TEKTRONIX TAP2500

TAP2500 is a single-ended active FET probe. It provides excellent high-speed electrical and mechanical performance required for today’s digital system designs. It is an easy access to oscilloscope probe menu display for probe status/diagnostic information and to control probe DC offset. It provides truer signal reproduction and fidelity for high-frequency measurements. It is specifically designed for use and direct connection to oscilloscopes with the TekVPI™ probe interface, the TAP2500 active FET probes achieve high-speed signal acquisition and measurement fidelity by solving three traditional problems they are lower DUT loading effects with ≤0.8pF input capacitance and 40kΩ input resistance, versatile DUT connectivity for attaching to small SMDs and preserves instrument bandwidth at the probe tip for up to 3.5GHz oscilloscopes.

High probe bandwidth
Fast probe rise time
Excellent signal fidelity
Small compact probe head for probing small geometry circuit elements
Robust design for reliability
Connects directly to oscilloscopes with the TekVPI™ probe interface
Provides automatic units scaling and readout on the oscilloscope display
Remote GPIB/USB probe control through the oscilloscope
