Rigol DS2072A-S

70MHz, 2GSa/s, 2 channels, 2 channels Arbitrary

945.00

The DS2000 series digital oscilloscope is another Best-In-Class instrument from Rigol offering an unmatched feature/value package. The DS2000 is a fast and versatile scope covering frequencies up to 200 MHz with two channels and a wide vertical range (500uV/div-10V/div) to deliver an extremely low noise floor to help you capture smaller signals. Add a 2 GSa/s max. sample rate and 14 Mpts. of standard memory depth to its user-friendly interface and 8 inch WVGA display and you’ve got a scope that outperforms the competition in a wide range of bench-top and field applications. • Wider vertical range(500uV/div ~ 10V/div), lower noise floor, better for small signal capturing • Full bandwidth, lower overshoot(<5%),perfact frequency response design • Bandwidth 70MHz, 100MHz, 200MHz up to 300MHz,standard with 50O input • Max. Sample Rate 2G Sa/s • Standard Memory Depth up to14Mpts,Optional Memory Depth up to 56Mpts • Innovative "UltraVision" technology • Complete connectivities :USB Host,USB Device, LAN(LXI Core Device 2011), AUX • Compact size, light weight, easy to use • 8 inch TFT (800x480) WVGA • Up to 65,000 frames Hardware based Real Time waveform Record, Replay and Analysis function(Std.) • Memory Depth up to 14Mpts(Std.), 56Mpts(Opt.) • Innovative "UltraVision" Technology • Waveform capture rate up to 50,000 wfs/s • Up to 256 Levels intensity grading waveform display

SKU: 783 Category:

Brand

Rigol
