack wide, the 437B minimizes the use of critical rack space in ATE systems. The advanced plastics technology used in the 437B cabinet combines the light weight of plastic with the shielding effectiveness of metal, making the 437B the only power meter to meet MIL-STD-461C EMI specifications.
Power reference for automatic calibration and zeroing
Duty cycle entry for a convenient peak power representation of the measurement average power
Ten preloaded sensor card factors versus frequency
Frequency Range: 100 kHz to 110 GHz
Datasheet -
Electronic Counter
HP-Agilent/Keysight 5345A
The Keysight 5345A universal counter is a high-performance microwave and millimeter-wave pulse frequency counter. Operating from dc to 500 MHz, the counter also makes sub-microwave measurements including frequency, period, totalization, ratio, and time interval. As a full universal counter, the 5345A features 2 ns single-shot timing resolution, improving to 2 ps with averaging.
The 5345A mainframe accommodates additional microwave products, including the 5355A Automatic Frequency Converter that extends operation to 1.5 GHz, and the 5356C Converter Head for measurements to 40 GHz. Together, the instruments provide an expandable range of capabilities for characterizing complex radar systems and components.
Output of more than 9000 measurements per second reduces test time
Flexible external gating extends application
Automatic averaging improves accuracy
Standard high-stability timebase lowers cost of ownership
25 mV sensitivity
Frequency with resolution of 9 digits per second
Datasheet
